Radio System Corporation 400-1988 Quick Start Manual

Read all warnings.
QUICK START GUIDE
Full operation and training guide included.
Components
Carry
Hopper Handle
Distance
Knob- pull
and turn to
adjust
Tennis Balls Power Cord
and AC adapter
The motion sensor detects
movement from up to 7 feet
away. Your dog should be
standing behind that distance.
Motion detected will pause the
machine for 5 seconds
Customer Care Center 1-800-732-2677
The world leader in pet training products
Material: 80 grams
Color: White
Printing: Black
Process: Offset
Coating: None
Battery
Compartment
Launch
Pocket
Safety
Sensor in
Launch
Pocket
Motion
Sensor
Angle Knob-
(7 feet)
pull and turn
to adjust
Distance Knob:
PULL AND TURN
left (counter
clockwise)
to increase
distance.
Motion
Sensor
Blind
Zone
1'
7'
RSC Part #: 400-1988
Description: GUIDE QUICK START PTY00-14665
Created by: RWL
Initial Creation Date: 7/1/2015
Approved by: M. SWEETNAM
Date Approved: 7/31/2015
Program used: INDESIGN CC2014
Revision: 000
Revision Description: RELEASE TO PRODUCTION
Revision Date: NA
For First Time Use
If your dog seems anxious or afraid (i.e. cowers or moves away from the
launcher, barks at the launcher etc.) of the sounds the launcher makes, you'll
want to introduce it to him slowly. Grab some delicious treats and a clicker
if you have it. Start by placing the machine in the play area with it turned off.
Let your dog notice and approach the launcher by his own choice. When
your dog looks at the machine, click your clicker or say "Yes!" and give him a
treat. Do this multiple times. You should also click your clicker or say "Yes!" if
he walks towards the launcher or interacts with it.
When your dog seems comfortable around the launcher when it is turned
off, place the machine further away from him and turn it on without any balls
in it. The launcher should beep a few times. When it beeps, click or say "Yes!"
and give him a treat. Do this several times until he looks comfortable and
seems relaxed. Repeat this when he is moves closer to the launcher.
The final step is to get your dog comfortable with the unit launching the ball.
Because the launching sound can be a little loud, this might be the part your
dog is most anxious about. Keep the machine in the other room or further
away in the yard. Have someone else place the ball in the machine and when
the ball launches, click your clicker or say "Yes!" and deliver tasty treats. Do
this several times. When he is comfortable with the unit launching a ball at a
distance, bring the launcher closer to him and do this again.
When he is completely comfortable with the ball launching, you can begin
playtime with your dog and the launcher!
How to Operate
• Install 6 D alkaline batteries (not included) (1) or use the
Angle Knob:
power cord/16V-DC adapter.
PULL AND TURN
left (counter
• The distance and angle knobs will be at the lowest setting.
clockwise) for
To change the distance and/or angle, adjust paw and
higher angle.
tennis ball knobs by pulling knob out and turning.
• Paw Knob – Angle (2) – to increase the angle, pull and turn
the paw knob left.
• Tennis Ball Knob – Distance (3) - to increase the distance,
pull and turn the tennis ball knob left.
• Place tennis ball in hopper, then fetch when launched.
Return ball back to hopper to play again.
• Turn power off when not in use. Do not leave outdoors
when not in use.
Indoor and outdoor use - Play responsibly
See Operating and Training Guide for full instructions
www.petsafe.net
ECO: INITIAL RELEASE
1
2
3
