SLI SECO-LARM ENFORCER SD-6176-SSVQ Manual

ENFORCER Outdoor Piezoelectric Request to Exit Pushbutton
Sample Installation:
Electromagnetic Lock (Fail-Safe) with Strobe Light
Also Available from SECO-LARM:
Electromagnetic Request-to-Exit
Locks Plates

WARRANTY

This SECO-LARM product is warranted against defects in material and workmanship while
used in normal service for a period of one (1) year from the date of sale to the original consumer customer.
SECO-LARM's obligation is limited to the repair or replacement of any defective part if the unit is returned,
transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of
God, physical or electrical misuse or abuse, neglect, repair, or alteration, improper or abnormal usage, or
faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating
properly as a result of causes other than defects in material and workmanship. The sole obligation of
SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or
consequential personal or property damages of any kind to the purchaser or anyone else.

NOTICE

: The information and specifications printed in this manual are current at the time of publication.
However, the SECO-LARM policy is one of continual development and improvement. For this reason,
SECO-LARM reserves the right to change specifications without notice. SECO-LARM is also not
responsible for misprints or typographical errors.
Copyright © 2011 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or
copied, in whole or in part, without the written permission of SECO-LARM.
®
U.S.A., Inc.
SECO-LARM
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
ENFORCER
ENFORCER
Electromagnetic Lock
LED Strobe Light
No-Touch RF Wireless
Request-to-Exit Request-to-Exit
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
MiSD-6x73-SSxQ_1112.docx
SECO-LARM U.S.A., Inc
Outdoor Piezoelectric
Request-to-Exit Pushbuttons
SD-6176-SSVQ
SD-6276-SSVQ
SD-6176-SS1Q
SD-6276-SS1Q
SD-6176-SSQ*
SD-6276-SSQ*
*
Special order item. Please contact SECO-LARM.
• Piezoelectric push buttons for indoor
or outdoor use (IP65).
• LED ring around button changes from
green to red or red to green when the
button is pressed.
• Timed or toggle output.
PIHWK1
Note: Products with model numbers that end with "Q" or that have a round green "Q" sticker are RoHS compliant.
Manual
Slimeline plate, manual override
Single-gang plate, manual override
Slimline plate, "EXIT/SALIDA"
Single-gang plate, "EXIT/SALIDA"
Slimline plate, "TOUCH/EXIT"
Single-gang plate, "TOUCH/EXIT"
• Includes separate manual override
button in case power to piezoelectric
push button fails.
• Relay rated 2A@30VDC with two
individually programmable outputs
(NO/NC).
