Table of Content 45340001 1. User manual ..........................2. Legal regulations ......................... 3. Safety instructions ........................4. Controller functions ........................5. Functional principle ........................6. Technical data ..........................7. Mounting ............................8. Dimensions (H x W x D) ....................... 9. Electrical connection ........................ -
Page 2: User Manual
1. User manual This instruction manual contains information and instructions to enable the user to work safely, correctly and economically on the unit. Understanding and adhering to the manual can help one: Avoid any dangers. Reduce repair costs and stoppages. Extend and improve the reliability and working life of the unit. -
Page 3: Safety Instructions
Disregarding the instruction manual Operating error Inappropriate work on or with the unit The use of non-specified spare parts and accessories Unauthorised modifications or changes to the unit by the user or his personnel The supplier is only liable for errors and omissions as outlined in the guarantee conditions contained in the main contractual agreement. -
Page 4: Controller Functions
4. Controller functions The cooling unit is used where heat needs to be dissipated from electrical control cabinets or similar enclosures in order to protect heat sensitive components. The unit has two completely separate air circuits which ensure that the clean cabinet air does not come into contact with the ambient air which may well be dirty or polluted. It is not intended for household use. - Page 5 Condensate is drained to an internal recipient where it evaporates when in contact with the cartridge surface. Resulting steam is directed towards the condenser. The PTC heater cartridge is permanently connected, and condensate evaporator has an approximate evaporation capacity of 250ml/hr. The recipient has an overflow socket at the bottom of the unit.
-
Page 6: Technical Data
6. Technical data Order Number 45340001 Cooling capacity 95F/95F 3170 BTU Cooling capacity 95F/122F 2170 BTU Compressor Reciprocating compressor Refrigerant / GWP R134a / 1430 Refrigerant charge 400 g / 14 oz 35 / 6 bar High / low pressure 508 / 88 psig Temperature range 68°F - 131°F... -
Page 7: Mounting
7. Mounting The power supply rating on unit rating plate must comply with mains rating. Always disconnect the power supply before opening the unit. The heat load to be dissipated from enclosure should not exceed specific cooling output of the unit at any condition. -
Page 8: Dimensions (H X W X D)
8. Dimensions (H x W x D) Version Nr. 1-1 - 14.02.2020 Doc. Nr. 9945340001 8 / 12... -
Page 9: Electrical Connection
9. Electrical connection Door Switch The unit can be switched on and of via a door contact switch. When delivered the door contact terminals are bridged on the female connector. To connect the door contact switch remove the bridge and connect door contact switch. -
Page 10: Taking Into Operation
11. Taking into operation Attention! The unit can be damaged by lack of lubricant. To ensure that the compressor is adequately lubricated the oil, which has been displaced during transport, must be allowed to flow back into it. The unit must therefore be allowed to stand for at least 30 min. -
Page 11: Maintenance & Cleaning
13. Maintenance & Cleaning Always switch power supply off before starting any maintenance on the unit. The cooling unit is generally maintenance free and can be operated without filters in most environments. For units with filters these should be checked, cleaned and if necessary replaced on a regular basis. In addition the unit should have regular functional tests (approx. -
Page 12: Parts Supplied
1 x Condensation Pipe 1 x Sealing Gasket Seifert Systems GmbH Seifert Systems Ltd. Seifert Systems AG Seifert Systems Inc. Seifert Systems Pty Ltd. Albert - Einstein Str. 3 HF09/10 Wilerstrasse 16 75 Circuit Drive 105 Lewis Road Hal-Far Industrial Estate...
