TrynEx International, LLC, 531 Ajax Drive, Madison Heights, MI 48071-2429 • www.snowexproducts.com
PARTS LIST
6
* Includes additional parts needed to
install a 11228 Replacement Mop Frame
(item 8) on a legacy DPM-060 dust mop.
Item
Part
Qty Description
1*
D4292-1
1
60" Dust Mop Frame Kit
2
D4298
1
Broom Bracket
3
D4290
2
Hitch Pin
Item 1*
7
11727
1
DMP Arm/Retainer Kit
Item 7
9
1
Arm/Retainer Kit
10
2
3/8-16 x 1 Serrated Flange Hex Cap
Screw
60" Dust Mop Kit
VSB-060 Broom
1
10
9
DMP-060-1 60" Dust Mop Kit
D4292-1 60" Dust Mop Frame Kit
11727 DMP Arm/Retainer Kit
A DIVISION OF DOUGLAS DYNAMICS, LLC
7
12
11
1*
8
Item
Part
Qty Description
4
2
3/8-16 x 3/4 Hex Cap Screw
5
2
3/8 Lock Washer Zinc
6
D4295
1
60" Dust Mop
8
11228
1
60" Dust Mop Frame
11
1
Mount Arm Assembly
12
1
Dust Mop Retainer
DMP-060-1
February 1, 2019
Lit. No. 11275, Rev. 01
3
2
4
5
Advertisement
Related Manuals for Douglas Dynamics SweepEx VSB-060
Summary of Contents for Douglas Dynamics SweepEx VSB-060
- Page 1 D4292-1 60" Dust Mop Frame Kit 11727 DMP Arm/Retainer Kit 11228 60" Dust Mop Frame Item 7 11727 DMP Arm/Retainer Kit Arm/Retainer Kit Mount Arm Assembly 3/8-16 x 1 Serrated Flange Hex Cap Dust Mop Retainer Screw A DIVISION OF DOUGLAS DYNAMICS, LLC...
- Page 2 DMP-060-1 INSTALLATION INSTRUCTIONS 2. Attach the dust mop retainer to the end of the mount arm assembly using two 3/8" x 1" serrated CAUTION fl ange cap screws. Verify that the dust mop retainer is positioned as shown below. Read this document before installing the dust mop kit.
- Page 3 DMP-060-1 DUST MOP OPERATION 6. Insert one hitch pin through the top holes in the broom bracket and through the outermost pair of holes in the mount arm assembly. To use the dust mop, insert a second hitch pin only through the bottom holes in the broom bracket as NOTE: The hitch pin can stay in this position shown below.
- Page 4 DMP-060-1 Copyright © 2019 Douglas Dynamics, LLC. All rights reserved. This material may not be reproduced or copied, in whole or in part, in any printed, mechanical, electronic, fi lm, or other distribution and storage media, without the written consent of TrynEx International, LLC.
