Phase 1 Components ACTIV-1 Installation Guide 1. Components layout Hardware center left right stretcher bar unit M5 X 4 M5 X 6 M5 X 12 aluminum connecting rod x 1 (comes mounted in connecting rod) allen keys screws steel drive rod x 2 (long & short)
Page 3
Phase 2 Stretcher Bar Unit Assembly ACTIV-1 Installation Guide 2. Stretcher bar unit assembly Assemble center stretcher bar in the middle. Adjust stretcher bar to desired length and tighten with six M5 screws Assemble center, left and right stretcher bar Preset stretcher bar to desired length and tighten with six M5 screws.
Page 4
M5 screws Phase 3 Motor Assembly ACTIV-1 Installation Guide Mount motor unit on stretcher bar using three M5 screws. Please contact cc@amqsolutions.com if you are missing any parts, have difficulty with assembly, or have any product related questions.
Page 5
Attach both leg columns to the stretcher bar ends using twelve M5 screws Phase 4 Leg Column Assembly ACTIV-1 Installation Guide Attach both leg columns to the stretcher bar ends using M5 screws. Make sure that the rod opening side of the leg columns are facing toward each other.
Phase 5 Feet Assembly ACTIV-1 Installation Guide 5. Feet assembly Attach both feet using M5 screws. Attach both feet using twelve M5 screws Please contact cc@amqsolutions.com if you are missing any parts, have difficulty with assembly, or have any product related questions.
Page 7
Phase 6 Drive Rods Assembly 5. Drive rods assembly ACTIV-1 Installation Guide Insert short drive rod through the motor unit and into the right leg column Insert short drive rod through the motor unit and into the right leg column.
Page 8
7. Cantilever assembly Phase 7 Cantilever Assembly ACTIV-1 Installation Guide Attach cantilever to the leg columns Use M5 screws to fasten in place Attach cantilever to the leg columns. Use M5 screws to fasten in place. Please contact cc@amqsolutions.com if you are missing any parts, have difficulty with assembly, or have any product related questions.
Page 9
8. Connecting control and power Phase 8 Connecting Control and Power ACTIV-1 Installation Guide Connect power plug after the handset are connected properly Facing Orient yourself to the table Direction assembly by facing as a user Handset to identify left and right motor.
Page 10
Phase 9 Program Height Memory Presets ACTIV-1 Installation Guide To Program Up to 3 Presets: Use the up/ down arrows to find desired height, then press “M” followed by the number 1, 2, or 3. To Test Programmed Height: Use the up/ down arrows to adjust the table to a height other than the preset height.
Page 11
