Refraction Technology 130-01 Operation Manual

Hide thumbs Also See for 130-01:
Table of Contents

Advertisement

Quick Links

Download this manual
Refraction Technology

130-01 Operations
Startup
10/30/2008

CPU 2.9.1
This REF TEK manual provides startup and basic operating procedures for the 130‐01 and its related
family of products. Internal cable drawings are also provided along with guidelines for initial
communication and installation.
Refraction Technology, Inc.


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 130-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Refraction Technology 130-01

Summary of Contents for Refraction Technology 130-01

  • Page 1 Refraction Technology   130-01 Operations Startup 10/30/2008    CPU 2.9.1  This REF TEK manual provides startup and basic operating procedures for the 130‐01 and its related  family of products. Internal cable drawings are also provided along with guidelines for initial  communication and installation.  Refraction Technology, Inc.  ...
  • Page 2 Copyright© 2008 Refraction Technology, Inc. All rights are reserved. No part of this manual may be reproduced, copied or transmitted in any form outside the approved recipient’s organization without written permission from Refraction Technology Inc. Printed in USA. Refraction Technology...
  • Page 3 Doc-1301-Ops Rev 2.9.1 10/30/08 About this manual: This 130-01 Startup manual provides a detailed overview of the command line operations and setup of the 130-01. It covers the following broad operational topics: Overview Connections Operation with PFC Port Settings and Power Considerations...
  • Page 4 130-01 Operations Revision History: Revision Date Reason for change Pages 03/14/08 Initial release 10/26/04 Update to new format 03/01/05 Update to new A/D and Case 06/30/06 Update SM sections 01/09/07 Updated for new PFC version 04/08/08 Converted to WORD templates...
  • Page 5 PC with a Compact Flash reader or ftp into the 130 DAS, with a Compact Flash installed, in binary mode. 3. With the Compact Flash with the main.s3 image installed in the 130 DAS, issue a reset command. Refraction Technology, Inc.
  • Page 6 130-01 Operations (a) If you are at the 130 DAS: 1. Issue a Reset command from a PDA running PFC_130 or Physically disconnect and reconnect power to the unit. 2. Observe the LCD for the following messages: READING DISK DO NOT DISTURB WRITING FLASH DO NOT DISTURB 3.
  • Page 7 Kilo, KiloHertz; 103 = 1,000 M, MHz Mega, MegaHertz; 106 = 1,000,000 G, GHz Giga, GigaHertz; 109 = 1,000,000,000 Kb, KB Kilobit, KiloByte; 210 = 1,024 Mb, MB Megabit, MegaByte; 220 = 1,048,576 Gb, GB Gigabit, GigaByte; 230 = 1,073,741,824 Refraction Technology, Inc.
  • Page 8 130-01 Operations Related Manuals: 130-01/3 System Documents Number PDF file 130-01 System Startup Doc-130-Ops 130_startup_01.pdf PFC_130 Users Guide Doc-130-PFC Pfc_130.pdf Data Utilities Users Guide Doc-DataUtils 130_utilities.pdf Archive Utilities Doc-ArcUti ls arcutil.pdf 130 Theory of Operations Doc-130-Theory 130_theory. pdf 130 PFC Release Notes Doc-130-PFCRel 130_PFCRN.pdf...
  • Page 9 Once we register your contact we will only send necessary notifications via email. The same notifications will be shown on our website’s www.reftek.com/support page Thanks, Your REF TEK support team Refraction Technology, Inc.

  • Page 10: Table Of Contents

        1.12 Static sensitive device protection ..............24     2  Startup ....................25  Getting started with your 130-01 DAS ............25     Establishing Minimal Hardware Connections ........... 26     2.2.1 Install the Compact Flash ..............27  ...
  • Page 11 4.6.1 130-01 Bill of Materials ................. 72     Assembly of the 130................... 76     Sealing and pressure testing a 130-01 DAS ........... 77     Firmware update options................78     4.9.1 Download firmware from the FTP site ............78  ...
  • Page 12 130-01 Operations 4.10 To Test the 130 DAS Memory ..............81     4.10.1 Overview .................... 81     4.10.2 Memory test process ................81     5  Adding or replacing an RT527 .............. 83  Overview ....................83    ...
  • Page 13 Figure 32 Remote Access ..................50   Figure 33 Services ....................52   Figure 34 RAS started ..................... 52   Figure 35 130 Modem ..................... 53   Figure 36 PFC Control ..................... 56   Figure 37 Assign Baud .................... 56   Refraction Technology, Inc. xiii...
  • Page 14 Figure 49 Install Drive .................... 65   Figure 50 Compact Flash ..................66   Figure 51 PTO Connector ..................68   Figure 52 130-01 Boards Stack ................69   Figure 53 130-01/3 Bill Of Materials................72   Figure 54 Tighten Pattern ..................76  ...

