For Replacement Parts and more detailed product information,
refer to the Guitar Storage Rack Assembly Instructions 148J325.
A
SSEMBLY
If Optional Security Cables are being used to secure instruments, pinch the looped end of the
Security Cable and slide it through the top of either the left or right side hole in the Yoke
as shown.
The washer end will keep it from sliding completely through.
Repeat for each Yoke that is to include a Security Cable.
Washer
End
Looped
End
Note: Please read and understand the instructions before attaching or using.
Note: If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2012
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 1-800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Basic Instructions only!
Security
Cable
Yoke
Printed in USA 11/12
Assembly/Operating Instructions
Security Cable for
Guitar Storage Rack
Part #148J328-01
Advertisement
Table of Contents
Summary of Contents for Wenger 148J325
- Page 1 Cable Yoke Looped Note: Please read and understand the instructions before attaching or using. Note: If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2012 Printed in USA 11/12 Part #148J328-01 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448...
- Page 2 PERATION Load the instruments onto the Guitar Storage Rack by placing the bottom end on the Rack Extrusions and the top end either into the Yoke or resting against the Yoke Assembly. Lock the Front Braking Swivel Casters when the Guitar Storage Rack is in the desired location. Unlock the casters to move the rack to a different location.
