- Page 1 EdgeGate483S (GW-483S) Installation Guide MN100167 Rev. B...
- Page 2 Telco Systems will, if necessary, explain issues which may not be covered by the document. Telco Systems' liability for any errors in the document is limited to the documentary correction of errors. TELCO SYSTEMS WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN...
-
Page 3: Safety Considerations
GW-483S Installation Guide Rev. B Safety Considerations Please read these safety considerations before you begin installation. The instructions in this guide are for use by qualified personnel only. To avoid shock, do not perform any procedures other than those contained in the instructions. CAUTION Changes or modifications made to this device that are not expressly approved by the party responsible for compliance could void the user’s authority to... -
Page 4: Table Of Contents
GW-483S Installation Guide Rev. B Table of Contents SAFETY CONSIDERATIONS........................3 TABLE OF FIGURES............................ 5 ABOUT THIS DOCUMENT ......................... 6 ........................6 HOULD UIDE ......................6 BTAINING ECHNICAL SSISTANCE INTRODUCTION............................7 ..........................7 RODUCT IGHLIGHTS ................................7 ORTS ............................7 OWERING PTIONS GW-483S O... -
Page 5: Table Of Figures
GW-483S Installation Guide Rev. B Table of Figures Figure 1: The VoIP Gateway Board..................10 Figure 2: A GW-483S System Cabinet – The Technician Access Area ......11 Figure 3: A GW-483S System – Cable Management Area..........13 Figure 4: A GW-483S System – Telco Cable Management ..........14 Figure 5: The VoIP Gateway Board Enclosure –... -
Page 6: About This Document
Obtaining Technical Assistance Telco Systems provides technical assistance for customers and partners. Users can obtain technical assistance by any of the following phone, fax and e-mail options: Web Access: http://www.telco.com... -
Page 7: Introduction
GW-483S Installation Guide Rev. B Introduction The EdgeGate483S is a multi-service customer premises equipment (CPE) device designed to reduce the cost of delivering voice, video, and data services to homes, small office/home office (SOHO), and small enterprise. This guide provides installation instructions for the GW-483S family of EdgeGate483S systems. -
Page 8: Available Gw-483S Options
GW-483S Installation Guide Rev. B Available GW-483S Options The tables below describe the various system, board and power supply options: System Models Model Name Power Option Options • GW-483S-z Not included 100BaseFx and 1GBaseX uplink (z = software • 8 10/100BaseTX ports option to be loaded •... -
Page 9: Before You Install
GW-483S Installation Guide Rev. B Before You Install Before you begin the installation: 1. Please review the packing list. 2. Familiarize yourself with the equipment and unit (see pictures below). Packing List The packing list depends on the ordered GW-483S model, but can include some or all of the following items: •... -
Page 10: Figure 1: The Voip Gateway Board
GW-483S Installation Guide Rev. B 2 Phone Actual Lines location of Phone Line LEDs Adapters Power, Ready, and Voice LED Labels Hinge F.O. LNK/ACT Actual LED Label location of Reset Button Reset Button Label 8 LAN Customer Ports Access Screw Telco Area Lock Screw Bottom... -
Page 11: Figure 2: A Gw-483S System Cabinet - The Technician Access Area
GW-483S Installation Guide Rev. B Upper Middle Mounting Cover Cover Base Fiber Splice Routing Tray Console cable connector Lower Mounting Figure 2: A GW-483S System Cabinet – The Technician Access Area NOTE The console cable is provided for use by service personnel for configuring the EdgeGate 483S VoIP Gateway, as described in the EdgeGate VoIP Gateway H.323, MGCP, SIP User Guide (Document MN100112). -
Page 12: Installing The Gw-483S
GW-483S Installation Guide Rev. B Installing the GW-483S This section contains instructions for the indoor/outdoor installation of the GW-483S system. The installation is broken into three distinct phases: Installing the Cabinet Installing the VoIP Gateway Board Enclosure Installing the RF Video Board (Optional) After completing the installation, you can refer to: •... -
Page 13: Figure 3: A Gw-483S System - Cable Management Area
GW-483S Installation Guide Rev. B 2. Use a pencil point to punch a small hole in the center of the middle entrance circle. CAUTION Do not use a knife to cut the grommet. Doing so may create a too large of an opening which might allow moisture into the cabinet. -
Page 14: Installing The Voip Gateway Board Enclosure
GW-483S Installation Guide Rev. B NOTE Fiber optic connectors, especially fiber edge (Ferula), must be professionally furbished and clean. 7. Secure the incoming service cable to the cable shield using a tie wrap. Fiber Cable Slack Tray Fiber Cable Interface Fiber Connector External Fiber Cable... -
Page 15: Figure 5: The Voip Gateway Board Enclosure - Top View
GW-483S Installation Guide Rev. B Repeat for the bottom hinges. 4. With the top/bottom hinges aligned, gently push the enclosure against the cabinet until the enclosure snaps into its place. 5. The enclosure should now freely swing open/closed to expose/cover the technician’s area of the cabinet. -
