TM
Droplet
, automated LED luminaire
User manual v2.0

DECLARATION OF CONFORMITY

Manufacturer:
Xilver B.V.
Address:
Stationsstraat 44a
6247 BL Gronsveld
The Netherlands
Declares that the product
TM
Droplet
Is in compliance with the following standards:
CE-measurements in accordance with the EMC and LvD standards
EN 55103-1
Part1: Emission
EN 55103-2
Part 2: Immunity
EN 61000-4-2
ESD
EN 61000-4-3
HF immunity
EN 61000-4-4
EFT
EN 61000-4-5
Surge
EN 61000-4-6
CDN / Clamp injection
EN 61000-4-8
Power Magnetic field, extended to 10kHz
EN 61000-4-11
Dips and Voltages Fluctuations
EN 61000-4-16
Immunity to conducted common mode disturbance
EN 61000-3-2
Harmonic currents
EN 61000-3-3
Flicker
EN 60598
Electrical Safety for Luminaires
Maastricht, March 2003
Ing. R. Buskens
©2003 Xilver B.V.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any
means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of Xilver
B.V.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Xilver
B.V. is constantly striving to improve its high-quality products, the information contained in this manual is subject to
change without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, Xilver B.V.
assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the
use of the information contained in this publication.
TM
Xilver™ and Droplet
are trademarks of Xilver B.V.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Droplet and is the answer not in the manual?

Questions and answers

Summary of Contents for Xilver Droplet

  • Page 1 Xilver B.V. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because Xilver B.V. is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.

  • Page 2: Table Of Contents

    This manual will first explain you how to use the Droplet , 2.1 Configuration. In part 2.2 Functionality you can find a detailed description of all the functions. To adapt the Droplet fully to your desires we offer some accessories to extend the applicability. The place of usage, maintenance requirements and terms of warranty will be quoted in the last 3 paragraphs.

  • Page 3: Product Description

    G-clamp. Use this package always to transport the Droplet Caution: the Nut, O-ring or Bolt that will be turned to the inside of the Droplet should not be higher than 10mm (0,39 inch).
  • Page 4 Hot in HSI color mixing each fixture has 11 channels (this is also the default setting), this means each Droplet uses 11 addresses from the set start address. So the first Droplet receives address Cold in number 1, the second 12, the third 23, the fourth 34 and the fifth 45. Make sure the Droplets have...

  • Page 5: Functionality

    The speed of the pan and tilt movement can be adapted via the motor speed channel. When the Blue 0 - 255 0 - 100 Linear Blue output from 0 – 100% channel is zero (in the compact mode this channel is not available), the Droplet moves at full speed. Intensity 0 - 255 0 - 100 Linear overall output from 0 –...

  • Page 6: Accessories

    Hold for 5 seconds to reset the Droplet Lenses 0 - 255 0 - 100 Position from 0° - 360° When delivered the has a beam angle of 10°. Additional supplied with each Droplet are two lenses, Tilt 0 - 255 0 - 100 Position from 0°...

  • Page 7: Maintenance

    2.5. Maintenance 3. TERMS OF WARRANTY By ‘normal’ use of the product the manufacturer, Xilver B.V. gives 2 years of warranty. Normal use Cleaning means: The interior of the Droplet needs low or even no maintenance because the fixture is convection Use within the specifications as prescribed in paragraph 2.1.

  • Page 8: Appendices

    Voltage 100-240VAC 50-60Hz Power Max. 35W Data USITT DMX 512 Protocol XSI Xilver Serial Interface Compact HSI mode: 7 channels Compact RGB mode: 8 channels Normal HSI mode : 11 channels Normal RGB mode : 12 channels Standard beam angle 10°...