  • Page 15: 1  Overview

    1.1 Introduction This section describes operations and maintenance requirements for the REF TEK 130-01 Broadband Seismic Recorder. It includes the following: An explanation of the general purpose of the 130 DAS units. Standard faceplate connection functions, pin-out, and associated cables drawings.
  • Page 16 130-01 Operations Refraction Technology, Inc.

  • Page 17: Specifications

    GPS Receiver/Clock plus a disciplined oscillator Accuracy with GPS: ±10 µsec after validated 3-D fix and locked Free-Running Accuracy: 0.1 ppm over the temperature range of 0º C to 60º C 0.2 ppm from -20º C to 0º C Refraction Technology, Inc.

  • Page 18: Mating Connectors

    130-01 Operations Auxiliary Channels Inputs: 3 Channels Available on each Sensor Connector Communication NET Connector: Ethernet 10-BaseT, TCP/IP, UDP/IP, FTP, RTP Serial Asynchronous RS-232, PPP, TCP/IP, UDP/IP, FTP, RTP Serial Connector: Terminal Asynchronous RS-232, 130 Command Recording Mode Continuous: Record length...

  • Page 19: Purpose Of The 130 Broadband Seismic Recorder

    10/30/08 1.4 Purpose of the 130 Broadband Seismic Recorder The REF TEK 130-01 DAS units are rugged, portable, and versatile data recorders. The modular design of their hardware and software allows you to reconfigure them for various types of applications, both short- and long- term.

  • Page 20: Standard Faceplate Connections

    Sensor cable Figure 1 130 Connectors 1.5.1 Power connector Power is supplied to the 130-01 DAS unit through one power connector. Hardware connection shows typical hardware connection for the 130-01 DAS. The following chart details individual connectors and REF TEK cable numbers.

  • Page 21: Control Connector (Serial)

    Rev 2.9.1 10/30/08 1.5.2 Control Connector (Serial) The 130-01 DAS unit's SERIAL connector provides general-purpose serial communications. Commonly, a personal computer, such as a DOS-based desktop, laptop, or PDA using REF TEK software is connected here to monitor and control 130-01 DAS operations.

  • Page 22: Net Connector

    1.5.4 Net Connector Communications between the 130-01 DAS and an external TCP/IP and/or Modem occur across the 130-01 DAS unit's NET connector. The cable (130- 8004) has two connectors to allow two connections, one for ethernet and one for serial communications.
  • Page 23 Ethernet = Transformer coupled Ethernet = Transformer coupled Ethernet = Transformer coupled Ethernet = Controlled by software and protected by self resetting fuse Volts = Tracks main input voltage VDC = Alternate main power input Tristate = Controlled by software Refraction Technology, Inc.

  • Page 24: Channel Input Connectors

    4-6) connector socket to designate the unit as only a three channel. Signals from an external sensor enter the 130-01 DAS through the channel input connector labeled CH 1 - 3. Six channel 130 DAS units (130-01/6 and 130- 02/6) use a second input connector labeled CH 4 - 6. Channel connectors also provide pins for calibration signals to be sent to a sensor.

  • Page 25: Channels 1-3 Connector Signals

    Note: 3 = Output on/off controlled by software Note: 4 = Open Collector, pulls to Ground Note: 5 = Open Collector, pulls to + 5 V Note: 6 = Functions provided by Optional RT527 Sensor Control board Refraction Technology, Inc.

  • Page 26: Channels 4-6 Connector Signals

    130-01 Operations 1.5.7 Channels 4-6 connector signals Recorder Name Electrical Voltage Note Faceplate Desc Range Connector Channels Ch4+ Channel 4 input + ±10 Volts On All Ch4– Channel 4 input – ±10 Volts models Ch5+ Channel 5 input + ±10 Volts Ch5–...

