SUPERKIOSK M-215D User Manual

M-215D
USER MANUAL
■ Name and Function of each part
Front/Rear
Locking device
Receipt Exit
■ Product I/O
［Rear-Internal］
■ Printer Door Open/Close
① Turn key to clock direction.
※ Key location: Cable exit
∙ Be sure to read and use the manual before using it.
∙ Do not disassemble or modify this product; causes electric shock, fire, and failure.
In this case, you may not receive After Service.
∙ The shape and color in this manual may not be the same as real product.
Touch Monitor
Multi Card Reader
［Front］ ［Rear-External］
② Open door.
[HANASIS A/S]
∙ Address : 17, Saneop-ro 155beon-gil, Gwonseon-gu,Suwon-si, Gyeonggi-do, Republic of Korea 16648
■ Power ON
Rear cover
① Open door and press power button on the right top.
■ Printer Paper(Thermal) loading
Cable exit
-Power cable
-LAN cable
① Release the lock with key and open the door.
■ Card Reader Use
① If it is IC card, put the IC chip is on top.
■ Check Product Label
M-215D
기기(모델)명 : M-215D (SMART KIOSK)
제 품 코 드 : M-215D-00001A
정 격 전 압 : AC-100-240V 50/60Hz
제조자/제조국 : 하나시스(주) / 대한민국
인증받은 자 : 하나시스(주)
인 증 번 호 : R-R-HS7-K-215L
제조번호 M 2 1 5 D 0 0 0 0 1 A - 1 8 B 0 0 1
※ Please check the product model name and S/N
before requesting A/S
b
a
② Set the printer head in the direction indicated by the arrow.
a
Place the printer paper on the paper rack as shown.
b
② If it is Magnetic card, put the Magnet face is on top.
