E-MCR-05
Media Converter Rack
User Guide
Supports up to twelve media converters
•
Powered by a single internal universal power supply
•
Media converters are hot swappable
•
Includes twelve Shelf Support Panels
•
Contents
Introduction ................................................................................................................................................................1
Package Contents .......................................................................................................................................................2
Optional Accessories (sold separately) .......................................................................................................................2
Optional Converter Mounting Brackets .................................................................................................................2
Installation ..................................................................................................................................................................2
Table Top Installation .............................................................................................................................................2
Rack Installation .....................................................................................................................................................2
Power Cord Included ..............................................................................................................................................2
Maintenance ...............................................................................................................................................................7
Technical Specifications ..............................................................................................................................................8
E-MCR-05 Specifications ........................................................................................................................................8
Power Supply Specifications ..................................................................................................................................8
Compliance Information .............................................................................................................................................9
Declaration of Conformity......................................................................................................................................9
FCC Regulations ......................................................................................................................................................9
Canadian Regulations .............................................................................................................................................9
European Regulations ......................................................................................................................................... 10
Contact Us ............................................................................................................................................................... 10
Warranty .................................................................................................................................................................. 10
Record of Revisions ................................................................................................................................................. 11
Introduction
Transition Networks E-MCR-05 series media converter rack provides space and power in a rack-mountable
chassis for twelve (12) separate and independent Transition Networks stand-alone media converters, each with
power requirements of 12 VDC.
Note: The E-MCR-05 media converter rack is intended for the installation of media converters designed and built
by Transition Networks only.
The E-MCR-05 provides installation space for up to twelve (12) Transition Networks stand-alone media
converters that require an external power supply.
33392 Rev. C
www.transition.com/
Page 1 of 12
Advertisement
Table of Contents
Summary of Contents for Transition Networks E-MCR-05
-
Page 1: Table Of Contents
(12) separate and independent Transition Networks stand-alone media converters, each with power requirements of 12 VDC. Note: The E-MCR-05 media converter rack is intended for the installation of media converters designed and built by Transition Networks only. -
Page 2: Package Contents
The E-MCR-05 ships with four (4) attachment screws for installation in a standard rack. Warning: Take care to mount the E-MCR-05 so that it will not fall. Failure to observe this warning could result in an injury or damage to the equipment. - Page 3 Locate four (4) screws (provided) and optional clip-nuts (not provided) for each E-MCR-05 Media Converter Rack. Carefully align the E-MCR-05 at a level position between the rack mounting rails as shown on the next page. Install two (2) screws through the right front bracket and two (2) screws through the left front bracket; use the clip nuts to secure the E-MCR-05 to the rack.
- Page 4 Install Media Converters into E-MCR-05 1. Position the media converter in the E-MCR-05 as shown below and then carefully slide it into the slot. 2. Tighten the panel fastener located directly under the media converter to secure it to the E-MCR-05.
- Page 5 Transition Networks E-MCR-05 User Guide Input Power / Fuse Label Connect Power to Media Converters 1. Select a barrel connector end of one power supply cable that is inserted into the harness as shown below. 2. Insert the octopus power supply cable into the media converter as shown below.
- Page 6 Specifications on page for current and power maximums. WARNING: Make sure that the E-MCR-05 is properly grounded. Failure to observe this warning could result in an electrical shock. 1. Locate the power cord. 2. Insert the female end of the power cord into the power supply AC power inlet shown below.
-
Page 7: Maintenance
1. Turn the power rocker switch to the OFF position (O) as shown below. 2. Remove the power cord from the power supply of the E-MCR-05. 3. Insert a small flat-blade screwdriver at the fuse holder as shown below and pull or carefully pry outward to dislodge the fuse holder. -
Page 8: Technical Specifications
Warranty: Lifetime Note: Information in this document was deemed accrurate at the time of publication. For the most current information on the E-MCR-05, view the online user guide at https://www.transition.com/. Power Supply Specifications Power Supply: Universal, internal power supply; AC 85 – 264V, 47 – 63 Hz. -
Page 9: Compliance Information
Transition Networks E-MCR-05 User Guide Compliance Information Declaration of Conformity FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 10: European Regulations
In accordance with European Union Directive 2002/96/EC of the European Parliament and of the Council of 27 January 2003, Transition Networks will accept post usage returns of this product for proper disposal. The contact information for this activity can be found in the 'Contact Us' portion of this document. -
Page 11: Record Of Revisions
Networks for a fee will carry a 180-day limited warranty. All warranty claims are subject to the restrictions and conventions set forth by this document. Transition Networks reserves the right to charge for all testing and shipping incurred, if after testing, a return is classified as "No Problem Found."... - Page 12 Transition Networks E-MCR-05 User Guide E-MCR-05 Media Converter Rack User Guide, 33392 Rev. C 33392 Rev. C https://www.transition.com/ Page 12 of 12...