Page 16: Figure 6: Gateway Board Connectors
GW-483S Installation Guide Rev. B NOTE Use only Telco Systems approved SFP transceivers (Ordered separately). Approved SFP transceivers can be of the SM, MM and bi-directional LX, SX, ZX variety. Input Console Output Port Figure 6: Gateway Board Connectors 3. Insert the SFP transceiver into the SFP cage. -
Page 17: Figure 7: A Gw-483S System - Customer Cable Management
GW-483S Installation Guide Rev. B NOTE For 10/100BaseTX ports, use twisted pair, 100 Ohm CAT 5 or UTP CAT 5. You must use the most flexible cables available in order to make the task of routing them inside the cabinet easy and to prevent damage to the unit. 1. -
Page 18: Figure 8: A Terminal Bridge Assembly
GW-483S Installation Guide Rev. B NOTE For connecting the phones, use standard DTMF telephone cables. 1. Feed the telephone cable(s) through the punched grommet hole. 2. Place the grommet back into its original position. 3. Connect the telephone cable(s) to Phone 1 (and Phone 2) RJ-11 connector(s), as shown in Figure NOTE... -
Page 19: Installing The Rf Video Board (Optional)
GW-483S Installation Guide Rev. B WARNING Insert user cables directly into the user’s house. Use Min 26AWG for local phone lines cables. Do not run cables beyond 140 feet outdoors! Cables may NOT be connected to Telecommunication Network Voltages. Do not connect any port or cable from/to the public telephone network! Locking the Gateway Board After connecting all the cables listed in the previous section, use a ¼”... -
Page 20: Figure 10: Rf Video Board - Top View
GW-483S Installation Guide Rev. B drop into the mechanical alignment slot. Push the board downwards until the bottom mechanical alignment leg touches the lowest point of the mechanical alignment slot. 5. Slowly line-up the two mechanical mating pins with their matching holes on the gateway board, then press down until you hear a click indicating that the RF board has been secured to the gateway board. -
Page 21: Figure 12: Rf Board Cable Management
GW-483S Installation Guide Rev. B NOTE The two mechanical mating pins, as well as the two mechanical support posts, are located diagonally opposite from each other. Connecting the RF Board Cables Connecting Fiber Cable to RF Board 1. Route a fiber cable from the technician’s area, through the mechanical notch and connect it to the RF board’s fiber connector (see Figure 12). - Page 22 GW-483S Installation Guide Rev. B 5. Connect the RF video cable to either the L-Band or the CATV BNC connector, as shown in Figure Re-locking the Gateway Board After installing the RF board and connecting all the cables listed in the previous section, use the procedure in the Locking the Gateway Board section to relock the Gateway board.
-
Page 23: Diagnostics
GW-483S Installation Guide Rev. B Diagnostics LED Functions After completing the installation, verify proper operation of the unit by checking the status LEDs (Power, Ready, Voice) whose functions are described in the table below: Mode H.323, MGCP, SIP Status Downloader Status Power Steady glow Power OK... -
Page 24: Figure 13: Console Cable
GW-483S Installation Guide Rev. B NOTE A console cable can be built using the pinouts shown in Table 3 of Appendix A. Also shown are the pinouts for building telephone and 10/100BaseT/TX Interface cables. Figure 13: Console Cable Diagnostics... -
Page 25: Appendix A: Cable Pinouts
GW-483S Installation Guide Rev. B Appendix A: Cable Pinouts Table 1: Telephone Interface Pin-to-Signal Mapping Signal 1, 2 Not in use Ring 5, 6 Not in use Table 2: 10/100BaseT/TX Interface Pin-to-Signal Mapping Signal Rx + (receive positive) Rx - (receive negative) Tx + (transmit positive) Not in use Not in use... - Page 26 GW-483S Installation Guide Rev. B Table 4: Power Cable (Up to 15 m, 18 AWG) VoIP Gateway Side Power Supply Side – Polarity: On both ends, White is ( ), Black is ( DC Power Plug : Center pin diameter = 2.1mm, Outside Shell diameter: 5.5mm, Length: 9.5mm Appendix A: Cable Pinouts...
-
Page 27: Specifications
GW-483S Installation Guide Rev. B Specifications Physical Specifications Dimensions Height: 12.7 in (32.3 cm) Width: 9.9 in (25.1 cm) Depth: 3.8 in (9.7 cm) Weight 3.32 lb (1.5 kg) GW-483S (excluding the carton box and accessories) RF Video Board 0.66 lb (0.3 kg) Operating Conditions Power Requirements: 11-14 VDC, 18 W input... - Page 28 GW-483S Installation Guide Rev. B ETSI 300 386 Telecommunication Centers EN 61000-3-2 EN 61000-3-3 EN 61000-6-1 FCC 47 CFR: 2003 part 15 subpart B, class B This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
-
Page 29: Acronyms
GW-483S Installation Guide Rev. B Acronyms The following table provides a list of acronyms that are used in this document and lists their meaning. Acronym Meaning Customer Premises Equipment DTMF Dual Tone Multi-Frequency Fiber Optics FTTH Fiber-To-The-Home MGCP Media Gateway Control Protocol Power Supply Unit Ringer Equivalence Number Small-form Factor Pluggable... -
Page 30: Revision History
GW-483S Installation Guide Rev. B Revision History Date Edited by Doc Rev. History Jun 21, 07 Samir Zahra Initial release Aug 06, 07 Samir Zahra Updated picture in Figure 7. Nov 14, 07 Samir Zahra Release to Production April 13, 08 Bentzi Crystal Updated regarding TUV remarks Olga Menukhin...
