Summary of Contents for DDS OA Kneetrac
- Page 1 USER MANUAL disc disease solutions Bi-Compartmental OA Knee Decompression...
- Page 2 Thank you for choosing DDS and welcome to an enjoyable life, free from knee pain. www.DDSbelt.com...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Safety Warnings What’s Inside the Box Recommendations for E ective Use How to Wear the Product Angle Lock System OA Kneetrac Knee Extension Overview Maintenance Warranty Registration & Warranty Card Table of Contents... -
Page 4: Safety Warnings
Safety Warnings READ this manual carefully to ensure proper use of the OA Kneetrac ALWAYS follow the advice of your physician before wearing the brace. DO NOT wear an OA knee brace on both knees at the same time. IMMEDIATELY discuss with a specialist if you feel any discomfort, pain, swelling and/or poor blood circulation. -
Page 5: What's Inside The Box
What’s Inside the Box Front Strap handle Strap Knee support main frame Rigid Guard Center Connector (Hinge) º FLEX º The angle stopper is located FLEX º º inside of the center connector/hinges FLEX º º FLEX º º FLEX º... -
Page 6: Recommendations For E Ective Use
Recommendations for E ective Use Elastic Knee Sleeve (Not Included) An Elastic Knee Sleeve worn under the DDS OA KneeTrac may help prevent brace migration. Rigid Guard Velcro Rigid Guard Front Back Sponge Pad The Rigid Guard can be added in place of the shin sponge pad if there is discomfort or pain experienced on the shin when wearing the brace. -
Page 7: How To Wear The Product
How to Wear the Product The brace must only be worn on the knee it was assigned to by your physician. Sit on a stable chair and extend your leg. Place the brace on your knee so that the hinge is centered with the knee. With the leg extended and only slightly bent, fasten strap #1 (as indicated on the handle) rst. - Page 8 How to Wear the Product Bend the knee in a 90 angle when fastening straps #3 and #4. If the center connector (hinge) is too high or too low compared to the knee, adjust the height appropriately. : The length of each strap can also be adjusted OPTIONAL Remove the adjustable velcro.
-
Page 9: Angle Lock System
Angle Lock System IMPORTANT : Only use the Angle Locks when recommended by your physician. Angle Stopper The Angle Lock System controls the angle and the range of motion with respect to knee extension and knee exion by combining various EXT and FLEX Angle Stoppers. Extension Flexion Degree Flexion... - Page 10 How to Secure the Angle Stopper The Angle Lock System is installed inside the center connector(hinge). Remove the sponge padding to access. Attach the exion stopper with the extension stopper [B] so that the exion degree [C] snaps in to the exion degree indicator [D]. Tighten the screw [E] with the allen key to attach stoppers to the Hinge [F].
-
Page 11: Oa Kneetrac Tm Knee Extension Overview
• Angle Restriction: 30 • Angle Restriction: 45 • Angle Restriction: 60 º º º • Range of Motion : 76 • Range of Motion : 61 • Range of Motion : 46 º º º OA Kneetrac Knee Extension Overview... - Page 12 • Angle Restriction: 31 • Angle Restriction: 46 • Angle Restriction: 61 º º º • Range of Motion : 75 • Range of Motion : 60 • Range of Motion : 45 º º º OA Kneetrac Knee Flexion Overview...
- Page 13 Maintenance for OA Kneetrac Main Frame of the Knee Brace - Clean with a damp cloth and let it dry in the shade. Sponge Pads - Remove the sponge pads and place them in the laundry bag provided with the Brace.
-
Page 14: Warranty
Warranty Limited 1 Year Warranty DDS, Inc. will repair or replace the unit free of charge for a 1 year period from the date of purchase. The warranty is covered only if the device is defective in workmanship or materials. -
Page 15: Registration & Warranty Card
PHONE (DAY): (EVENING) PRODUCT INFORMATION DATE OF PURCHASE: DDS MODEL: DDS OA Kneetrac HOW DID YOU BECOME AWARE OF DDS? MAIL TO SERVICE CENTER: DDS, INC. 100 Commerce Way, Suite 5 Hackensack, NJ 07601 U.S.A. www.DDSbelt.com Registration & Warranty Card... - Page 16 Disc Disease Solutions, Inc. 100 Commerce Way, Suite 5 Hackensack, NJ 07601 U.S.A. For Canada please contact Tel: (888) 495-7440 Tel: (204) 470-5741 Fax: (201) 880-7799 canada@discdiseasesolutions.com www.DDSbelt.com info@discdiseasesolutions.com...
