User Manual
Please note your phone is battery-embedded design with removable battery and battery cover. Unauthorized
personnel are strictly prohibited from disassembling the phone. Make sure to use only the power adapter (5V
2A Output AC/DC) that came with DOT-PM80.
In case your phone does not work as expected, you are strongly recommended to restart it by pressing and
holding the power button for at least 12 seconds until the startup screen appears. If your phone has
encountered a serious error and cannot be recovered, you should reset your phone to factory settings by using
the menu, either "Backup & Reset", or "Factory Reset". For more details, please refer to "Factory data reset"
section on page 44
Note: Please be cautious while performing the factory data reset. Because this will erase personalized
settings and data saved in your phone, such as SMS, Contacts, Music, etc.
Body-worn Operation
This device was tested for typical body-worn operations with the front
& back of the phone kept 0.2 inches (0.5 cm) between the user's body
and the front & back of the phone. A minimum separation distance of
0.2 inches (0.5 cm) must be maintained between the user's body and
the front & back of the phone. Any belt clips, holsters, and similar
accessories containing metallic components may not be used. Body-
worn accessories that cannot maintain 0.2 inches (0.5 cm) separation
distance between the user's body and the front & back of the phone,
and have not been tested for typical body-worn operations should be
avoided.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume
levels for long periods. Exercise caution when holding your device near
your ear while the loudspeaker is in use.
© 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved
1
DOT-PM80 Android 6.0.1 User Manual
Rev 03
Advertisement
Table of Contents
Related Manuals for POINTMOBILE DOT-PM80
Summary of Contents for POINTMOBILE DOT-PM80
-
Page 1: User Manual
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. Rev 03 © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 2: Table Of Contents
OS Image update from the FOTA ...........................43 Factory data reset ................................45 Factory data reset from Settings ..........................45 Force Factory data reset ............................47 EmKit .....................................50 EmKit Secure ................................51 EmKit Remote ................................54 EmKit Tools ................................62 © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 3: Getting Started
1. Barcode Scanner 2. LED Indicator 3. Illuminance / Proximity Sensor 4. Front Camera 5. Touch Screen 6. Front Panel 7. AC / DC Adaptor Jack 8. Direct Sync I/O Connector © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 4 DOT-PM80 Android 6.0.1 User Manual © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 5 Getting Started 1. Volume Key 2. Scanner Trigger 3. Camera 4. Flash Light 5. Speaker 6. Battery Cover Lock 7. 3.5mm Audio Jack 8. Power Key 9. Scan Trigger Key © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 6: Accessary
DOT-PM80 Android 6.0.1 User Manual Getting Start ed Accessary Accessary Getting Started AC/DC adapter Plug (US/ EU/ UK) LCD protection film Li-ion battery (3,000mAh or 4000mAh) © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 7: Setup Dot-Pm80
1. Insert the SIM card and SAM card (Optional) into the each slot. (Gold contact should face down) 2. To remove the card, gently slide it out of the slot. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 8 2. To remove the microSD card, gently slide it out of the slot. Note: To avoid data loss and SD card damage, please ensure the SD card is unmounted from Android system “Settings – Storage - Unmount SD card” Getting Start ed © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 9 Close the Battery Cover Insert “Battery Cover” from the top area first and then put in bottom area. Press battery cover with both hand and Make sure “Battery Cover Lock” is “Locked “ © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 10: Charge Dot-Pm80
Extend Battery : About 6hours Note: Always use an original charger and cable from the Point Mobile. Other chargers and cables may damage DOT-PM80. In addition, make sure connector, charger, cables are not wet. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 11: Turn On/Off Dot-Pm80
Turn On 1. Press and hold down the “Power Key” for a few seconds. 2. When DOT-PM80 enter to the boot mode, it will display “SMART BEYOND RUGGED” logo with short vibration 3. Release the “Power Key” and wait until DOT-PM80 finish booting Note: If you cannot turn on your DOT-PM80, try below steps To turn on DOT-PM80, battery needs to be charged certain level. -
Page 12: Hot Swap The Battery
Hot swap the batt ery Hot swap the battery Getting Started When battery level is low, you can replace the battery without turning off and on DOT-PM80. Remove the Battery and replace to another one. Make sure the battery cover closed firmly. -
Page 13: Learning The Basics
Adjusts the media volume. In camera preview Take the photo by pressing Volume Up or Down key. Scanner Triggers When “Scan Wedge” mode is activated By pressing, DOT-PM80 scan the barcode. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 14 Press to go back to the previous screen, or to close a dialog box, options menu, notification panel, etc. Function key (Programmable) Press to run the function or the app. You can set EmKit - Program Buttons © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 15: Use A Touch Screen
