Summary of Contents for Stairs Climbers Jacob

Page 1 Jacob Instruction Manual Wheelchair Stair Lift 1 ...
Page 2: Table Of Contents
Contents Essential Safety Information Description Features Technical parameters Initial Operation Turning the Unit On Checking the Battery Charge Operation Loading a Wheelchair User Climbing Stairs Descending Stairs Folding the Unit Maintenance Charging the battery pack Cleaning Recycling Troubleshooting...
Page 3: Essential Safety Information
1 Essential Safety Information The following symbols are used throughout this manual Caution: Failure to comply with this notice may result in injuries. Note: Failure to comply with this notice may result in damage to the unit or premises. Before Initial Operation ...
Page 4 While Operating the Unit Never change settings while climbing or descending stairs. ● Never put any part of a body, especially feet, under the climbing ● tracks. If the drive elements lock up, turn off the unit immediately. ●...
Page 5: Description
2 Description 2.1 Features 5 ...
Page 6: Technical Parameters
2.2 Technical parameters Product size (L*W*H) 63*56*112cm Folded size (L*W*H) 112*46*30cm Packing size(L*W*H) 120*60*35cm Load limit 200kg Net Weight. 33kg Gross Weight 49kg Height adjustment 112cm to 171cm with three height positions Overall depth ...
Page 7: Initial Operation
3 Initial Operation Note: Before the initial operation, please ensure the machine will be operated in an environment higher than 0°C. 3.1 Turning the Unit On The power switch is located on the lifting pallet, close the main frame. Turn the switch to the ON position. ...
Page 8: Operation
4 Operation Caution: Never leave a wheelchair user unattended in the unit and always use the supplied safety belts. Caution: The wheelchair stair lift should only be operated by trained personnel. Caution: ...
Page 9 When the desired position is reached, release the red button. There are 4 heights can be selected. Ensure the operating handle is locked in position by pulling on the handle with the button released. Adjust the headrest by depressing the upper of the red buttons on the ...
Page 10 Press the red button under the lock catch to adjust the lock catch. Adjust the position of each wheel loading tray by pulling the locking ring away from the unit and sliding the loading tray to the desired width. ...
Page 11: Climbing Stairs
Manoeuvre the wheelchair onto the unit as shown. The main wheels of the wheelchair should be firmly seated in the loading trays. The locking catches should secure the back of the wheelchair. The headrest should be in a comfortable position for the wheelchair user. ...
Page 12 Caution: Never touch any part of the climbing tracks when the unit is powered. Caution: Always ensure that all parts of the unit are securely locked into place, especially the stair climbing tracks, before climbing stairs. ...
Page 13 Turn on the control unit by pressing the red POWER button. Tilt the unit backward until the climbing track is in contact with the stairs. Press the UP button on the control unit to begin moving. When you have reached the top of ...
Page 14: Descending Stairs
4.3 Descending Stairs Caution: Never touch any part of the climbing tracks when the unit is powered. Caution: Always ensure that all parts of the unit are securely locked into place, especially the stair climbing tracks, before descending ...
Page 15: Folding The Unit
Turn on the control unit by pressing the red POWER button. Tilt the unit backwards and carefully push the unit towards the stairs until the climbing tracks engage on the stairs. If possible, have a second person positioned on the stairs to steady ...
Page 16 Remove each wheel loading tray by pulling the locking ring away from the unit and sliding the tray completely free of the unit. Lay the unit on the ground. Under the loading pallet are two screws.
Page 17: Maintenance
5 Maintenance 5.1 Charging the battery pack Caution: Do not use wet hands when operating the equipment. Notice: Charge the unit after each use. Notice: Protect the charger and the charging wires from oil, grease, detergent, thinner or any potentially damaging liquids. Notice: ...
Page 18: Cleaning
remove the charging cable and screw the charging port cover back into place. 5.2 Cleaning Clean the unit and its parts with a clean cloth or soft brush and warm soapy water. Rinse with warm water and air dry. Do not clean with products comprising of bleach or phenol.
Page 19: Troubleshooting
6 Troubleshooting Fault Detection and solution The unit won’t start or Ensure the main power switch on the loading can't go up or down pallet is in the ON position. The indicator light stairs should glow red. Check the battery charge. If it shows low power (<25%), charge the unit. ...
Page 20 ww.stairclimbers.com.au (03) 8899 6615 20 ...
