OPERATION AND MAINTENANCE
mod. WILLY - GALAXY - SPLASH
EUROGAMES S.r.l. - Ed. 12/2012 - All rights reserved
©
No part of this document can be reproduced or transmitted to third parties by any means or in any form (either electronic or mechanical,
including photocopying, recording or data saving) for purposes other than the personal use without prior written authorisation of
EuroGames S.r.l.
Via degli scavi, 41 - 47122 Forlì (ITALY)
Tel. +39 0543 796665 Fax. +39 0543 722727
www.eurogames.it - info@eurogames.it
HANDBOOK
BUMPER BOAT
"
"
GB
Advertisement
Table of Contents
Related Manuals for EuroGames BUMPER BOAT Series
Summary of Contents for EuroGames BUMPER BOAT Series
- Page 1 " mod. WILLY - GALAXY - SPLASH EUROGAMES S.r.l. - Ed. 12/2012 - All rights reserved © No part of this document can be reproduced or transmitted to third parties by any means or in any form (either electronic or mechanical, including photocopying, recording or data saving) for purposes other than the personal use without prior written authorisation of EuroGames S.r.l.
-
Page 2: Table Of Contents
BUMPER BOAT CONTENTS Page GENERAL INFORMATION ..................3 GENERAL SAFETY PRECAUTIONS ................3 DESCRIPTION OF THE MACHINE ................4 TECHNICAL FEATURES .....................5 Technical data.......................5 Standard equipment .....................5 Adjustable parameters....................5 Characteristic parameters ....................6 MANUFACTURER .......................6 CONFORMITY ......................6 IDENTIFICATION ......................6 FUNCTIONING ......................7 Preliminary operations ....................7 Setting the game time....................8 Setting the sound volume .....................8 Selecting the sound effects ..................9... -
Page 3: General Information
Draws the attention to important general messages which affect neither safety nor the machine effi ciency. If, after the reading, you are unsure about anything, contact EuroGames who will assure you a prompt and careful assistance to get the best performance and highest effi ciency from your machine. -
Page 4: Description Of The Machine
For this reason, any information of this manual might not match the technical features of the product completely. EuroGames does not incur in any obligation as far as updatings are concerned which will be included in future printings of this manual. -
Page 5: Technical Features
TECHNICAL FEATURES The automatic games of the “BUMPER BOAT” series have been designed and manufactured by EuroGames according to the most advanced technologies, and using a strong fi berglass reinforced structure which insulates and protects the internal mechanisms against any accidental or occasional tampering. -
Page 6: Characteristic Parameters
+5°C to +40°C, relative humidity: 40% to 90%. MANUFACTURER The “BUMPER BOAT” eries Automatic Games mod. “WILLY”, " ” and " ” are manufactured by: EuroGames S.r.l. Via Degli Scavi, 41 Tel. +39 0543 796665 47122 FORLÌ / ITALY Fax +39 0543 722727 CONFORMITY The Automatic Games “BUMPER BOAT”... -
Page 7: Functioning
BUMPER BOAT FUNCTIONING The Automatic Games of the “BUMPER BOAT” series have been designed to be used in public, suitably fi tted places like amusement parks, fun-fairs and public gardens. CAUTION The internal electric components of the “BUMPER BOAT” series are suitably protected against humidity. -
Page 8: Setting The Game Time
BUMPER BOAT Fig. 2 Fig. 3 5 - Using the supplied key B open the seat lock, raise the seat (fi g. 2) from the bottom and rotate it backwards. 6 - Position the batteries in the relevant compartment and make sure to connect the positive (+) cable to the positive terminal (red and brown) and the negative (-) cable to the negative pole (black, fi... -
Page 9: Selecting The Sound Effects
TESTING For the production, tests, controls and inspections of its Automatic Games, EuroGames adopts the criteria established by the international ISO 9000 standards for Quality Systems. Before allowing people to use the “BUMPER BOAT”, check for 3 (three) times its correct... -
Page 10: Use
BUMPER BOAT ATTENTION Because of its functions, dimensions and characteristics, the Automatic Games of the “BUMPER BOAT” series are not recommended to children under 8 years. For this reason, children under this age must always be accompanied by an adult who can watch over them. -
Page 11: Maintenance
BUMPER BOAT MAINTENANCE ATTENTION All maintenance operations must be carried out only by qualifi ed people, authorized by the “BUMPER BOAT” owner or by the pool attendant. General cleaning This operation must be carried out daily. With a wet sponge or cloth, and, if necessary, using suitable house detergents, clean the external surface of the driving seat, then dry. -
Page 12: Checks And Inspections
Repair works should be carried out only by skilled and authorized people to prevent accidents and damages to the users. The “BUMPER BOAT” series Automatic Games supplied by EuroGames have been manufactured according to the EC directives; if the local laws require special installation conditions, make sure that these provisions do not imply changes of the “BUMPER... -
Page 13: Troubleshooting
BUMPER BOAT TROUBLESHOOTING 1 - The “BUMPER BOAT” does not run. a - check the batteries are connected and effi cient; b - make sure the coin-box microswitch is well connected and n effi cient working order; c - check the timer is in effi cient working order. -
Page 14: Spare Parts
These functions can be programmed using the timer control unit. Programming When the Bumper Boat is not used, the display shows EuroGames logo alternated with the coin counter (if this has been selected). Pressing one of the three selection keys ( - , ENTER, + ) once, the display lights while the coin counter remains displayed (if selected). -
Page 15: Resetting The Coin Counter
(which can be viewed only in the protected menu). To reset the partial counter, proceed as follows: When the display is in the normal mode showing the EuroGames logo alternated with the coin counter, press: the + key for 4 seconds or more;... -
Page 16: Wiring Diagram
BUMPER BOAT Wiring diagram BATTERY CHARGER LIGHT COUNTER COIN BOX SMALL PEDAL REMOTE CONTROL EMERGENCY RADIO CONTROL TURN SIGNALS 24 V BRAKE CONTROL LEVER PEDAL POTENTIOMETER DISP1 EXTERNAL DISPLAY DISP2 HORN BACK... -
Page 17: Battery Charger
BUMPER BOAT BATTERY CHARGER Technical features The battery charger consists of a red fi reproof case that contains the electric transformer, the electronic board, the power plug and the power cable, in order to charge the “BUMPER BOAT”. The features of any single group are the following: Width ...... -
Page 18: Using The Battery Charger
The Battery charger has been designed to be installed in public places like amusement arcades, shopping centres, amusement parks, fun-fairs and public gardens with specifi c tracks/pools for EuroGames Automatic Games “BUMPER BOAT” series. To recharge the batteries of the “BUMPER BOAT” series Automatic Games, operate as it... - Page 19 Periodically check the condition of the cable and of the power plug, and the effi ciency of the differential protection of the battery charger (every 15 days). The battery charger should not be tampered or modifi ed by the user. The EuroGames products meet the established standards. Repais works should be carried out only by specialized and authorized technicians.
-
Page 20: Warranty
WARRANTY • EuroGames offers a warranty of one year from the purchase date stated in the sale document. The Manufacturer undertakes to make good by repair or replacement at its option any defect in the “BUMPER BOAT” arising from faulty design, materials or workmanship which shall become apparent within the warranty period. - Page 21 BUMPER BOAT NOTES...
- Page 22 BUMPER BOAT NOTES...
- Page 24 EuroGames s.r.l. Via degli scavi, 41 - 47122 Forlì (ITALY) Tel. +39 0543 796665 Fax. +39 0543 722727 www.eurogames.it - info@eurogames.it...
