For two-stroke glow engines up to 7.45 cc capacity
This model requires a five-function radio control system
Specification Wingspan approx.
Length approx.
Wing area approx.
Tailplane area approx.
Total surface area approx.
All-up weight according to fittings approx.
Centre of Gravity, measured at
the root leading edge, approx.
Caution: this model is not a toy!
If you are a beginner to this type of powered model, please ask an experienced
model flyer for help and support. If you attempt to operate the model without knowing
what you are doing, you could easily injure yourself or somebody else. Please keep
your safety and well-being in mind at all times.
Important: before you start construction
Even if you have already built a large number of RC models please read right through
these instructions and check that all the kit components are actually present. We
have taken great trouble to keep construction as simple as possible, without making
any compromises in the area of safety.
Note regarding the film covering
Minor creases or bubbles may develop in the film covering due to major fluctuations
in weather conditions (temperature, humidity etc.); in rare cases you may even find a
slight warp in a component. These trivial faults are in the nature of film-covered built-
up wooden structures, and can easily be corrected using a heat gun, as commonly
used for modelling.
Creases:
Blow warm air over the area and rub down with a soft cloth.
Wing warp:
Hold the panel twisted gently in the opposite direction to the warp,
and apply warm air to remove the creases from the covering.
Instructions
CESSNA
four-stroke glow engines of 9.32 cc capacity
®
172 S
or
Cessna® emblems, logos and body
designs are trademarks of Textron
Innovation Inc. and are used under
license by Graupner GmbH & Co. KG
1675 mm
1300 mm
37.4 dm²
8.6 dm²
46 dm²
3450 gLongitudinal dihedral
0 - 0.5 degrees
80 - 85 mm
Order No. 9595
9595.M
