Mr Beam II dreamcut ready Quick Start Manual

Desktop lasercutter
Hide thumbs

Advertisement

Quick Links

Download this manual
EN
dreamcut
DESKTOP LASERCUTTER
QUICK START GUIDE
When you start up your Mr Beam II dreamcut / dreamcut
ready, remember that it has been assembled and packed
by us with great care. We hope that you will take the time to
unpack and set it up carefully.
Munich, 01 December 2019 | Rev. 1.3

Advertisement

loading
Need help?

Need help?

Do you have a question about the II dreamcut ready and is the answer not in the manual?

Questions and answers

Related Manuals for Mr Beam II dreamcut ready

Summary of Contents for Mr Beam II dreamcut ready

  • Page 1 DESKTOP LASERCUTTER QUICK START GUIDE When you start up your Mr Beam II dreamcut / dreamcut ready, remember that it has been assembled and packed by us with great care. We hope that you will take the time to unpack and set it up carefully.

  • Page 2: Safety Instructions

    You can find the latest manual and safety instructions in the menu of your Mr Beam user interface and on mr-beam.org Only process materials that Mr Beam Lasers has classified as harmless. You can find an up-to-date list of materials at mr-beam.org...
  • Page 3 SCOPE OF DELIVERY - WITH AIR FILTER SYSTEM LASER HEAD 2 KEYS CABLE AIR FILTER MR BEAM FOCUS TOOL POWER CABLE POWER SUPPLY UNIT Air Filter System AIR FILTER SYSTEM HOSE SUCTION SOCKET SCREWS WASHERS...
  • Page 4 MR BEAM FOCUS TOOL POWER SUPPLY UNIT HOSE SUCTION SOCKET SCREWS WASHERS For indoor use we recommend a Mr Beam Air Filter System. If you don‘t have one yet, order it now from our shop at store.mr-beam.org Air Filter System...
  • Page 5 UNPACKING MR BEAM First, remove the small box on the side. The laser head, the power adapter, the key and the Focus Tool are inside it. Remove the transport safeguard inside the device carefully.
  • Page 6 SETTING UP MR BEAM AIR FILTER SYSTEM Network connection (Ethernet)
  • Page 7 To adjust the laser focus to different material heights, the base plate can be mounted at different heights. You can make fine adjust- ments using the knurled screw and the slotted hole in the base plate. See the chapter: Mr Beam Focusing...
  • Page 8 Screw the contra-angle incl. hose to the AIR FILTER SYSTEM housing using the knurled screws. Also connect the Mr Beam Air Filter System or suction fan with the appropriate cable. Air Filter System Connect the Mr Beam Air Filter System or suction fan to your Mr Beam.
  • Page 9 Laser Klasse 1 Wartungsarbeiten das GerŠt immer ausschalten und den Netzstecker ziehen. Model: Mr Beam Turn on your Mr Beam using the key. It serves Mr Beam Lasers UG Gollierstr. 70d Vorsicht - sichtbares Laserlicht Klasse 4, Wartungs- und InspektionstŠtigkeiten...
  • Page 10 No internet access or network infrastructure is required. You may not be able to use the Internet on your computer while you are connected to Mr Beam. See page 11. Option B: Connection via network cable (Ethernet) and router Connect Mr Beam to the network router using a cable.
  • Page 11 Whether it is your first time setting up your Mr Beam or whether you have been connected to it many times, the Mr Beam Status Lights show you how you can connect to Mr Beam at the moment. For that, the status lights “breathe“ (pulsate up and down) in different colors.
  • Page 12 OPTION A: WI-FI ACCESS POINT Connect your computer directly to the Wi-Fi Access Point of your Mr Beam. Name: MrBeam-XXXX S/N: 0000000XXXXXXXXX-2X On your computer, select the Wi-Fi network Name: MrBeam-XXXX with the name of your Mr Beam: S/N: 0000000XXXXXXXXX-2X „MrBeam-XXXX“.
  • Page 13 OPTION B: CABLE AND ROUTER Connect your Mr Beam to your network with a cable. Connect your Mr Beam to your router with a network cable (Ethernet). The network socket is located on the back under the USB ports. Name: MrBeam-XXXX...
  • Page 14 This process is described in detail on page 11. Name: MrBeam-XXXX If you have a cable, select Option B to connect S/N: 0000000XXXXXXXXX-2X Mr Beam to your router with the cable. Now use Vor Beginn von Reinigungs- und Laser Klasse 1 Wartungsarbeiten das GerŠt immer ausschalten und den Netzstecker ziehen.
  • Page 15 Option A from the beginning. If you have selected the Option B using a cable for initial setup, Mr Beam will tell you if the connection to your router was successful or not. If successful, you can now disconnect the network cable, use the Wi-Fi connection and use the find.mr-beam service.
  • Page 16 CONNECTION TO MR BEAM - ORANGE PULSING If your Mr Beam is breathing orange, you can access your Mr Beam at find.mr-beam.org. find.mr-beam.org Google Chrome Enter the address find.mr-beam.org into your Google Chrome browser to connect to your Mr Beam.
  • Page 17 Made in Germany durch direkte oder Streustrahlung vermeiden Input: 19V 3.42A max XXXX stands for your specific device name, which is located on the back of your Mr Beam. Name: MrBeam-XXXX Password: mrbeamsetup The password for the Wi-Fi connection is: mrbeamsetup.
  • Page 18 If your Mr Beam is breathing white, you have several options to access your Mr Beam. Mr Beam is connected to a network either via network cable or by Wi-Fi. However, it can not connect to the find.mr-beam service, e.g. because there is no internet connection.
  • Page 19 For this adjustment, the distance between the bottom edge of the laser head and the top edge of the material 10mm Focus point has to be 10mm. Use the Mr Beam Focus Tool for this. Material Step 1: Move the laser head over the material by double clicking on the working area on your computer.
  • Page 20 For coarse focusing, the laser head can be mounted at different positions. To connect and disconnect the ribbon cable, Mr Beam must be disconnected from the power supply! First remove the laser head by using the knur- led screw and put it aside carefully. It is not necessarily needed to disconnect the ribbon cable.
  • Page 21 Continue to the material settings Working area Design library When the lid of Mr Beam is fully open, a photo is taken every five seconds and it is shown on the working area. Double-click anywhere to move the laser head to the desired position.
  • Page 22 MR BEAM SOFTWARE 1. Upload file Switch to the “design library“ area. Under “Upload“ or by dragging and dropping them into the browser window, you can upload files with the following extensions: .dxf, .svg, .gcode, .gif, .jpeg, .jpg, .bmp, .pcx, .png, ...
  • Page 23 After the lid of the laser is closed and the button pressed to confirm, Mr Beam starts to laser. The computer can then be disconnected or turned off from your Mr Beam, as the laser instructions are now on your Mr Beam. Never operate your Mr Beam unsupervised!
  • Page 24 Share your section: mr-beam.org/support results on Facebook, Twitter and Instagram or contact our friendly #madewithmrbeam customer service team through a Support Ticket at mr-beam.org/ticket © 2019 | Mr Beam Lasers GmbH | Gollierstraße 70 | Munich | Germany | www.mr-beam.org...
