X2E XORAYA DATACUBE User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X
D
ORAYA
ATACUBE
User Manual
Version: 1.2 / March 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XORAYA DATACUBE and is the answer not in the manual?

Questions and answers

Summary of Contents for X2E XORAYA DATACUBE

  • Page 1 ORAYA ATACUBE User Manual Version: 1.2 / March 2018...
  • Page 2 This user manual is protected by copyright; all usual rights reserved. Reproduction of this user manual, even in part, is only permitted with the approval of X2E GmbH. Any infringement will result in liability for damages and may result in criminal prosecution.

  • Page 3: Table Of Contents

    User Manual ORAYA ATACUBE Table of contents Introduction ..................... 4 Intended use .................... 4 Delivery contents ..................4 General safety instructions ..............5 Connections and controls ................ 6 Installation ....................9 Connecting ....................9 Suite ..................10 ORAYA Network settings ..................11 Operation ....................

  • Page 4: Introduction

    ORAYA Check to ensure that the delivery is complete and all hardware components are in sound condition. If the delivery is incomplete or supplied components are damaged, contact X2E immediately. Do not use damaged components.

  • Page 5: General Safety Instructions

    User Manual ORAYA ATACUBE General safety instructions The X is only intended for use by qualified personnel. Read the user man- ORAYA ATACUBE ual and especially this chapter thoroughly before operating. CAUTION Electric shock due to damaged components Damages to the D , the power cord or the AC adapter can result in ATACUBE electric shock.

  • Page 6: Connections And Controls

    User Manual ORAYA ATACUBE Connections and controls Front view Back view...
  • Page 7 ATACUBE Service LAN port (E) In case of errors, this port is used as a debugging interface by the X2E support team. USB 3.0 ports (F) Perform a firmware update by using a USB flash drive containing the suitable ISO file.
  • Page 8 User Manual ORAYA ATACUBE The bold settings on the attached label indicate the default configuration: RJ45 port LEDs: Colour Meaning Activity flashing yellow data is transferred (off) no connection Link speed orange 1 Gbit/s green 100 Mbit/s for 1GbE ports 10 Gbit/s for 10GbE ports (off) no connection or 10 Mbit/s...

  • Page 9: Installation

    User Manual ORAYA ATACUBE Installation Connecting CAUTION Device damage due to overheating Overheating may result in malfunction or destruction of the D ATACUBE  Do not operate the D in the vicinity of heat sources. ATACUBE  Ensure adequate air circulation. ...

  • Page 10: Xoraya Suite

    User Manual ORAYA ATACUBE Suite ORAYA The graphical user interface X Suite is available to configure and to control the ORAYA ATACUBE Supported operating systems:  Microsoft® Windows® 7 (32 Bit or 64 Bit)  Microsoft® Windows® 8 (32 Bit or 64 Bit) ...

  • Page 11: Network Settings

    User Manual ORAYA ATACUBE Network settings The X Suite extra tool HWFinder enables access to a web interface to change the con- ORAYA figuration of the 1GbE (G) and 10GbE (H) LAN ports.  Start the X Suite. ORAYA  Click in the Windows notification area.
  • Page 12 User Manual ORAYA ATACUBE  In the menu on the left side, select the category Network configuration.  Click the desired port in the graphic.  Click one of the tabs Port A to Port D.  Activate the Editmode. ...

  • Page 13: Operation

    User Manual ORAYA ATACUBE Operation Download via Hdd-Control The Hdd-Control tool allows downloading log data from X external storage units to the ORAYA  Start the X Suite. ORAYA  Click Hdd-Control. Connect D ATACUBE  Connect the D to power supply, PC and one or more X external stor- ATACUBE ORAYA...
  • Page 14 User Manual ORAYA ATACUBE Each cell contains for each connection or for each connected device:  port number (1-6)  connection date and time  configuration, consisting of four blocks: product ID, product variant, hardware revision and serial number  percentage of used space ...
  • Page 15 User Manual ORAYA ATACUBE To eject a X external storage unit safely or to activate another device, click Change ORAYA disk (5). Via Settings (6) or the Settings command in the Download menu, you can configure that the connection is automatically released after downloading. There are different ways to select the log data to download.
  • Page 16 User Manual ORAYA ATACUBE Calendar tab Displayed date and Zoom:  Filter the displayed measurements, for example, by default or streaming queue (a).  Specify a start date (b).  Choose between Week and Day (c) as the displayed time unit. ...
  • Page 17 User Manual ORAYA ATACUBE Time range tab  Specify start date (a) and start time (b) of the desired time range.  Specify the end date (c). Use the arrows (d) optionally to apply the start date or to jump one day forward or backward. ...
  • Page 18 In the Download menu, click Cancel. Analyse log data  Click (7) to open the path last used in Windows Explorer.  After downloading into the X2E-Native output format, double-click the DLI file to open the measurement with the Viewer tool.
  • Page 19 User Manual ORAYA ATACUBE Disconnect D ATACUBE  Click Release connection to logger (2).  In the Logger menu, click Disconnect. and Hdd-Control are disconnected. ATACUBE...

  • Page 20: Automatic Download Service

    User Manual ORAYA ATACUBE Automatic download service This X Suite extra tool is a server, which automatically downloads log data from se- ORAYA lected D s (and dataloggers). ATACUBE  Start the X Suite. ORAYA  Click in the Windows notification area. ...
  • Page 21 User Manual ORAYA ATACUBE In the category White list, select the devices for the automatic download service.  Click Refresh the device list (a) to search for D s and dataloggers in the net- ATACUBE work again.  Select the check boxes (b) for all devices that you want to add to the white list. For a selected device, the symbol (c) changes from if it is currently not reachable.

  • Page 22: Update Firmware

    User Manual ORAYA ATACUBE Update firmware  Start the D web interface (see chapter Network settings). ATACUBE  In the menu on the left side, select the category Firmware Update.  Click Browse… (1) and select a suitable XSWU file. ...

  • Page 23: Cleaning

    Never open the D ATACUBE  Maintenance and repair must be carried out by X2E personnel only.  In case of malfunctions or damages, please contact X2E via e-mail to get information about returning the D xoraya-return@x2e.de ATACUBE Disposal Within the European Union, the disposal of electrical devices is determined...
  • Page 26 X2E GmbH Jahnstrasse 2b 76870 Kandel GERMANY Phone +49 7275 9143 100 +49 7275 9143 109 E-Mail info@x2e.de Internet http://www.x2e.de...
