SoundGate VIDGM2V4 Instructions

Be Sure To Ask Your Autosound Specialist About
These Other Exciting SoundGate Products...
• Competition-Grade Interfaces for adding amplifiers
• Remote audio control interfaces that let you control aftermarket receivers and CD players from
your factory rear seat, or steering-wheel-mounted audio controls.
• And many others!

Why SoundGate Dealers have the edge...

The technologies used in today's vehicles are as sophisticated as any laptop computer.
At SoundGate we believe these new technologies are full of opportunities for mobile
electronic dealers across the nation. We make it a high priority to not only research
these new systems, but to understand them and their impact on the aftermarket car
audio industry. Armed with this knowledge, we are well equipped to help you integrate
new components into these systems with our innovative, high-performance interfaces
and unparalleled technical support.
Liability Disclaimer: SoundGate ® , Stillwater Designs, Inc., its subsidiaries, or Officers of the corporation
cannot be held liable for damages or injuries caused by, or resulting from the use of this instruction guide or
product.
REPAIR OR REPLACEMENT IS THE EXCLUSIVE REMEDY OF THE PURCHASER. ANY IMPLIED WARRANTY ON
THIS PRODUCT INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN
DURATION TO THE DURATION OF THE WARRANTY(please see the enclosed Limited Warranty document for
complete Warranty information). SOUNDGATE NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON
TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE AND USE OF THIS PRODUCT.
SOUNDGATE PROHIBITS ANY RETAILER FROM EXTENDING ANY WARRANTY OR WARRANTIES ON BEHALF
OF SOUNDGATE TO ANY PERSON. SOUNDGATE IS NOT RESPONSIBLE FOR ANY INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES.
Strictly adhere to all car manufacturer warnings that pertain to the disassembly, maintenance, or servicing of
the vehicle and any of its associated parts or systems.
SoundGate cannot be held responsible for discrepancies, or inconsistencies that may occur due to vehicle
manufacturing changes.
If you feel that you cannot agree with the above limitations, please return this product to the dealer you
purchased it from, or call SoundGate Customer service at 800-256-0808 for a Return Authorization number,
and return the product to SoundGate for a credit or refund.
Simple-fi
Page 1
VIDGM2V4
TM
video signals (DVD, VCR, rearview camera,
game console, etc.) to the factory navigation
systems on the touchscreen navigation
equipped General Motors vehicles listed
below.
Note: The VIDGM2V4 provides video input
only. To input audio signals, you will need an
The SoundGate VIDGM2V4 works in the following vehicles:
2003-2006 Geneal Motors Corporation vehicles, with factory
touchscreen navigation, excluding Cadillac Sedans, Chevrolet
Corvette, and Hummer H3 (for vehicles without touchscreen radio,
please see SoundGate VIDGM1).
Note:
Disassembly of factory radio is required. Installation by a Mobile Electronics
Specialist is highly recommended.
Audio input interfaces (one required if you need to input audio signals also):
SDSGM2 - Vehicles with Satellite Radio or remote-mounted CD changer
AUXGMV3 - Vehicles without Satellite Radio or remote-mounted CD changer
Copyright © 2004-2007 SoundGate ® . All Rights Reserved. SoundGate ® is a
registered trademark of Stillwater Designs, Inc. All other trademarks are the
property of their respective owners.
If you experience any problems, call SoundGate Technical Support at 800-256-0808

Purpose...

additional interface (sold separately - see
below).
The
VIDGM2V4

Features...

allows you to
The VIDGM2V4 utilizes microprocessor
add up to 2
control, ultra-reliable surface-mount
construction, and advanced firmware design,
to flawlessly match the video signal from the
new sources to the factory system. The
VIDGM2V4 is also equipped with brightness,
color, contrast, and tint adjustments to allow
you to get the best quality picture possible.
Simple-fi
www.soundgate.com
Rev 20070827
or e-mail us at sgtech@soundgate.com.
