- Page 1 J D W ZQ661 10062019 JDW PRESSURE WASHER (100 BAR) Instruction Manual Cat No: ZQ661...
- Page 2 Introduction Congratulations on choosing to purchase the JDW Pressure Washer (100 Bar).AII products brought to you by JDW are manufactured to the highest standards of performance and safety. Before use, please read this manual carefully. It gives important instructions about safety, use and maintenance of your Pressure Washer.
-
Page 7: Product Overview
PRODUCT OVERVIEW High Pressure Hose Cleaning pin Water inlet connector and filter Extension Wand Adjustable Nozzle... - Page 8 ASSEMBLY INSTRUCTIONS Minor assembly is required with this Pressure Washer. Before assembly, make sure that all parts are present and correct. Ensure that the unit is powered off and no water supply is connected to the Pressure Washer. Main Body Assembly 1.
- Page 9 2. Insert the spray adjustable nozzle(F) into the extension wand(F), as quick-connect type, you just need push it onto extension wand(D) directly and powerful until hand tight to lock it in place. When the pieces are joined properly, you cannot separate the two components by pulling straight out on the extension wand(D).
- Page 10 4. Attach the high pressure hose(A) to the pressure cleaner water outlet. Insert and quick-connect it tight to avoid leakage. When the pieces are joined properly, you cannot separate the two components by pulling straight out from the water outlet. Push the “Button”...
- Page 11 6. Attach the hose connector to pressure washer. Before attaching the connector to the male fitting, remove the plastic cap, which is inserted onto the male fitting on the pressure washer before shipping. This plastic cap can be discarded once removed. After both components have been installed, attach the garden hose with connector screw on the pressure washer.
-
Page 12: Before First Use
BEFORE FIRST USE Starting Up Ensure that the area in which you will be using the Pressure Washer is clear and free from people and animals. Ensure that the area you are using the Pressure Washer on is clear of sharp objects and debris. Due to the high power water jet, objects are subject to movement. -
Page 13: Automatic On/Off
Automatic On/Off The pressure cleaner is equipped with an automatic on/off switch. The pressure cleaner will only run when the power switch is in the ON position and the trigger on the gun is squeezed. When you release the trigger to stop spraying water through the gun, the motor on the pressure cleaner will automatically shut off. - Page 14 Gun Safety Lock This pressure cleaner is equipped with a gun trigger safety lock. When not using the pressure cleaner, use the safety lock to keep from accidentally engaging the high pressure spray. Adjust Spray Nozzle The adjustable nozzle will allow you to use any variety of spray patterns from a full fan spray (diagram 1) to a direct stream spray (diagram 2).
- Page 15 Unblock Lance When the nozzle is clogged, it will cause the pump to build pressure and may cause unit to surge ,you can clean the nozzle inserting needle into the tip to rid of the deposits. For the adjustable nozzle ,you can lubricate the nozzle collar(high pressure to low pressure )by using non-water...
-
Page 16: Clean-Up & Storage
CLEAN-UP & STORAGE Shutting down the Pressure Washer When you have finished using the Pressure Washer, follow these steps to shut the unit down: • Turn the Pressure Washer to the OFF position. • Turn off the water supply. • Unplug the Pressure Washer from the power source. -
Page 17: Maintenance
Winterising & Long Term Storage Follow all of the above shut-down procedures, adding the following steps. • After disconnecting the water supply, and before disconnecting the high-pressure hose, turn the pressure cleaner on for 2-3 seconds, until any remaining water in the pump exits. -
Page 18: Cleaning Tips
CLEANING TIPS WARNING: ALWAYS TEST THE SPRAY IN AN AREA FREE AND CLEAR OF PEOPLE AND OBJECTS BEFORE YOU SPRAY AT THE INTENDED CLEANING SURFACE. Wood and Vinyl Decks Rinse the deck and surrounding areas with fresh water. For optimal results, reduce your work area to smaller sections and clean each section one at a time. - Page 19 Cars, Boats and Motorcycles Rinse the cleaning and surrounding areas with fresh water. Rinse at high pressure using the fan spray in a sweeping motion keeping the tip of the spray nozzle at least 20cm from the cleaning surface. Maintain a further distance from the cleaning area when using a direct spray and wipe the surface dry with a non...
-
Page 20: Product Specification
PRODUCT SPECIFICATION Mains Voltage AC 220-240V Mains Frequency 50/60Hz Power Input 1200W Rated Pressure 70 bar/ 7 MPa Max Pressure 100 bar/ 10 MPa Rated Flow 5.5L/mi Max Flow 6.5L/min Max Pressure Water Supply 1.2 MPa ° Max Water Temperature Fully Assembled Weight 5 Kg Sound Pressure Level... -
Page 21: Troubleshooting
TROUBLESHOOTING When the switch is in the "ON" position but the machine will not start. Cause Solution Electrical socket is faulty Check plug, socket & fuses Check whether the voltage supplied is Voltage is inadequate adequate Power Cord is not plugged in Plug in the power cord The pump does not reach adequate pressure or fluctuates. -
Page 22: Disposal Information
The Pressure Washer makes excessive noise Cause Solution Intake is blocked Check the intake valves Valves are worn, dirty, or clogged Check, clean or replace valves Filter is dirty Check, clean or replace filter The motor stops running while in use Cause Solution Net voltage lower than... - Page 23 OPTIONAL ACCESSORIES TO BUY Rotary Brush Perfect for cleaning smooth surfaces, the Rotary Brush allows you to deal with tough to clean jobs. Fixed Brush Suitable for any task, the Fixed Brush is the go to accessory for pressure washers. Patio Cleaner Keep your patio fresh and clean with the specially designed Patio...
