I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Secure Storage Cabinet
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PAC735
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for CHIEF PAC735
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Secure Storage Cabinet Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PAC735...
- Page 2 Milestone assumes installer’s responsibility to make sure the combined weight of no responsibility for accuracy, completeness or sufficiency of all equipment stored within the PAC735 does not exceed 40 lbs the information contained in this document. (18.14 kg).
- Page 3 Installation Instructions PAC735 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
- Page 4 PAC735 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" 1/2" (12.7mm) PARTS B (1) C (1) [Left wedge plate] A (1) [Right wedge plate] [Storage cabinet] E (1) F (1) [Front cross bar] [Rear cross bar] D (1) [Clamp bracket] L (2)
- Page 5 Assemble Base Support (Cart Installation ONLY!) (H) x 2 NOTE: If installing PAC735 to a stand rather than a cart, the base support is not needed as the PAC735 will sit directly on the base of the stand. Proceed to Mount Storage Cabinet section.
- Page 6 PAC735 Installation Instructions Push base support back until it snaps in behind front cap of Insert four 5/16-18 x 5/8" button head cap screws (G) cart base. (See Figure 4) through clamp bracket holes and into holes on back of storage cabinet (A).
- Page 7 Installation Instructions PAC735 Rack Installation (Optional) Open windowed door. Slide rack equipment (not included) into storage cabinet. NOTE: Each storage cabinet supports 19" (483 mm) wide rack mount equipment and has a capacity of 4 U. Use #10-32 cage nuts (not included) to secure storage...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
