Summary of Contents for Lowel TOTA LED
- Page 1 DAYLIGHT LED FLOODLIGHT USER MANUAL...
- Page 2 The TOTA-LED is a portable flood light that emits 4275 lux (@ 1 m) of flicker-free continuous light. It operates on AC or battery power, and it draws only 70 W to deliver the equivalent output of a 750 W tungsten bulb.
- Page 3 PRODUCT CONTENTS · LOWEL TOTA-LED floodlight with yoke · Power source · AC power adapter and power cord · Diffuser · V-mount attachment strap · Carry case TOTA-LED USER MANUAL...
-
Page 4: Product Overview
Barndoors Diffuser slot Umbrella mount Tilt locking knob 1/4-20 mounting PRODUCT socket OVERVIEW Gel clips Umbrella locking knob Mounting foot Yoke Locking knob Carrying case 5/8 in. mounting receiver Power adapter AC power cable 3-pin XLR cable TOTA-LED USER MANUAL... - Page 5 Hanger loop Dimmer control box Battery Mounting-shoe release button slot Battery contacts D-tap power socket Brightness 3-pin XLR control power input Power output 3-way power cable V-mount switch battery slot V-mount adapter with touch-connect strap TOTA-LED USER MANUAL...
- Page 6 · Do not attempt to disassemble or manufacturer. repair the equipment—doing so will · Make sure the item is intact and that void the warranty, and Lowel will not there are no missing parts. be responsible for any damage. · All images are for illustrative ·...
-
Page 7: Mounting The Light
MOUNTING THE POWERING THE LIGHT TOTA-LED The two-way 5/8-inch receiver allows the yoke The TOTA-LED can be powered directly from to be mounted vertically or horizontally. an AC outlet or by a V-mount battery (not included). Mount the yoke horizontally to use the TOTA- LED as a flood light. - Page 8 POWERING THE TOTA-LED (CONTINUED) To move the control box safely out of 2. To connect the power output cable to the the way and avoid clutter: TOTA-LED’s 4-pin connector, align the internal notch and channel of the two 1. Align the yoke’s mounting foot with the connectors and press the two together.
- Page 9 POWERING THE TOTA-LED (CONTINUED) Alternative method: Using the TOTA-LED with Battery Power 1. Wrap the touch-connect strap securely 1. When attaching a V-mount battery, make around the AC adapter. sure the power switch is in the off position, and disconnect the AC adapter so the control 2.
- Page 10 ADJUSTING THE LIGHT Brightness Control Umbrella The brightness control on the control box can An umbrella hole and locking knob are built adjust the output from 100% to 0%. into the yoke and angled so the light will be centered when the umbrella is added to Diffuser your setup.
-
Page 11: Product Specifications
PRODUCT SPECIFICATIONS LED Count: Battery Mount Type: V-mount Color Temperature: 5600K DC Operating Voltage: 16 V, 5 A Dimming: 100% to 0% AC Adaptor: SP-AC15 (16 V/5 A) Luminance: 4275 lx @ 1 m Bulb Life: 50,000 hr. Coverage: 65° (without diffuser) Battery: 14.8 V 100°... -
Page 12: One-Year Limited Warranty
In the event of a defect reported by the consumer within the applicable time period, Lowel will, at its option, replace or repair the defective merchandise at no charge to the consumer for either parts or labor. If the product has been discontinued Lowel reserves the right to replace the product with a model of equivalent quality and function.
