ABOUT THESE OPERATING INSTRUCTIONS This User Manual is for the NC-iQ (DD1 1 101) and its accessories. It contains important in- formation to put the device into operation, to use and maintain it safely and pursuant to its intended use. -
Page 7: Important Safety Notes
Utilise the device, its accessories and all connection cables only in technically perfect condition. Only use original NOUVEAU CONTOUR needle modules, accessories and spare parts. Product-specific safety instructions Never modify the device, the needle modules or other accessories. -
Page 8: Important Hygiene And Safety Regulations
"Cleaning surfaces“ on page 28 for regular disinfection and 7.2 "Material compatibili- ties“ on page 28, and the “Product-specific safety instructions" on page 7. Should you be using a local anaesthetic, this product must be thoroughly removed before the treatment. NC iQ... -
Page 9: Contraindications
Acute inflammation of the conjunctiva (contraindicated when pigmenting eye-liner) All types of scars Skin areas after plastic surgery performed less than twelve months ago Skin areas after filler or laser IPL treatments performed less than six months ago NC iQ... -
Page 10: Side Effects
Formation of herpes simplex virus type I (HSV-I) blisters in cases of previously untreated infections. Furthermore, the following problems may arise after micro-pigmentation: Colour differences Pigment loss Freshly treated skin areas should generally be protected against UV radiation and from direct sunlight. NC iQ... -
Page 11: Required Qualifications (User Requirements)
Proper use also includes these operating instructions and especially the chapter “Important Safety Notes" being fully read and understood. Intended use includes only the following groups of consumers: Adult men and women at least 18 years of age who are in a good state of health. NC iQ... -
Page 12: Symbols Displayed On The Product
Housing provides protection against foreign objects thicker than 1 mm. Applied part Type B: Applied part offers safety against electric shock and leakage. Handpiece Foot-operated switch DC power connector/inner pin positive DC current AC current Observe manual! Manufacturer Date of manufacture NC iQ... - Page 13 Catalogue number, order number Serial number Lot code Sterilised with ethylene oxide Use by Caution! Temperature limit Humidity limit Keep dry For indoor use only Fragile Do not use if packaging is damaged! Not available for re-use Do not resterilise NC iQ...
- Page 14 Energy Efficiency Level VI Device complies with Japanese VCCI Standards CHINA SJ/T 1 1364-2014 Distinctive component for Canada and US Double insulation/Protection category II device GHOST-R mark for Russia Device meets the requirements of RoHS 2 SIQ MArk License EN60601-1 NC iQ...
-
Page 15: Scope Of Delivery
1 Warranty declaration The hygiene sheaths (25500) needed for practising the procedures are not included in the supply. The accessories to match your handpiece are available at your respective authorised dealer, see “Accessories and spare parts” on page 16. NC iQ... -
Page 16: Product Information
1 1215 (5 pont Shader Safety Needle) 15 pcs Hygiene sheath for hand- 25500 piece Foot-operated switch 10860 1 pcs SCOPE QTY./PACK- SPARE PART ARTICLE NUMBER OF DE- ING UNIT LIVERY Control unit 10100 1 pcs Handpiece 10120 1 pcs NC iQ... -
Page 17: Operation
Never bend the product cables. CAUTION Risk of tripping due to cable Inappropriately routed cables can present a tripping risk and cause injuries. Install all cables in such a way that no one will trip over or accidentally pull them. NC iQ... -
Page 18: Setting Up The Control Unit
Pull and hold back the holding bracket for the adapter and simultaneously lift out the country-specific adapter from the cavity in the power supply plug. Fig. 1: Remove the country-specific adapter How to insert the desired country-specific adapters: Insert the country-specific adapter into the power supply plug recess as shown below. NC iQ... -
Page 19: Connect The Foot-Operated Switch (Optional)
