INSTALLATION ID CPR50.10-E / -RE RFID Reader for ISO/IEC14443-A & -B, NFC and ISO/IEC15693 with Ethernet Interface RFID Access Control Terminal with Ethernet Interface (deutsch / english) Nur Hauptdokumentfinal - public (B) 2012-08-22 M90701-4de-ID-B...
Page 2
® OBID classic-pro Montage ID CPR50.10-E/-RE deutsche Version ab Seite 3 english version from page 18 FEIG ELECTRONIC GmbH Seite 2 von 31 M90701-4de-ID-B...
Page 3
® OBID classic-pro Montage ID CPR50.10-E/-RE Hinweis Copyright 2009-2012 by FEIG ELECTRONIC GmbH Lange Straße 4 D-35781 Weilburg Tel.: +49 6471 3109-0 http://www.feig.de Alle früheren Ausgaben verlieren mit dieser Ausgabe ihre Gültigkeit. Die Angaben in diesem Dokument können ohne vorherige Ankündigung geändert werden.
Geräts bzw. der Antenne aufhalten. 2. Beschreibung ID CPR50.10-E/-RE Der ID CPR50.10-xE ist ein Mitglied der OBID classic-pro Reader Familie und unterstützt passive Transponder gemäß ISO/IEC 14443 Typ A und Typ B, ISO/IEC15693 und kann mit NFC Geräten (ISO/IEC18092) kommunizieren.
ID CPR50.10-xE ist in zwei Versionen erhältlich: 1. ID CPR50.10-RE Version mit internem Relais 2. ID CPR50.10-E An diese Version kann das externe I/O Extention Board (ID CPR.I/O-A) angeschlossen wer- den, mit dem 2 digitale Eingänge und ein Relais zur Verfügung stehen.
® OBID classic-pro Montage ID CPR50.10-E/-RE 3. Montage und Anschluss Der Reader ist für die Wandmontage auf 60 mm Unterputzdosen oder für Aufputzmontage vorge- sehen. HINWEISE: Der Reader sollte nicht direkt auf leitende Materialien wie Metallflächen, Metallgitter (Armierung) oder metallisierte Oberflächen montiert werden, da diese Flächen eine Re- duzierung der Lesereichweite bewirken.
Page 8
® OBID classic-pro Montage ID CPR50.10-E/-RE 1. Montageort auswählen: Die Montage sollte auf einem möglichst ebenen Untergrund erfolgen. 2. Anschluss: siehe Kapitel: 3.1. Anschluss des Adapter Board 3. Wandmontage: Anschlussplatine von hinten in das Gehäuseunterteil einrasten (siehe: Abbildung Gehäuseunterteil auf der Wand verschrauben.
Der Anschluss des ID CPR50.10-xE erfolgt über die Adapter Platine, die im Readergehäuse einge- rastet wird. Abbildung 6: ID CPR50.10-E Adapter Platine mit LSA Anschlussleiste X2 3.1.1. LSA Anschluss X2 für TCP/IP Verbindung Der Anschluss des ID CPR50.10-xE an das Ethernet und das PoE Netzteil erfolgt über den LSA Anschluss X2.
Tabelle 2 Anschlussbelegung des internen Relais 3.1.3. Anschluss über PoE Netzteil ID CPR.IO Door Contact ID CPR50.10-E Ethernet PoE Power Supply (IEEE802.3af) Ethernet Abbildung 7: ID CPR50.10-E mit ID CPR.I/O-A und PoE Versorgung FEIG ELECTRONIC GmbH Seite 10 von 31 M90701-4de-ID-B...
3.1.4. Anschluss einer externe Spannungsversorgung ID CPR.IO Door Contact ID CPR50.10-E Ethernet Abbildung 8: ID CPR50.10-E mit ID CPR.I/O-A und 24 VDC Versorgung ID CPR50.10-xE Externe +24 V DC Externe (-) GND Tabelle 3 Anschluss für externe Spannungsversorgung an X3 HINWEIS: ...
® OBID classic-pro Montage ID CPR50.10-E/-RE 4. Technisch Daten ID CPR50.10-E/-RE Unterputzgehäuse 84 mm x 84 mm x 22 mm Abmessungen (L x B x H) Korpus: weiß / Frontscheibe: schwarz Farbe Aufputzadapter 77,7 mm x 77,7 mm x 18,0 mm...
® OBID classic-pro Montage ID CPR50.10-E/-RE 4.1. Abmessungen 84,2 mm 77,7 mm 56,8 mm 60,0 mm 60,0 mm Abbildung 10: Unterputzgehäuse Abbildung 11: Aufputzadapter Befestigungsmasse Befestigungsmasse 22 mm 84,2 mm 40 mm 14,0 mm Abbildung 12: Gehäuseabmessungen FEIG ELECTRONIC GmbH...
® OBID classic-pro Montage ID CPR50.10-E/-RE 5. Zulassung Funk - Europa EN 300 330 - USA FCC 47 CFR Part 15 - Kanada IC RSS-GEN, RSS-210, RSS-212 EN 301 489 Sicherheit - Niederspannung EN 60950 - Human Exposure EN 50364...
