Summary of Contents for Standing inOvation SiO X3
- Page 1 ATTENTION 3 Leg Installation Manual When assembling the system, ESPECIALLY THE STEPS WHILE ADDING THE CANTILEVER, by the middle of the 3 legs. ensure the control box is Patent number: 9,420,878 B2 9,723,918 B2...
-
Page 2: Unit Specifications
CAUTION Moving Parts Hazard Do Not Sit or Stand on Unit Your Standing inOvation unit contains multiple components. After opening the Standing inOvation box, ensure you have received the following: Sitting or standing on top of the Moving parts can pinch. - Page 3 Open box 1. Remove all parts from box. Please use two people for lifting Lay frame with actuators upside down. With cantilevers fully inserted, tighten actuators and frame. Rotate actuators up. Insert cantilevers. all four bolts with the provide Allen wrench.
- Page 4 Locate power management and power Identify the middle/ coner sleeve. In this Cord from box 1. Feed power cord example it is a right sleeve. Screw the cable through power management as shown. management with power cord to sleeve as shown.
- Page 5 With 2 people, adjust system to desired With 2 people, lift and lower actuators length. sleeves. 20 . Flip the 3rd leg over Lift and lower remaining 3rd leg into sleeve...
- Page 6 Attach all actuators to the control box. If needed use extension cable to connect Secure desired length, tighten bolts in frame with provided Allen wrench actuators to control box. Extensions work with either actuator/port. Secure actuators to sleeves with M10 bolts. Secure the other end of the cable management to the cantilever.
- Page 7 Remove handset from control box Place surface on frame, make sure the surface is square to the cubical. Pre-drill holes for wood screws in the cantilever and frame. Use 4 screws in each cantilever Plug the collision sensor into control box. and as many as possible in frame.
- Page 8 Press and hold both up and down Plug system into outlet. Pre-drill holes. buttons for 5 seconds to start system. Screw collision sensor in middle of desk and screw and set to desired location. Raise desk , attach top end of cable management Pre-drill holes.
- Page 9 USER GUIDE Enjoy your new sit-stand desk! After installation of your Standing inOvation desk, ensure the power cable is plugged into the outlet to power the desk. For more information, including a The first step is to perform a reset in order to calibrate the desk. To do this simply hold down both the user manual for how to use your buttons on the control for 3 seconds.