One-finger press, wait, lift for “Select an item” Drag, Swipe, or Fling One-finger press, move, lift for “Scroll” or “Tilt” Long-press drag One-finger press, wait, move, lift for “Pick up and move” or “select multiple items” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 16 Vertical or horizontal swipe in a single direction Pinch Open & Close Two-finger press, move outwards and inwords, lift for “Zoom in and out” Rotate When DOT-PM80 is turning sideways, screen orientation is changing © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 17: Home Screen, Apps And Widget
Touch an icon to run an app, open folder, etc Favorite tray apps Touch to run an app Touch and hold to reorganize App Drawer Touch to enter “Apps and Widget” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 18 Create “App Folder” Long press the app icon to other app icon. This will create the “App Folder” To set the folder name, touch the “Unnamed Folder” and rename it © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 19 App, you can check details by drag down the “Status Bar”. Quick setting panel You can access “Quick setting panel” by drag down the “Notification panel”. You can enable / disable functions or change modes easily. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 20 Long press, specific app icon to place to the “Home Screen”. All available widgets are listed in the “Widgets” tab, alphabetically. Long press, specific widget to place to the “Home Screen”. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 21: Status & Notifications Icons
Battery is partially drained Battery is low Battery is very low Battery is charging GPS is on Alarm is set Speaker phone is on Headset connected Vibrate mode/ Mute Phone mic is mute © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 22 Connected to VPN network Upcoming event Screenshot captured SD card removed, Preparing SD card unexpectedly OTG device connected File uploaded File downloaded There are more notifications Other input method available © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 23: Make A Call
To make a call from your contact list, select “CONTRACTS” Touch to use a dialer Suggested phone number(s) Phone number can be saved to “CONTACTS” Touch and hold the dial pad #1, to access voicemail. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 24 Tip: To mute the ringtone volume of an incoming call, keep press the “Volume down” key or turn your DOT- PM80 over. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 25: Add To A Contact
You can sync with your contacts in the Google account. IMPORT CONTACTS You can import contact in the storage (.vcf file) or SIM card Touch to add a new contact © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 26: Send A Message
Favorite tray apps Touch to use a dialer Touch to type a name, phone number or email Suggest contact display here. Touch “Contacts” to compose a message © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 27 Your message display here Touch to send the composed message You can attach photo, saved picture, voice or location Note: You may allow granting “Message App” access specific app or service. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 28: Connect To Your Wi-Fi Network
Icon means: Open Wi-Fi network. You don’t need to enter the password Icon means: Secured Wi-Fi network. To connect this Wi-Fi, you need to enter the password © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 29 Connect to your Wi-Fi network Learning the basics Touch SSID, which you want to connect. To connect to secured network, enter the password Your DOT-PM80 is obtaining the IP address from selected © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 30: Scanner Settings
Scanner Settings Default setting of Scanner is “Off” To use the Scanner, EmKit and then “ScanSetting” Touch “App Drawer” - “Settings” and Touch then “ScanSettings” Touch to turn on the Scanner © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 31 Use a Scanner Scanner Settings Now you can see “Scanner” icon in the “Status Bar” Note: When “Scanner” turned on, you can scan the barcode with “ScanDemo” in the EmKit © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 32 In the Wedge menu you can change, decode scan data’s result type handling “User Message”, “Keyboard Event”, “Clipboard’ or ‘Intent Broadcast’. Also you can set “Terminator” – “Space”, “Tab”, “LF” or “Tab & LF” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 33 Window”, set “Decode mode”, “Power save mode” and enable / disable “Aimer” & “Illumination” In the “Notification”, you can set notification option. You can change the volume level, notification sound, LED and vibration option © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 34 Scanne r Settin gs Use a Scanner Scanner Settings In the “Wedge”, you can enable / disable “Barcode ID” and “Aim ID”, set “Group separator”, “Prefix” & “Suffix” and “Character set” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 35 DOT-PM80 Android 6.0.1 User Manual Scanne r Settin gs Use a Scanner Scanner Settings In the “Symbologies”, you can enable / disable specific barcode. By touching each “Symbology” name, you can set detail option. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 36 In the ‘About’, you can check your Scanner’s information and restore Scanner’s settings to default Tip: By plug DOT-PM80 into the “Gun Handle”, you can start to scan with “Trigger” button © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 37: Scan A Barcode
