INSTALLATION INSTRUCTIONS
TufBox Base
Warranty
Thank you for purchasing the TufBox manufactured by TUFLOC. We have worked hard to develop the best
storage box on the market and warrant this product for one year from date of purchase against defects in
materials and workmanship. This warranty is limited to replacement or repair of the product only. No other
warranties are expressed or implied. Please contact the factory for warranty claims before returning any
product.
1-800-321-0870 • 330-452-9132 • Fax 330-452-2557
1406 Fifth Street, SW • Canton, Ohio 44702 • USA
info@esmet.com • Tufloc.com
6/18
Advertisement
Table of Contents
Summary of Contents for TUFLOC TufBox Base
- Page 1 TufBox Base Warranty Thank you for purchasing the TufBox manufactured by TUFLOC. We have worked hard to develop the best storage box on the market and warrant this product for one year from date of purchase against defects in materials and workmanship. This warranty is limited to replacement or repair of the product only. No other warranties are expressed or implied.
- Page 2 When the TufBox is installed, the spare tire WILL NOT be accessible if it is kept under the cargo mat unless the TufBox Base is installed at Position 3. The spare tire must remain in its original location in the Ford Interceptor.
- Page 3 Base Kit Components 1-800-321-0870 • 330-452-9132 • Fax 330-452-2557 1406 Fifth Street, SW • Canton, Ohio 44702 • USA info@esmet.com • Tufloc.com...
- Page 4 Next, while pressing in on the Retaining Tabs located on the sides of the drawer, lift up on the front of the drawer, removing it from the tabs and pull it away from the cabinet. (See detail below) 1-800-321-0870 • 330-452-9132 • Fax 330-452-2557 1406 Fifth Street, SW • Canton, Ohio 44702 • USA info@esmet.com • Tufloc.com...
- Page 5 Using five Hex Head Bolts, mount each side of the Base to the TufBox. (See Diagrams below for mounting in Positions 1, 2 or 3) 1-800-321-0870 • 330-452-9132 • Fax 330-452-2557 1406 Fifth Street, SW • Canton, Ohio 44702 • USA info@esmet.com • Tufloc.com...
- Page 6 Using the correct mounting holes, mount the Base in Position 2 or 3 using the supplied Straps and Fasteners. Install the four straps, two in front and two in back, as shown in the diagram above. 1-800-321-0870 • 330-452-9132 • Fax 330-452-2557 1406 Fifth Street, SW • Canton, Ohio 44702 • USA info@esmet.com • Tufloc.com...
- Page 7 TufBox assembly into the rear compartment. Line up the pre-drilled holes in the TufBox Base with the two empty bolt-holes in the vehicle. Insert the two long bolts into the TufBox Base and tighten. Locate the two mounting holes in the front of the Base and use the supplied lag screws to secure the front of the Base to the cargo mat (See detail below).
- Page 8 Standard T-Handle: An adjustable cam can be adjusted to keep the drawer tight and eliminate rattle (See diagrams below). Combination Lock: Please refer to enclosed instruction booklet. 1-800-321-0870 • 330-452-9132 • Fax 330-452-2557 1406 Fifth Street, SW • Canton, Ohio 44702 • USA info@esmet.com • Tufloc.com...
