SyxthSense FLSER Product Sheet

FLSER Service Tool for Wireless
Room Transmitters
TEFL wireless room sensors operate in 868.30MHz range. They
have been designed for reliable operation in wide range of
environments using the latest RF technology. The communication
between the TEFL room units and the FLTA control module is
two-way. The measurement readings are transmitted on change,
or at least every hour.
Each FLTA control module can have up to 99 room sensors in its
operating area. Up to 16 control modules can operate in the same
wireless area. Total maximum of 1,584 room sensors can be
connected to the system in a single system.
Each room sensor is configured at the commisioning stage with its
own identification number (SID) and the control module number
(MID). The addressing is done using FLSER Configuration Tool.
FLREP repeaters can be used to extend and boost the range in
difficult environments. It possible to use up to 8 repeaters.
Model Type

Technical Data

Online store: www.syxthsense.com
Enquiries: T: 0870 20 80 100 F: 0870 20 80 200
Model
FLSER
Power supply
Battery Life
Transmission Frequency
Transmission Power
Reception Sensitivity
Modulation Technology
Transmission Range
Agency Approvals
Operating temperature
Ambient humidity
Dimensions (Sensors)
Description
Wireless Configuration Tool
3V6 AA Lithium battery 2Ah
FLREP - 12-24Vac/dc (24hr built-in power fail backup)
Depends on usage
868.30 MHz
+8 dBm
-109 dBm
FSK
Line of sight: Up to 500m
In buildings: 20..100m, depending on the wall materials
FLREP module can be used to extend the transmission range
in difficult environments.
EU Directive 2004/108
EMC Emissions EN61000-6-3: 2001
EMC Immunity EN61000-6-2: 2001
0°C...+50°C
5...95%rh (non-cond.)
87W x 86H x 32D mm
Product sheet SN1.123
FLSER
Sensor type
PS SN1.123 - 1/2
