GENERATOR COLD WEATHER KIT

P/N 2881433

APPLICATION

P1000i AND P2000i 60 Hz GENERATOR

BEFORE YOU BEGIN

Read these instructions thoroughly and make sure all parts and tools are accounted for. Please retain these

installation instructions for future reference and parts ordering information.

KIT CONTENTS

Ref

Qty

TOOLS NEEDED

Hex Wrench, Inner, M6 (Polaris PN 3410206) (Included in the Generator Package)

Phillips Screwdriver

APPROXIMATE ASSEMBLY TIME

30 min

IMPORTANT

Your Polaris GENERATOR COLD WEATHER KIT is exclusively designed for your machine. Please

read the installation instructions thoroughly before beginning. For your safety, and to ensure a

satisfactory installation, perform all installation steps correctly in the sequence shown.

Generator Cold Weather Kit

P/N 9926344 Rev 01 01/15 Page 1 of 4

17" Flat Length Coiled

around a 1/2" Mandrel

Part Description

Zip Ties

Instructions

Part Number

2881433

9926344

Page 1 30 min IMPORTANT Your Polaris GENERATOR COLD WEATHER KIT is exclusively designed for your machine. Please read the installation instructions thoroughly before beginning. For your safety, and to ensure a satisfactory installation, perform all installation steps correctly in the sequence shown.
Page 2 INSTALLATION INSTRUCTIONS 1. Polaris Cold Weather Kit (1) is designed to provide reliable operation in regions that experience low ambient temperature. 17” Flat Length Coiled around a 1/2” Mandrel 2. Disconnect all power loads from the generator, shut down the generator (please see details from generator operator’s manual).
Page 3 5. Wrap the flexible heater (E) onto the breather tube (D) until it is fully in place. 6. Re-connect the breather tube to the air cleaner/filter cover. 7. Remove the generator front control panel (F) with Phillips screw driver. 8. Connect either lead (G) from the Cold Weather kit wire connector to the 120V, AC receptacle (H), positive side, from the back of the generator set front...
Page 4 9. Connect the other lead (J) from the Cold Weather kit wire connector to the 120V, AC receptacle (H), negative side, 120V AC Power Wire, from the back of the generator set front Negative, Black control panel. 10. Route the Cold Weather kit harness by using cable zip ties (K) to connect to the stainless steel support rod (L).