Example of good Barcode reading Idle barcode scan Please aim the middle of barcode Even you aim the barcode slightly upper or down area or angle is slightly tilted, you can read the barcode © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 38 If you aim the barcode wrong direction or tilt too much, you can’t read the barcode If you aim part of Barcode or aim two barcode together, you can’t read the barcode © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 39: Read A Credit Card
Read a Cre dit Ca rd IC Card Read a Credit Card To read an “IC Credit Card” with DOT-PM80, please insert the card to the “IC Card Pocket”. IC chip should face the front side © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 40 Read a Cre dit Ca rd Magnetic Card Read a Credit Card To read a “Magnetic Credit Card” with DOT-PM80, please slide the credit card to the “Card slot” Magnetic bar should face the front side. You can read the card, bi-direction...
-
Page 41: Os Update
To update OS image, copy or place OS image file into the root folder of “Internal Storage” or “External Storage” “App Drawer” - “Settings” and then Touch “About phone” Touch “System Updates” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 42 By touching the “CONTINUE” button, your DOT-PM80 start to update the OS image. During this time, you cannot use your DOT-PM80. Please save the data before start, the OS update process. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 43: Os Image Update From The Fota
OS Updat e OS Imag e u pdat e fr om t he FO TA OS Image update from the FOTA OS Update icon for the advanced option Touch “FOTA Client” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 44 You can cancel OS image download process Note: Default OS image download setting of FOTA Client is “Download over Wi-Fi only” Please connect to the nearby Wi-Fi network for FOTA service © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 45: Factory Data Reset
“Factory data reset” your DOT-PM80 “App Drawer” - “Settings” and then Touch “Backup & reset” Touch “Factory data reset” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 46 Please note, all apps and data in the internal storage will be deleted and restored to “Factory default” and this process cannot “Undo” Touch to start “Factory Reset” process Touch to confirm erase of “Apps and Data” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 47: Force Factory Data Reset
Force Factory data reset Factory data reset Force Factory data reset your DOT-PM80 You can perform “force” factory data reset your DOT-PM80. When your DOT-PM80 turned off, press “Power” + “Volume up” + “Home” button all together. After short vibration from your DOT-PM80, you may release the buttons. - Page 48 Facto ry d ata R eset Force Factory data reset Factory data reset Select “Wipe data/factory reset” Select “Yes” to perform the “Factory data reset” After that, your DOT-PM80 start wiping the data © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 49 Note: Factory Reset Protection (FRP) is a security method that was designed to make sure someone can't just wipe and factory reset your device if you've lost it or it was stolen © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 50: Emkit
EmKit consist with “EmKit Secure”, “EmKit Remote”, “Emkit Tools” and “EmKit Demos” EmKit Secure “Lock Your Device” EmKit Remote “Mobile Device Management” EmKit Tools “Smarty Tools Ease Enterprise” EmKit Demos “Friendly For Programmers” © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... -
Page 51: Emkit Secure
Restrict MTP connection : Limit to access Point Mobile Device’s MTP connection Screenshot Disable : Disable screenshot capture in OS level Restriction feature will be keep added. After restriction feature check, switch Launcher Lock to On. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 52 DOT-PM80 Android 6.0.1 User Manual EmKit Secure EmKit Secure EmKit When Power Launcher is locked, operator could not access to App drawer. Example of Screenshot Disable restriction. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 53 EmKit Secure EmKit Secure EmKit Program Buttons You can assign Hardware buttons function to rich pre- assigned functions. Also you can applying the customized KCM file (Key Character Map Files) here. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 54: Emkit Remote
