INSTALLATION GUIDE
SI-500
510 Gallon Solids Interceptor for Indoor / Outdoor Use
Contents
Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Getting to Know the SI-500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Buried Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
On the Floor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Application Specific Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Part #: 5075-001-01
Find these instructions online at: schierproducts.com/si-500
© Copyright 2019 Schier, All Rights Reserved
Advertisement
Related Manuals for Schier SI-500
Summary of Contents for Schier SI-500
-
Page 1: Table Of Contents
Special Precautions .........2 Getting to Know the SI-500 ........3 Buried Installation . -
Page 2: Special Precautions
SPECIAL PRECAUTIONS For Schier Solids Interceptor Installations - Failure to follow this guidance voids your warranty DO NOT AIR TEST UNIT OR RISER SYSTEM! Do not install this unit in any manner Doing so may result in property damage, personal injury or death. -
Page 3: Getting To Know The Si-500
GETTING TO KNOW THE SI-500 Pickable Cast Iron Cover (standard) 10. 4" Cleanout Plug (x4) 19. Outlet Diffuser Retaining Nut 2. Cover Gasket 11. Inlet Diffuser 20. Outlet Diffuser 3. Safety Star (x2) 12. Inlet Diffuser Retaining Nut 21. Outlet Bulkhead Connection (optional) 4"... -
Page 4: Buried Installation
Inspect unit, connections and gaskets for leaks. Check water level at specific time intervals per local code. Leak? Call customer care at 913-951-3300 8a – 5p M – F CST SI-500 Installation Guide Page 4 of 11... - Page 5 Cap all unused connection points with 4" cleanout plugs using pipe thread sealant or tape approved for use with plastics. Straight-through SI-500 Installation Guide Page 5 of 11...
- Page 6 Wet or Air Test Piping Per Local Code Leak? Call customer care at DO NOT AIR TEST UNIT OR RISER SYSTEM! 913-951-3300 Doing so may result in property damage, personal injury or death. 8a – 5p M – F CST SI-500 Installation Guide Page 6 of 11...
- Page 7 ASTM A615: connected with tie wire. Rebar to be 2-1/2" from edge of concrete and spaced in a 12" grid with 45º 4" spacing around access openings. 18" Pedestrian Traffic or Greenspace Areas: Minimum 4" thick concrete slab with rebar required. SI-500 Installation Guide Page 7 of 11...
-
Page 8: On The Floor Installation
Inspect unit, connections and gaskets for leaks. Check water level at specific time intervals per local code. Leak? Call customer care at 913-951-3300 8a – 5p M – F CST SI-500 Installation Guide Page 8 of 11... - Page 9 Cap all unused connection points with 4" cleanout plugs using pipe thread sealant or tape approved for use with plastics. Straight-through SI-500 Installation Guide Page 9 of 11...
- Page 10 Wet or Air Test Piping Per Local Code Leak? Call customer care at DO NOT AIR TEST UNIT OR RISER SYSTEM! 913-951-3300 Doing so may result in property damage, personal injury or death. 8a – 5p M – F CST SI-500 Installation Guide Page 10 of 11...
-
Page 11: Installation Options
SI-500 must be secured to concrete deadmen anchors (by others) using Schier model AK2 anchor kit. deadmen anchors (by others) APPLICATION SPECIFIC DETAILS Typical Installation: SI-500 Solids Interceptor Followed by GB-500 Grease Interceptor with SV24-L4 Sampling Port SI-500 Installation Guide Page 11 of 11...