  • Page 27: General Recorder Control Considerations

    “Firmware update options”. Contact Refraction Technology to determine the applicability and advantages of such an upgrade. In addition to the CPU control code in the 130-01 DAS, the 130-01 DAS requires that you download specific parameter information to instruct it exactly how and when to record data and perform other system functions.
  • Page 28 01 DAS units do not require hardware adjustments for normal operations. You may use a 130-01 DAS unit as a stand-alone recorder, or you may use a network of many 130-01 DAS units deployed over a survey site. During field operations, the 130-01 DAS can store data either in its own internal RAM or Compact Flash.

  • Page 29: Power Considerations

    This section describes current draw, power load, and general power supply considerations for 130-01 DAS units, peripherals, and subsystems. All 130-01 DAS units operate on nominal 12-volt power (10 to 15 VDC). This range allows a 130-01 DAS unit to be powered from an ordinary lead acid battery that can be charged from either a solar or AC power source.

  • Page 30: Port Settings & Modem Communications

    1.7.1 Control (Serial) Port Each 130-01 unit provides two bi-directional, asynchronous serial ports. The first of these ports is accessible at the Serial connector on the 130-01 DAS unit's faceplate. This port has the following primary functions and characteristics:...

  • Page 31: Serial Ppp Port

    Software controlled output 1.7.3 NET Port In addition to the serial port, each 130-01 DAS provides one Ethernet port. This port, accessible at the communications Net connector on the 130-01 DAS unit's faceplate, has the following primary functions and characteristics:...

  • Page 32: Hardware Modularity

    130-01 Operations 1.8 Hardware Modularity Four boards (*) form the basic REF TEK 130-01 DAS. There are six primary boards for the 130-01. Three of the modules are available on an optional basis. The following table identifies each module. Basic...
  • Page 33 CPU PCB [130-9000] Case,Bottom Note: *130-01/3 - same as figure above without RT505-B06 A/D Note: ** Optional board Note: For some DAS units an EMI protective shield has been added to make the unit CE compliant. Care should be taken in removal when servicing the unit.

  • Page 34: Frequently Asked Questions

    For further clarification see the explanation in the section “NET Port” on page 17. 2. Question: What happens if the Flash drive is pulled from the 130-01 when the LED is RED. If the LED shows RED the drive is writing data and should not be removed until the LED changes to GREEN.
  • Page 35 (2) Serial PPP (Asynchronous, RS-232) SERIAL Connector: (3) Serial Asynchronous, RS-232 for command and control ONLY. The 130-01 DAS can be used with a spread spectrum radio by direct connection over serial PPP to the spread spectrum radio, no router required.

  • Page 36: Warranty Statement

    It is the policy of Refraction Technology to continuously upgrade its DAS software. As new software versions become available, they will be supplied to the customer at no charge for two years. After that, upgrades will be available at a nominal charge.

  • Page 37: Warranty/Non-Warranty Service

    REF TEK supplied equipment without first obtaining an RMA number. The following policy is applicable for warranty/non-warranty equipment when a problem is encountered. Contact Refraction Technology, by a means that is listed below, to obtain an RMA number. Refraction Technology, Inc. 1600 Tenth Street, Suite A...

  • Page 38: Static Sensitive Device Protection

    130-01 Operations 1.12 Static sensitive device protection WARNING: All REF TEK circuit boards are Static Sensitive and appropriate handling is required to protect each board from damage due Static discharge. 1. Please insure that when handling REF TEK circuit boards, the handler and the work bench are grounded.

  • Page 39: 2  Startup

    Refraction Technology 2 Startup This section provides information on the following topics: Getting started with the 130-01 DAS and quick power up. Minimum hardware configuration. Quick start procedures to familiarize a new user with the system. 2.1 Getting started with your 130-01 DAS...

  • Page 40: Establishing Minimal Hardware Connections

    To perform the system power-up, you need the following hardware: A 130-01 DAS. A personal computer; either a PDA, laptop, desktop, or other appropriate control interface, including a dumb terminal.

  • Page 41: Install The Compact Flash

    4. With the Compact Flash in position in the guide rails, lightly press the drive, as shown below, to lock into position. Note: The 130-01 DAS is not shipped with the Compact Flash installed. ONLY remove the Compact Flash by holding the silver tape to prevent damage to the drive.

