Summary of Contents for Elliott 430G
- Page 1 430G Pneumatic Hammer Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions www.elliott-tool.com...
-
Page 3: Table Of Contents
Table Of COnTenTs Introduction ......................4 Safety Guidelines ....................5 Specifications ....................... 7 Service Notes ....................... 8 Parts List & Diagrams ................... 9 Warranty ......................10... -
Page 4: Introduction
InTRODUCTIOn Thank you for purchasing this Elliott product. More than 100 years of experience have been employed in the design and manufacture of this control, representing the highest standard of quality, value and durability. Elliott tools have proven themselves in thousands of hours of trouble-free field operation. -
Page 5: Safety Guidelines
National Standards Institute, Inc., 11 W 42nd Street, New York, NY 10036. • Know Your Elliott Tool. Read this manual carefully to learn your tool’s application and limitations as well as the potential hazards specific to this tool. - Page 6 Do not use a damaged tool. Tag damaged tools “Do Not Use” until repaired. A damaged part should be properly repaired or replaced by an Elliott service facility. For all repairs, insist on only identical replacement parts.
-
Page 7: Specifications
sPeCIfICaTIOns Recommended 90 PSI (6.2 bar) Maximum air pressure air Pressure Required 30 CFM (per tool being operated) available CfM Recommended 1/2” Hose Whip, 25ft Maximum Length 3/4” Supply Hose for longer runs Hose size Pneumatic Hammer... -
Page 8: Service Notes
2. To install the exhaust deflector, use Elliott P/N 35-3CH932 installation tool to press deflector over the barrel. Make sure the barrel flange and absorber ring are installed prior to installing the deflector. -
Page 9: Parts List & Diagrams
Trigger* 35-0481 Pin* 35-250027-487 Valve Stem Bushing* 35-250027-431 O-Ring* 35-250027-488 Throttle Valve* 35-250027-489 Valve Spring* 35-250027-490 O-Ring* 35-27505 1/2" NPT Inlet Bushing* *Complete Handle Assembly 35-3CH-1A includes all of these items. Page 4 Model 430G Pneumatic Hammer TM-75 Pneumatic Hammer... -
Page 10: Warranty
WaRRanTy Should any part, of Seller’s own manufacture, prove to have been defective in material or workmanship when shipped (as determined by Seller), Seller warrants that it will, at its sole option, repair or replace said part f.o.b., point of manufacture, provided that Buyer notifies, in writing, of such defect within twelve (12) months from date of shipment from the manufacturing plant. - Page 12 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Locally Supported By: Contact us or your local support. Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 www.elliott-tool.com/support Phone: +1 937 253 6133 • +1 800 332 0447 Fax: +1 937 253 9189 www.elliott-tool.com...