App provides AirWatch agent install via Google Play or Web URL. Google Play method requires Google account login. AirWatch agent download and install managed by Google Play Web URL method requires user’s manual installation © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 55 Web browser will download the apk file to the Point Mobile Android device. Before downloading, browser need permission to download apk file to the storage. Please touch Update Permissions button © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 56 After permission update, web browser download the latest version of AirWatch agent apk file. Install this apk file to Point Mobile Android device. Note: If you need to install specific agent version, please contact to AirWatch © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 57 SOTI Mobi Control installer is pre-installed to Point Mobile Android device. To start enrollment process, please touch MobiControl icon Mobi Control app request permission grant during enrollment process. Please allow it. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 58 After login, Mobi Control app communicate with SOTI server and then install the Mobi Control agent Note: Agent version determine from SOTI console’s setting. If agent version is incorrect after enrollment, please contact to SOTI © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 59 App provides TeamViewer QS app install via Google Play or Web URL. Google Play method requires Google account login. TeamViewer QS app download and install managed by Google Play Web URL method requires user’s manual installation © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 60 Web browser will download the apk file to the Point Mobile Android device. Before downloading, browser need permission to download apk file to the storage. Please touch Update Permissions button © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 61 After permission update, web browser download the latest version of TeamViewer QS apk file. Install this apk file to Point Mobile Android device. Note: If you need to install specific TeamViewer QS version, please contact to TeamViewer © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
-
Page 62: Emkit Tools
Nearby Point Mobile device will automatically communicate with Master PDA and download the backup file and then Restore. Create the backup file Backed up file will restore your Point Mobile Android device. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved... - Page 63 - Connect to your network - Restore your PDA - Work Managed Device setup Step 1. Create Direct Clone Backup file Make a Direct Clone file from Master PDA device © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 64 Step 2. Upload Direct Clone file to your FTP site or Web server Copy the Direct Clone file from the Point Mobile Android device Upload this file to your FTP site or Web Server. You may change file name © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 65 DOT-PM80 Android 6.0.1 User Manual EmKit Tools EmKit Tools EmKit After file uploading, please check the url first. File should be download with url address. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 66 DOT-PM80 Android 6.0.1 User Manual EmKit Tools EmKit Tools EmKit Step 3. Generate QRcode Access to Web QRcode generating site www.pointmobile.co.kr/qr Click Web/Google Drive menu Input Network information, Direct Clone file name and password © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 67 DOT-PM80 Android 6.0.1 User Manual EmKit Tools EmKit Tools EmKit Make sure put http:// or https:// in front of url address Note: Click Generate QRcode button and save or print generated QRcode © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 68 Press the Power Button, then you will see the Scan2Set in the menu Read the generated QRcode. Point Mobile Android device will download the file from the FTP site or Web server and restore Direct Clone file © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 69 DOT-PM80 Android 6.0.1 User Manual EmKit Tools EmKit Tools EmKit ScanSetting You can set your DOT-PM80’s scanner option with intuitive menu. System information All of SW and HW information available here and can save it to the file. Touch Save to file.
- Page 70 Copy the file to the PC and then zip it to reduce the file size. Share bug report file to the service center or Point Mobile Support team with reproduce steps. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 71 SKU (Stock Keeping Unit) ICCR Demo Developer can demonstrate or check Point Mobile Android model’s payment solution. Some of demo app only available for specific Hardware feature integrated SKU (Stock Keeping Unit) © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 72 Developer can demonstrate or check Point Mobile Android model’s IC card and Magnetic card reading solution. Some of demo app only available for specific Hardware feature integrated SKU (Stock Keeping Unit) © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 73 NFC Read/Write solution. Some of demo app only available for specific Hardware feature integrated SKU (Stock Keeping Unit) Ping Demo Developer can demonstrate or check Point Mobile Android model’s ping test. © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 74 DOT-PM80 Android 6.0.1 User Manual © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 75 Bluetooth mobile printing solution. SAM Demo Developer can demonstrate or check Point Mobile Android model’s SAM communication. Some of demo app only available for specific Hardware feature integrated SKU (Stock Keeping Unit) © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
- Page 76 EmKit Demos EmKit Scan Demo Developer can demonstrate or check Point Mobile Android model’s Scanner solution. Some of demo app only available for specific Hardware feature integrated SKU (Stock Keeping Unit) © 2006 – 2018 POINTMOBILE Co., Ltd. All rights reserved...