  • Page 42: Power Up The 130-01 Das

    Reset the PDA to the PFC_130 icon by touching the Home button on the PDA. 2. Turn on the supply to apply voltage to the 130-01 Recorder and to your control interface. Note: Wait at least 20 seconds and the LCD display should display the following:...

  • Page 43: General Gps Operations

    2. Then into Push-to-fix mode (via serial commands), at which point the GPS will go to sleep. Note: The GPS is still powered from the 130-01 but is drawing < 1 mA of power. The 130-01 will stay asleep until reset by the 130-01, or until it wakes up to check ephemeris data.

  • Page 44: Using A Pda For Configuration

    4. A connect to DAS menu will display initializing the connection to the DAS. Figure 5 PFC Control 5. Tap the Status window to check the current status of the 130-01 DAS. Figure 6 PFC Status 6. Two more screens will open to verify and load status information.

  • Page 45: Check The Gps Status

    Doc-1301-Ops Rev 2.9.1 10/30/08 7. The Status screen will open to show status information for the 130-01 connection. Start ON = Acquisition start requested and acquisition is ON Acq status Start OFF = Acquisition start requested and acquisition is OFF...

  • Page 46: Figure 8 Gps Mode

    130-01 Operations To set the GPS Mode for how the GPS will be used to phase lock the internal VCXO: 3. Select one of the options, as described below, from the Mode drop-down menu. Mode Option Description Before CPU Hard coded as Cycled firmware version 2.7.3...

  • Page 47: Example Configuration Steps

    Create an example configuration having 3 channels at 100sps to one datastream using the disk as a destination for the data: 1. Create a new configuration for the 130-01 DAS starting with the New menu. Figure 9 PFC New Configuration 2.

  • Page 48: Figure 11 Pfc Channels

    7. Set the record length to be 300 seconds and leave time as default. 8. Change to the Configuration Manager menu and save the configuration. 9. Send the parameters to the 130-01 DAS by using the Send to DAS command from the Configuration Menu.

  • Page 49: Format The Compact Flash

    Control menu. 5. Confirm the format by selecting the OK button. 6. When the format is complete the submenu displays Completed or Error. 7. Select the Done button to return to the Status menu. Refraction Technology, Inc.

  • Page 50: Start Acquisition

    130-01 Operations 2.6.3 Start Acquisition 1. Check that the GPS has locked or the 130-01 DAS has the correct time. 2. Turn on acquisition by tapping Start Acq next to the acquisition line on the PFC Status menu. 3. If a delay is desired enter a delay time or approve with the OK button.

  • Page 51: Write Parameters To Disk (Wp)

    3. Select the OK button to approve the write operation. Note: It is also possible to Write or Load a parameter file during the DAS configuration operations by using the DAS LP/WP command on the configuration menu. Refraction Technology, Inc.

  • Page 52: Load Parameters From Das Disk

    130-01 Operations 2.6.5 Load Parameters from DAS Disk The Load Parameter (LP) command causes the DAS to look for a file named 130 (UNIT_ID.CFG) on the disk and load the first one it finds. If this file is not found then the DAS will search for a file named 130_0000.CFG.

  • Page 53: Examples Of 130 Lcd Displays

    Actual State C = Continuous L = Level I = Time Interval E = Event T = Time List K = Cross ---- Inactive Event Count Stream Indicato X = External V = Vote else trigger type Refraction Technology, Inc.

  • Page 55: 3  Serial Ppp Communication

    Modem PPP connection over a serial link with the 130 DAS Modem or by using the Modem connector on the 130-SM. An optional external modem can also be used with the 130 NET connector for serial communication. Refraction Technology, Inc. 41 ...

  • Page 56: Direct Ppp Connection

    130-01 Operations 3.2 Direct PPP Connection 3.2.1 PC Setup Information File (Generic Null Modem.inf) REF TEK has supplied a modem information file (Generic Null Modem) that is located in the C:\reftek directory. This file must be resident on the local drive, however, there is no reason to access or make changes to it.

  • Page 57: Figure 19 Have Disk - Modem

    7. At the Install From Disk window in the Copy Manufacturer’s files from: text box type C:\reftek 8. Click OK when ready. 9. At the Install New Modem window under Models select Generic NULL Modem. 10. Click Next> when ready. Figure 20 Select Generic Refraction Technology, Inc.

