ALP-120
Closet Rod / LED Luminaire
INSTALLATION / ASSEMBLY GUIDE
INSTALL TWO (2) CLOSET ROD MOUNTING
1
FLANGES (ALP-120-MF). SECURE TIGHTLY
WITH A SCREWDRIVER.
INSTALL TWO (2) CLOSET ROD MOUNTING
2
COVERS SUPPORT TO FIXTURE.
INSTALL ONTO CLOSET ROD MOUNTING
3
BASE SUPPORT.
15024 Staff Ct., Gardena CA, 90248
info@corelightingusa.com | www.corelightingusa.com
T: 888.737.9192 | F: 888.789.4643
ALP-120-MF
CLOSET ROD MOUNTING COVER
WARNING: RISK OF ELECTRICAL SHOCK
* turn off main power prior to installation
* make sure hands are dry
* never touch exposed wires
ALP120GUIDE
|
P1
