DC COMPRESSOR FRIDGE/FREEZER MODEL: Glacier 1.1
Congratulations on the purchase of the Grape Solar Glacier 1.1 Refrigerator/Freezer. We trust that you will
enjoy many years of trouble free use. Please read the instructions carefully before using your Refrigerator/
Freezer. This book will provide you with information on how to operate and care for your Refrigerator/
Freezer in order to gain the maximum benefit from it.
The appliance must be connected to a suitable 120volt or 12 volt socket. The manufacturer and the seller do
not accept responsibility for any damage due to incorrect electrical installation.
www.grapesolar.com
Tel. 1-877-264-1014 (toll free), 1-541-349-9000, Fax: 1-541-343-9000
Grape Solar
INSTRUCTION MANUAL
©Copyright 2012, Grape Solar, Inc. All Rights Reserved
ENGLISH
GS-CF-1.1-Fab1
Reference Manual Rev. 130515
Valid from May 2013
1
Advertisement
Table of Contents
Summary of Contents for Grape Solar Glacier 1.1 GS-CF-1.1-Fab1
- Page 1 INSTRUCTION MANUAL ENGLISH Congratulations on the purchase of the Grape Solar Glacier 1.1 Refrigerator/Freezer. We trust that you will enjoy many years of trouble free use. Please read the instructions carefully before using your Refrigerator/ Freezer. This book will provide you with information on how to operate and care for your Refrigerator/ Freezer in order to gain the maximum benefit from it.
-
Page 2: Input Requirements
GS-CF-1.1-Fab1 Reference Manual Rev. 130515 INPUT REQUIREMENTS DC Input Voltage Range:10.9Vdc~28Vdc Cut Out: 10.4Vdc Cut In: 11.8Vdc AC Input Voltage Range: 120Vdc TEST-RUN Do not pull the appliance by the power cord. Connect power, set the digital thermostat to 0°F and check the indicators, 30 minutes later, open the door and check the inside surface. -
Page 3: Defrosting And Deodorizing
SAFETY A separate grounded 15A socket outlet should be used on 120Vac and at least a 120Wdc socket on 12Vdc. In the event of any malfunction of your freezer, please contact Grape Solar Technical Support. www.grapesolar.com Valid from May 2013... -
Page 4: Main Technical Parameters
GS-CF-1.1-Fab1 Reference Manual Rev. 130515 MOVEMENT AND INSTALL ATION When moving the freezer, the angle between the cabinet and the ground should not be more than 45 degrees C in order to protect the compressor and refrigerating system. Position the freezer in a dry and well-ventilated place. Keep the freezer away from direct sunlight, heaters and corrosive gases. -
Page 5: Circuit Diagram
1～5 minutes and normal stops The compressor runs The refrigerant has but inner liner does not leaked Contact Grape Solar get cold The system is blocked The controller is faulty Contact Grape Solar The door is being The door should be...