  • Page 58: Figure 21 Select Port

    130-01 Operations 11. At the next Install New Modem window select an available port to use for the modem 12. Click Next> when ready. Figure 21 Select Port Note: If the “Digital Signature Not Found” warning appears, select the Yes button and proceed.

  • Page 59: Figure 24 Modem Properties

    17. Click OK when ready. Figure 24 Modem Properties 18. In the Phone and Modems Options window click the OK button. 19. At this point the PC needs to be restarted. Using standard operations restart the Refraction Technology, Inc.

  • Page 60: Adding Remote Access Services (Ras)

    130-01 Operations 3.2.2 Adding Remote Access Services (RAS) Configure the Remote Access Services (RAS): 1. Using standard window operations click Start —> Settings —> Control Panel. 2. Double-click the Dial-up Connection Icon. Network and Dial-up Connection Figure 25 Control Panel Note: Windows XP uses a “New Connection”...

  • Page 61: Figure 27 Incoming Connect

    Rev 2.9.1 10/30/08 4. Select the Next option screen. 5. Select Accept incoming connections and the Next button. 6. Check the Generic Null Modem option. 7. Click the Next button when ready to continue. Figure 27 Incoming Connect Refraction Technology, Inc.

  • Page 62: Figure 28 Allow Incoming Virtual

    130-01 Operations 8. Select the Allow option on the Incoming Virtual Connection window. 9. Click the Next button. Figure 28 Allow Incoming Virtual 10. Select the Add button to add a new DAS connection. Figure 29 Add DAS User Note: When a DAS unit is setup and is connected to a PC, an account must be created and added.

  • Page 63: Figure 30 Add User

    13. For the Password: setting you must use the Username (i.e., das#9066). 14. Next Confirm Password by re-typing the password. Note: The Password: settings are case sensitive. 15. Select the OK button to create the new user. Figure 30 Add User 16. Select the Next button. Refraction Technology, Inc.

  • Page 64: Figure 31 Networking

    130-01 Operations 17. In the Network Components window, under the components, highlight Internet Protocol (TCP/IP). 18. Select the Properties button. Figure 31 Networking 19. On the Incoming TCP/IP Properties, enable Allow callers to access my local area network. Figure 32 Remote Access 20.

  • Page 65: Start Remote Access Service (Ras)

    Component Services. A shortcut to the control program has also been placed at Start -> Programs -> Refraction Technology -> RTP Services -> Services. The shortcut can be copied to the windows desktop by dragging it to the desktop while holding down the CTRL key.

  • Page 66: Figure 33 Services

    130-01 Operations To start RAS perform the following steps: 1. Start the Services control program. 2. Double-click the Services icon to open the windows services process window. Start icon Figure 33 Services 3. Highlight and select the Routing and Remote Access service.

  • Page 67: Modem Ppp Connection

    This Section explains the REF TEK 130-Modem when it is used with the REF TEK 130 family. The 130-Modem is an optional external modem. A user should be familiar with whatever REF TEK host system is in current use. Documents for other REF TEK products are available on request. Refraction Technology, Inc.

  • Page 68: Setting Up The 130 To Use The 130-Modem

    130-01 Operations 3.3.3 Setting up the 130 to use the 130-Modem 1. Connect the 130-Modem to the 130 DAS unit NET connector, using the standard REF TEK 130-8154 cable supplied with the 130-Modem unit, this cable is also available separately (see drawing).

  • Page 69: Slm Modem Module

    It is a single design that includes a DSP data pump, a modem controller, on-chip RAM and ROM, an analog front end (AFE) a DAA, and analog output. Note: The 130-8137 modem cable is used with the 130-01 when supplied with an internal modem. 3.4.1 Modem features The SLM2456 accepts standard modem AT commands and provides connect rates up to 56/33.6/14.4 kbps full-duplex over the Public Switched...

  • Page 70: Modem Configuration

    130-01 Operations 3.5 Modem configuration Note: The internal modem (used on the 130-SM) requires the jumper installed on the RT530 lid board to assign the serial PPP port to the internal modem and therefore disable the serial PPP port coming out of the NEt connector.

  • Page 71: Figure 39 Modem Setup

    Note: Type the init string exactly as shown above. The init string is the ONLY string that works. It is sent to the modem on both boot up of the 130-01 and/or if sent from the above window using the Send button.