Connect the foot-operated switch (optional) Insert the RCA plug of the foot-operated switch into the foot switch socket ( ) on the back of the control unit. Only the foot-operated switch authorised as an accessory in 4.3 can ensure safe operation! NC iQ... -
Page 20: Connecting The Handpiece
Never soak the handpiece, control unit or the power supply plug in cleaning or disin- fectant agents. Never clean the handpiece, the control unit or the power supply plug in an autoclave or an ultrasonic bath. NC iQ... -
Page 21: Inserting Or Replacing The Needle Module
Always place the handpiece on the handpiece rest, so that the needle module does not touch the surface. Should you incur an injury from a contaminated needle, make sure to seek the help of a physician! Turn off the handpiece. NC iQ... -
Page 22: Fitting The Hygiene Sheath
20 to 27 mm. That corresponds to a sheath width of approx. 30 to 45 mm. Proper application of the hygiene sheath: Slide the hygiene sheath completely over the connection cable and the handpiece. NC iQ... -
Page 23: Fill The Needle Module
Inject the desired companion product with a suitable applicator that guarantees sterility, through the fill opening (1) into the needle module. Please note the fill capacity of the needle modules of approximately 1 ml. Fig. 7: Filling the needle module NC iQ... -
Page 24: Checking The Equipment
A preset can be selected at any time. A change in frequency can be made via the button Frequency up ( ) and the button Fre- quency down ( ) in increments of 10 The frequency buttons light up briefly when pressed. NC iQ... -
Page 25: Selecting The Projection Position Of The Needle
Select the needle protrusion depending on your customer’s skin texture in the area of the procedure. Switch the control unit into operating mode. Adjust the needle position by twisting the flexible part of the handpiece (1). Fig. 8: Adjusting the needle projection NC iQ... -
Page 26: Selecting The Puncture Frequency
The current operational mode of the handpiece is displayed on the control unit with a symbol next to the frequency. If the connected handpiece does not start: Please refer to chapter 10 "In the event of questions and problems“ on page 30. NC iQ... -
Page 27: Cleaning And Maintenance
"Material compatibilities“ on page 28). Inspection An inspection may only be carried out by an authorised dealer. We recommend to drop off the device at an authorised service dealer at regular 24 month intervals for an inspection according to the manufacturer's specifications. NC iQ... -
Page 28: Material Compatibilities
Disinfect the connection cables, the handpiece and the handpiece rest as described in 5.5 "Cleaning and disinfecting the equipment“ on page 20 chapter. Cleaning surfaces For contaminants on the outside: Wipe the device and its accessories with a soft cloth, moistened with cleaning solution or disinfectant. NC iQ... -
Page 29: Transport And Storage Requirements
If the product and its accessories are still in service after the projected product life cycle has expired, you may run the risk of increased wear and tear or failure of individual functions. Fault-free operation can then no longer be guaranteed. NC iQ... -
Page 30: In The Event Of Questions And Problems
(see not switch been discon- connected. chapter 5.2 "Connecting the hand- into standby nected. piece“ on page 18). mode. E Check the mains power supply to the workstation. NC iQ... -
Page 31: Warranty Declaration
Damage and consequential damage caused by the improper use or non-compliance with the operating instructions. Any damage caused by ingress of liquids or debris into the inside of the handpiece, the control unit or the power supply plug NC iQ... -
Page 32: Declaration Of Conformity
DECLARATION OF CONFORMITY The Manufacturer: MT.DE R M GmbH Gustav-Krone-Str. 3 D-14167 Berlin declares under sole responsibility that the following product: Name of the Product: Nouveau Contour IQ Article No.: DD11101 comply with the provisions of the following directives: EMC-Directive: 2014/30/EU... -
Page 33: Notes
NOTES NC iQ... - Page 34 NC iQ...
- Page 35 NC iQ...
- Page 36 Manufactured by: MT.Derm GmbH | Gustav-Krone-Str. 3 | 14167 Berlin...
