BMW E6x/E9x Android Touch Screen
Radio Installation Instructions
Enjoy your new Android Radio from Bremmen Parts,
we appreciate your business.
Easy Installation:
•
This kit utilizes the stock mount-
ing hardware, making installation
quick and seamless.
Thousands of Apps:
•
From the Google play store you
can download your favorite audio
streaming service, video stream-
ing apps, navigation apps, or
even apps that can diagnose and
monitor your vehicles' systems.
Advertisement
Summary of Contents for Bremmen Parts UB8512
- Page 1 BMW E6x/E9x Android Touch Screen Radio Installation Instructions Enjoy your new Android Radio from Bremmen Parts, we appreciate your business. Vibrant Touch Display Easy Installation: • This radio features a responsive • This kit utilizes the stock mount- 8.8” touch display capable of ing hardware, making installation stunning HD resolution.
- Page 2 BMW E6X/E9X ANDROID RADIO INSTALLATION Listed below are the components which will need to be removed in order to install the new radio: 1. Factory radio screen 2. Dash trim panel 3. Climate control panel 4. Factory Radio Listed below are the different ports on the back of the radio and components we will be...
- Page 3 BMW E6X/E9X ANDROID RADIO INSTALLATION Here’s what’s included in the box: 1. Wiring Harness 2. Aux Cord 3. USB Port 4. Component Input Adapter 5. GPS Antenna Here’s all the tools required for this install: 1. Phillips Screwdriver 2. T10 Torx 3.
- Page 4 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 1: Removing the Stock Radio Step #1 • Ensure that your battery is disconnected prior to beginning installation. • Locate and remove the two vertical screws (arrows). Step #2 • Rotate the screen down and pull it partially out of the dash. Step #3 •...
- Page 5 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 1: Removing the Stock Radio Step #5 • Disconnect the connector (arrow) from the back side of the vent, then set the entire trim panel aside. Step #6 • Locate the two screws which secure the climate control panel to the vehicle (arrows). Step #7 •...
- Page 6 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 1: Removing the Stock Radio Step #9 • Remove the four screws (arrows) which secure the factory radio into the dash. Step #10 • Remove the big block connector (arrow) by releasing the sliding lock and pulling it free from the back side of the radio.
- Page 7 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 2: Installing the new Radio Step #1 • Connect the stock connector into the new wiring harness as shown. Step #2 • Reinstall the radio connector on the new harness into the back of the radio and close the sliding lock.
- Page 8 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 2: Installing the New Radio Step #5 • Plus the LVDS cable into the back of the new screen. Step #6 • Install the new GPS antenna by doing the following: Find a suitable location to mount the GPS antenna which is clear of obstacles that may cause signal interference.
- Page 9 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 2: Installing the New Radio Step #9 • Install the USB port by doing the following: Find a convenient location to mount the USB port, we found the glove compartment to work well on this model. Route the USB port to the desired mounting location, removing trim panels to tuck and secure the cable as needed.
- Page 10 BMW E6X/E9X ANDROID RADIO INSTALLATION Section 2: Installing the New Radio Step #13 • Turn the radio on and test for functionality (sound, video, steering wheel controls, GPS, Wifi, etc.) then: Reconnect the connector and install the trim panel. Slide the new screen into the dash and rotate it up until it sits flush. Install the two vertical screws (arrows) to retain the screen in place.