® OBID classic-pro Montage ID CPR50.10-E/-RE 6. Konfigurations-Reset (Werkseinstellung) Mit Hilfe des Jumpers B2 kann der Reader wieder auf Werkseinstellung zurück gesetzt werden. 1. Dazu das Gehäuseoberteil demontieren (siehe Kapitel: 3. Montage und Anschluss) 2. Einen 2 mm Jumper auf die Steckkontakte „B2“ stecken und den Reader wieder mit Spannung versorgen (Gehäuseoberteil wieder auf die Adapter-Platine stecken).
Page 17
® OBID classic-pro Montage ID CPR50.10-E/-RE FEIG ELECTRONIC GmbH Seite 17 von 31 M90701-4de-ID-B...
Page 18
® OBID classic-pro Installation ID CPR50.10-E/-RE Note Copyright 2009-2012 by FEIG ELECTRONIC GmbH Lange Strasse 4 D-35781 Weilburg Tel.: +49 6471 3109-0 http://www.feig.de With the edition of this document, all previous editions become void. Indications made in this manual may be changed without previous notice.
Page 19
9.1.3. Connection with PoE Supply ..................25 9.1.4. Connection with External Powered Supply ..............26 9.1.5. Connection of the extension I/O-Board ID CPR.I/O-A (ID CPR50.10-E only) ..... 27 9.1.5.1. Technical Data ID CPR.I/O-A ................. 27 10. Technical Data of the Reader Family ID CPR50.10-E/-RE 10.1.
DC power supply can be used. The ID CPR50.10-E can work in ISO-Host mode (polling) or in notification mode which reduces the necessary data traffic with the reader to a minimum. In notification mode the host will be informed by a notification message if a transponder was detected by the reader and can start the further data exchange with this transponder if required.
ID CPR50.10-xE can be ordered in two different versions 1. ID CPR50.10-RE Version with internal relay. 2. ID CPR50.10-E Version to connect the remote I/O-board (ID CPR.I/O-A) with one relay output and 2 digital in- puts. 8.1. System delivery contents...
® OBID classic-pro Installation ID CPR50.10-E/-RE 9. Installation The Reader has been designed for wall installation on 60 mm flush-mounting box. For surface in- stallation you can use the surface adapter. NOTES: The device must not be installed directly upon conductive materials as e.g. metal surfac- es, metal grids (reinforcements) or metalized surfaces, as these surfaces reduce the de- tection range of the Reader.
Page 23
® OBID classic-pro Installation ID CPR50.10-E/-RE 1. Select installation place: The installation should be executed always on a surface as even as possible. 2. Connection: see chapter 9.1. Connections 4. Wall installation: Snap in the connection board from the back side into the lower casing (see Fig. 3) ...
® OBID classic-pro Installation ID CPR50.10-E/-RE 9.1. Connections The connection of the ID CPR50.10-xE is carried out via a connection board which will be snapped into the housing. Fig. 6: ID CPR50.10-xE connection board with LSA terminal X2 9.1.1. LSA Connection X2 for TCP/IP Interface The connection of the ID MAX50.10-E with the Ethernet and PoE power supply will be carried out...
Table 2 Terminal assignment of the internal relay 9.1.3. Connection with PoE Supply ID CPR.IO Door Contact ID CPR50.10-E Ethernet PoE Power Supply (IEEE802.3af) Ethernet Fig. 7 ID CPR50.10-E with ID CPR.I/O-A and PoE FEIG ELECTRONIC GmbH Page 25 of 31 M90701-4de-ID-B...
ID CPR.IO Door Contact ID CPR50.10-E Ethernet Fig. 8 ID CPR50.10-E with ID CPR.I/O-A and external 24 VDC power supply ID CPR50.10-xE External + 24 V DC External (-) GND Table 3 Connection for the external power supply on X3 NOTICE: ...
® OBID classic-pro Installation ID CPR50.10-E/-RE 9.1.5. Connection of the extension I/O-Board ID CPR.I/O-A (ID CPR50.10-E only) Fig. 9: ID CPR.I/O-A ID CPR.I/O-A ID CPR50.10-E Symbol X3 Pin Ground GND-D +5 VDC Receive Input Transmit Output IN1* Digital Input 1...
OBID classic-pro Installation ID CPR50.10-E/-RE 10. Technical Data of the Reader Family ID CPR50.10-E/-RE Housing for flush-mounting box 84 mm x 84 mm x 22 mm (3.31" x 3.31" x 0.87") Dimensions (W x H x D) Corpus: white / Face plate: black...
® OBID classic-pro Installation ID CPR50.10-E/-RE 10.1. Dimensions 84,2 mm 77,7 mm 56,8 mm 60,0 mm 60,0 mm Fig. 10 Concealed casing Fig. 11 Surface adapter Fixing dimensions dimensions 22 mm 84,2 mm 40 mm 14,0 mm Fig. 12 Housing dimensions...
® OBID classic-pro Installation ID CPR50.10-E/-RE 11. Approval Radio - Europa EN 300 330 - USA FCC 47 CFR Part 15 - Canada IC RSS-GEN, RSS-210, RSS-212 EN 301 489 Safety - Low-Voltage EN 60950 - Human Exposure EN 50364...
® OBID classic-pro Installation ID CPR50.10-E/-RE 11.3. Declaration of Conformity for CANADA Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including inter- ference that may cause undesired operation of the device.