  • Page 72: Data Transfer Through Ppp Real-Time

    130-01 Operations 3. Tap the Send button to send the modem parameters to the DAS. 4. Tap the Done button to return to the Connection setup menu. Send Figure 40 Send 3.5.2 Data transfer through PPP real-time If you want data to be transferred real-time through PPP then it must be marked in the data stream parameters and the RTPD host IP entered in the PPP menu.

  • Page 73: Pc Communication Setup

    3.6 PC Communication Setup 3.6.1 130 DAS modem communication Note: The modem at the 130-01 DAS end of the line should be pre-configured to automatically answer before trying to dial to the DAS. The following steps are an example of the steps necessary to configure the 130-01 DAS modem to automatically answer.

  • Page 74: Install Modem

    3.6.2 Install modem Note: This section only applies if a modem has not already been installed on the This section describes requirements for dialup into a 130-01 Recorder on a computer running Windows 2000. 1. Connect the modem to an open COM port of the PC.

  • Page 75: Figure 43 Modem Option

    5. Select the Add option to detect and install a modem. Figure 43 Modem Option 6. The Install New Modem window opens and installs. Figure 44 Detect Modem 7. Select the Finish button to accept the new device and finish the installation. Figure 45 Installed Modem Refraction Technology, Inc.

  • Page 76: Figure 46 New Modem

    130-01 Operations 8. The Phone and Modem Options window displays to show the new modem. Figure 46 New Modem 9. Highlight the new modem. 10. Select the Properties button to set the baud rate for the modem. 11. Set the Baud rate from the drop-down menu and Select the OK button.

  • Page 77: 4  Periodic Maintenance Operations

    Refraction Technology 4 Periodic Maintenance Operations 4.1 Introduction This section provides maintenance information for the 130-01/3 and 130- 01/6 on the following topics: Replacing the Compact Flash Connector Assembly & Maintenance Periodic Maintenance checks Replace CPU Battery (130-01/3 and 130-01/6)

  • Page 78: Replacing The Compact Flash

    4.2 Replacing the Compact Flash If the Compact Flash needs to be changed do the following 1. Remove the cap off the 130-01 DAS. 2. If the LED, in the disk well assembly next to where the Compact Flash is installed, shows “Green”, it can be replaced with an empty formatted drive.

  • Page 79: Figure 48 Handle Drive

    5. Install a newly formatted drive in either slot by holding (ONLY) onto the sides of the Compact Flash and inserting into the well or reader. Figure 49 Install Drive 6. The LED, for the well slot, should turn “Green”. Refraction Technology, Inc.

  • Page 80: Figure 50 Compact Flash

    Due to the large variability of CF cards available on the world market and the resulting problems with compatibility due to memory layout, signal structuring and power requirements, Refraction Technology cannot guarantee a CF card will work in a REF TEK data recorder unless it is sold through REF TEK itself. REF TEK ensures compatibility through communications with CF manufacturers and rigorous in-house testing.

  • Page 81: Connector Assembly & Maintenance

    DAS units are constructed of an alloy, excessive force on the locking groove can cause burrs which make subsequent installation and removal of the connectors more difficult. 4. Do not attempt to remove a plug with pliers. 5. Assemble new connectors correctly as shown below. Refraction Technology, Inc.

  • Page 82: Figure 51 Pto Connector

    130-01 Operations Figure 51 PTO Connector Refraction Technology, Inc.

  • Page 83: Periodic Maintenance Checks

    Note: For some DAS units an EMI protective shield has been added to make the unit CE compliant. Care should be taken in removal when servicing the unit. Note: ** Optional board Note: RT505-B06 A/D PCB is for 130-01/6 and 130-02/6 6 Channel 130 DAS units. Refraction Technology, Inc.

  • Page 84: Replace Cpu Battery (130-01/3 And 130-01/6)

    2.2 volts for the battery it should be replaced. Refer to Figure 52 on page 69 1. The power to the 130-01 may be left on so data in memory will not be lost. 2. Remove the cap (130-9002) (Item 19) from the well disk enclosure (Item 3).

  • Page 85: Disassembly Of The 130 For Service

    2. Check and make sure the cap (130-9002) is installed on the well disk enclosure (Item 3). 3. Flip the 130-01 DAS upside-down on the top of the top case (Item 1). 4. Unbolt the bottom base case (Item 15) of the recorder by removal of twelve #8- 32x5/8 screws (Items 16) and the twelve #8 lock nuts (Item 17).

