Information for the installer
Item no.
Parts included
Qty
1
Front Panel
1
2
Endboxes
2
3
Horizontal Top Grille
1
4
Horizontal Bottom Grille
1
5
Bracket Kit (Grille)
1
Important Notes:
• Fixings for LST assembly are included in
the Bracket Kit (item 5). Content will vary
depending on the length of the LST.
• Fixings to install LST to the wall are not
included.
• Emitter and fixings shown on exploded
view. Installation instructions provided with
emitter.
• Bottom grille (item 4) measures 20mm
LESS than the overall casing length.
All dimensions are in mm.
Merriott UK & Ireland
Purmo Group (UK) Ltd,
Eastern Avenue,
Team Valley, Gateshead,
Tyne & Wear, NE11 0PG
Tel: 0330 0415 472
sales@merriottuk.com
sales @merriott.ie
www.merriottuk.com / www.merriott.ie
Follow us on
@merriottuk and
LST Style 2
Wall mounted - suitable with horizontal Precision emitters
3
2
5
5
103
EMITTER/LST CASE
POSITIONING
E11
4
153
176
E12
E22
E24
INTERMEDIATE BRACKET PANEL DEPTH & BRACKET TYPE
PANEL
TOP
BOTTOM
LENGTH
BRACKET
SUPPORT
(mm)
SUPPORT
G10, G15,
B10, B15,
1
G17, G25
B17, B25
0-1000
0
0
1001-1550
1
1
1501-2150
1
1
2151-2750
1
1
2751-3000
2
2
PANEL
BOTTOM
LENGTH
SUPPORT
ST0, ST5,
ST7, ST9
0-1000
2
1001-1550
3
1501-2150
3
2151-2750
3
2751-3000
4
FIG. 1
FIG. 2
5
259
'X' Value = 150mm unless otherwise specified
to suit TRV location
MPI-LH002
DIST. A
DIST. B
FIG
NO.
609
0
1
909
0
1
1209
0
1
909
1809
2
DIST. A
DIST. B
FIG
609
0
1
909
0
1
1209
0
1
909
1809
2
