Anatomic SITT Zitzi Wave Manual

4:1 Mounting the seating system
The seating system can easily be attached to the
mountingplate.
- Press down the "locker" and turn it to the right,
into the gap, see fig. 1.
- Push Zitzi from the front into the mountingplate.
Push until it is blocked up in the back. See fig 2
- Press down the "locker" and turn it back to its
original position, straight forward. See fig. 3
NOTE!
Turn until a "clicking sound" is heard.
Zitzi is now safely mounted in the frame.
4:2 Care instructions
Wipe it off with a damp rag or if the farme is very dirty clean the frame with some kind
carschampoo. Be careful with the electric parts and the gasspring. Make sure that all moveable
parts are complete and fixed. Change if necessary.
Clean it from dirt with a rag. Make sure that the driving wheel is put back on properly after
cleaning it.
Controll all movable parts for torn damages. Exchange if needed. If you feel insecure about
anything, you are more than welcome to contact us by calling +46 11 16 18 00 or send us an
email at info@anatomicsitt.com.
A consumed part or product should be separated by material and then thrown into a junkyard.
4:3 Marking
The frame are CE-marked and marked whith one identification number that are to be
used under all correspondence regarding this product.
4:4 Spare parts
Only spare parts delivered from Anatomic SITT AB may be used.
4:5 Warranty
1 year, manufacturing defect.
4:6 Suitable seating systems
Zitzi Delfi, Zitzi Delfi Pro & Anatomic SITS. For other combinations, contact Anatomic SITT AB.
4:7 Technical data
Weight:
14 kg
Tilt:
+20 /-30
0 0
Seat width: 40 cm
Length & width:
96 x 65 cm
Seat height:
43 cm
Max load:
65 kg
Wheels:
175 x 250 mm
8
MANUAL
Zitzi Wave
It is very important that everyone in care of
the child reads this manual.
If you need additional information you
are more than welcome to contact
Anatomic SITT AB.
Adjustment / adaptation of
Zitzi Wave must be done by
a medical / suitable person.
Table of contents
2:1 Folding and unfolding
2:2 Brakes - Rear wheels
3:1 Locking - Front wheels
3:2 Tilt
3:3 Driving bow
4:1 Mounting the seating system
4:2 Care instructions
4:3 Marking
4:4 Spare parts
4:5 Warranty
4:6 Suitable seating systems
4:7 Technical data
Art.nr. BR601-331, utgåva 1 - 2005-03-20
BR601-40, edition 1 - 2010-05-06
Sticker placement!
Tillverkare / Manufacturer
Anatomic SITT AB
Box 6137, SE-60006 Norrköping
SWEDEN - Phone +46 (0)11-16 18 00
Check the checkbox if the product
is CUSTOMIZED. The CE Mark is no
longer valid and should be removed.