  • Page 86: Bill Of Materials

    130-01 Operations 4.6.1 130-01 Bill of Materials Figure 53 130-01/3 Bill Of Materials Refraction Technology, Inc.
  • Page 87 Doc-1301-Ops Rev 2.9.1 10/30/08 Refraction Technology, Inc.
  • Page 88 130-01 Operations Refraction Technology, Inc.
  • Page 89 Doc-1301-Ops Rev 2.9.1 10/30/08 Refraction Technology, Inc.

  • Page 90: Assembly Of The 130

    8. Bolt the two halves of the 130-01 DAS together using twelve #8-21x5/8 SS screws (Item 16) and #8 lock nuts (Item 17). 9. Seal and pressure test the 130-01 DAS. Refer to Step 7 on “Sealing and pressure testing a 130-01 DAS”.

  • Page 91: Sealing And Pressure Testing A 130-01 Das

    6. Carefully lower the recorder bottom base case (Item 25) onto the top case assembly half of the 130-01. Observe the O-ring and check that the corners do not get caught and displaced or gouged as the unit is seated on the top.

  • Page 92: Firmware Update Options

    3. Download the zip file of the most recently released firmware version. 4.9.2 Firmware update process Updating firmware in a 130-01 requires the presence of a firmware file on an installed Compact Flash device. 1. On power-up, the 130-01 checks the Compact Flash for the presence of ‘main.s3’...

  • Page 93: Updating Firmware Using Ftp

    4. Use the put ftp command to send the file (main.s3) to the Compact Flash™ installed on the 130-01. 5. With the Compact Flash™ with the main.s3 image installed in the 130-01 DAS, issue a reset command from the 130-01...

  • Page 94: Updating Firmware Via Telemetry Mode

    130-01 Operations 4.9.6 Updating firmware via telemetry mode 1. If you are connecting remotely by a TCP connection: First connect Discover the unit Acquire status 2. Issue a reset command from the Status screen. 3. Delete the unit from the Station List screen:...

  • Page 95: To Test The 130 Das Memory

    This Section explains the how the Memory Test (MT) command is handled in the REF TEK 130-01 DAS. 4.10.2 Memory test process The Memory Test Command causes the REF TEK 130-01 to perform a memory test on data and buffer memory. Since the test overwrites any existing data, the DAS performs several actions prior to starting the actual test.

  • Page 97: 5  Adding Or Replacing An Rt527

    Control board (RT527) in the 130 DAS family systems. Refer to the RT527 board technical reference information for the RT527. Note: Please read all instructions carefully before proceeding. If you have any questions please call or E-mail REF TEK. Figure 55 RT527 SCB Refraction Technology, Inc. 83 ...

  • Page 98: Installation

    5.2 Installation To install the RT527 in the 130-01 DAS follow these steps: 1. Upgrade the 130-01 to a minimum firmware version of 2.1.0 or later (see the “Update Firmware” section (Page 78) in the System Operations Manual). 2. Power off the 130-01.

  • Page 99: Figure 57 Remove 130 Top

    8. Loosen and remove the six #6-32 screws (Item 12) or (Item 13) from the stack. Figure 58 Stack Screws 9. Retain the lock washers (Item 21 on Figure 52) with the screws so they do not get misplaced. Refraction Technology, Inc.

  • Page 100: Upgrade

    130-01 Operations For a new installation of the RT527 go to Step 12. If an upgrade of an RT527 go to Step 10. 5.2.1 Upgrade 10. If an upgrade or replacement of the RT527 (Item 9 on Figure 59 on page 87) is desired, gently lift and remove the old sensor control board (RT527) (Item 9).

  • Page 101: Figure 60 130-Exploded View

    RT505-B06 (Ch4-6) A/D PCB RT506-B01 [130-9004] CPU PCB O -ri ng RT527-B 01** Sensor PCB Internal lock w asher #6-32x1-5/8 screw [130-9000] 13 # 6-32x3-1/8 screw * #8 Lock Nut Figure 60 130-Exploded View Figure 61 Bolt Pattern Refraction Technology, Inc.

  • Page 102: Rt527 Scope

    For more information on sensor control see Section 8 in the 130 Theory of Operations. 5.3.1 Channel Connector Signals Each channel connector of the REF TEK 130-01 has the following pin-out: Name Direction...

