Serial RS232 / RS485 Ethernet Converter Manual – US2000A

WWW.USCONVERTERS.COM

BIT COMMANDER

Serial RS232 / RS485 to Ethernet Converter

(Part US2000A)

Copyrights © U.S. Converters

Table of Contents

Need help?

Do you have a question about the BIT COMMANDER US2000A and is the answer not in the manual?

Questions and answers

Summary of Contents for U.S. Converters BIT COMMANDER US2000A

Page 2: Table Of Contents
Send reset (RST) command over Ethernet ..............14 Firmware update ......................15 Default Screenshots ......................17 FAQ ............................ 23 Default parameters: IP address: 192.168.0.7 Subnet mask: 255.255.255.0 The default gateway: 192.168.0.1 User name: admin Password: admin Copyrights © U.S. Converters...
Page 3: Overview And Features
15. Support IP and domain name at the same time 16. Supports up to 8 clients per port in TCP mode. 17. Built in Keep alive function. 18. TCP Server mode supports transparent and ‘ID’ communication modes. Copyrights © U.S. Converters...
Page 4 Fire and Security Panels  Vending Machines  Point of Sale Terminals  Remote equipment management  IT management services  Access Control  Industrial Control  Home Automation  Instrumentation  Building Control  Power Management Copyrights © U.S. Converters...
Page 5: Functions
This means that we can GET data from HTTP client’s request. Open the following URL to see the data: www.usconverters.com/1.php?data=12345 The web page is shown below, we can see that the web server have received the data (12345). Diagram 2-1 Request www.usconverters.com/1.php? and upload data Copyrights © U.S. Converters...
Page 6: Tcp Auto Mode
1. Receive window show data only when “Read” button is clicked or when selecting the “Auto read” checkmark. 2. Regardless if WEB to Serial mode is selected or not, the send web data to serial screen is always active. Copyrights © U.S. Converters...
Page 7: Hardware
In RJ45 port, bright after network connection Data (yellow) In RJ45 port, flash if there are data on network RS232 interface Standard DB9 male connector: Number RS232 Description Receive Transmit Signal ground Request to send Clear to send Copyrights © U.S. Converters...
Page 8: Rs485 Interface
The Ethernet port supports 10 M / 100 M adaptive, AUTO MDI/MDIX, will work with standard straight through and cross-over Ethernet cables. Name Description Transceiver Data+ Transceiver Data- Receive Data+ Not connected Not connected Receive Data- Not connected Not connected Copyrights © U.S. Converters...
Page 9: Reset
Simply use a web browser and login to the converter at IP address 192.168.0.7. Serial port Power on the converter and press the reset button. The converter will now go into configuration mode. The default port parameters are: 9600, 8, N, 1, Copyrights © U.S. Converters...
Page 10 Total cmd：55 BA C9 00 A8 C0 2A 20 07 00 A8 C0 8C 4E C9 00 A8 C0 01 00 C2 01 03 00 00 00 00 FF FF FF B9 Example: 55 BA for writing to Port 0，55 BC for reading port 0 55 C1 for writing to Port 1，55 C3 for reading port 1 Copyrights © U.S. Converters...
Page 11: Configuration Software
(5) Click ‘Save Config’ and the new parameters will take effect. Notice: After modifying the parameters, first click ‘Base Save’ or ‘Save COM(0)’, then click ‘Save Config’. If not, the parameters will only be saved, but not take effect. Copyrights © U.S. Converters...
Page 12: Other Functions And Features
Enter the new address with ‘-’ between each byte, (it will also work with just a ‘space’ between each byte). Click ‘Update Settings’ to save the new address, and reset the converter for the changes to take effect. Copyrights © U.S. Converters...
Page 13: Telnet Timeout
When TCP Server mode is selected, the converter will disconnect with from the client, release the resources, wait for a new connection and clear the time out count. When TCP Client mode is selected, the converter will disconnect from the server and reconnect. Telnet timeout represent no signal reconnect timeout. Copyrights © U.S. Converters...
Page 14: Send Reset (Rst) Command Over Ethernet
61 64 6D 69 6E 00 61 64 6D 69 6E 00 Converter will respond (4 Byte): FF 01 02 4B (command success) 4B = 'K'; FF 01 02 45 (user name and password false) 45 ＝ 'E'. Copyrights © U.S. Converters...
Page 15: Firmware Update
Firmware updates can be made by using the configuration software. Updates can only be done by connecting directly to the converter, not over a network. 1. Click search and select the converter: 2. ‘Device’ -> firmware update Copyrights © U.S. Converters...
Page 16 Click “Program” to start the update progress. 3. Update success, click exit. Notice: If the configuration software cannot find the converter after the firmware update, please reset the converter to factory defaults and click search again. Copyrights © U.S. Converters...
Page 23: Faq
Solution: Reset the converter back to factory settings. Problem: When the connection is established, the converter receives several random characters. Possible causes. Telnet Protocol is set to use “Telnet” instead of “RAW”. Module ID type is not set to “0”. Copyrights © U.S. Converters...
Page 24 Possible cause. Telnet Timeout timer is set to a value higher than ‘0’. Solution. Set Telnet Timeout to ‘0’ or send data before timeout. To access technical support, please visit the U.S. Converters website at: www.USconverters.com Here you will find:...