  • Page 103: Sensor Test Signals

    Doc-1301-Ops Rev 2.9.1 10/30/08 5.3.2 Sensor Test Signals Sensors vary in the number and type of signals they support. The following table shows some common sensors used with the Ref Tek 130-01: Sensor Mass Center CalSig CalEn Notes Outputs Inputs...
  • Page 104 130-01 Operations Pseudo-code (some error and border conditions not covered): count limit = ((Time * 3600) / Rate) if (Attempts == 0) Attempts = 1 retry = Attempts ...… if (Rate seconds has passed) if (reading < Level) if (counter > 0) counter = counter - 1 else /* reading >= Level */...

  • Page 105: 6  Logfile Example

    018:09:06:44 INTERNAL CLOCK TIME JERK # 1 OCCURRED AT 09:06:44.553 The DAS internal clock was changed according to the 130-GPS time pulse, 1 PPS. It will be only correct to the next 1 Hz pulse and therefore no more than a 1 second correction occurred. Refraction Technology, Inc. 91 ...
  • Page 106 130-01 Operations 018:09:06:44 DSP CLOCK SET: OLD=04:018:09:06:44.553, NEW=04:018:09:06:44.000 The DAS internal clock change message that tells the operator: Time the internal clock was changed (DSP) Time the internal clock was at the time of the change Time it was changed to (The first change is always less than a second to line the internal 1 Hz to the 1 Hz of the 130-GPS.)
  • Page 107 The DAS internal clock or 1 Hz is compared to the 130-GPS 1 Hz periodically and the difference is noted. In this case: 223 mS 357:09:44:53 GPS: POSITION: N23:18:20.04 E101:23:29.58 +01610M The DAS prints the 130-GPS position information given by this 130-GPS after lock. Refraction Technology, Inc.
  • Page 108 130-01 Operations 305:02:37:56 SIRF: JERK The DAS compares the 130-GPS time to its internal oscillator time at the first GPS lock since 130 power-up or reset. If a change is required to equal the 130-GPS time, enables the timing algorithm that makes the change, Time Jerk. It gives the time it was enabled and will jerk the DAS internal clock with the next IPPS or 1 Hz rise from the 130-GPS.

  • Page 109: System Information

    Reports the DAS RTPD or Host address from network parameters. Ethernet is reported first and Serial PPP second. 018:08:58:54 Gate: 194.226.112.125 192.168.1.10 Reports the DAS Gateway from network parameters. Ethernet is reported first and Serial PPP second. Refraction Technology, Inc.
  • Page 110 130-01 Operations 018:08:58:54 Channel:Offset 1:$0001DE8A 2:$0001DFF7 3:$0001DDDD Reports the DAS A/D offset in hex counts for channels 1 - 3. This offset is user selectable. It is factory set for a terminated input to center around zero counts. RT505 A/D inherent offset is approximately 123,000 decimal counts.
  • Page 111 018:09:06:45 ATD: BI 12 BO 11 BF 0800 BW 0 IS 0 IE 1 IC 0 Ib 3:3 This message ties in with the ATD Interrupt Error above dumping the contents of some system buffers. This is for REF TEK DEBUG ONLY! and should not concern the operator. Refraction Technology, Inc.

  • Page 112: Acquisition Information

    130-01 Operations 6.3 Acquisition Information 017:10:38:08 PARAMETERS ERASED Indicates the existing parameter set in the DAS has been erased. This is done before another parameter set is loaded. 017:10:38:08 PC1 Indicates the parameters for Channel 1 were received by the DAS.
  • Page 113 018:09:08:05 ACQUISITION STOP REQUESTED Indicates the user requested acquisition to stop through an external user command. 018:09:08:05 ACQUISITION STOPPED Reports the DAS has successfully stopped ACQ after instruction or due to data memory being full. Refraction Technology, Inc.

  • Page 114: Disk Access Information

    130-01 Operations 6.4 Disk Access Information 301:09:14:20 AUTO DUMP CALLED Indicates that RAM has reached the operator specified used amount and the DAS enables the RAM to Disk transfer. 357:10:55:02 IDE device: IBM-DSCM-11000 S/N: KHLZ9250 fw: SC2IC915 Specifies the disk device the RAM will be dumped to.
