Summary of Contents for Bistos BT-220
- Page 1 BT-220 Operation Manual BT-220 Keep this manual for future reference P/N: 220-ENG-OPM-EUR-R03...
- Page 2 Information furnished by Bistos Corporation is believed to be accurate and reliable. However, no responsibility is assumed by Bistos for its use, or any infringements of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent...
-
Page 3: Table Of Contents
BT-220 Operation Manual Table of Contents 1. SAFETY ....................3 1.1 Instructions for the Safe Operation and Use of the BT-220 Doppler ........3 1.2 Warnings ............................ 3 1.3 Cautions ............................. 4 1.4 Definitions of Symbols ......................5 2. INTROCUTION ..................6 2.1 Product Overview ........................ -
Page 4: Safety
The BT-220 is not specified or intended for operation in the presence of electrosurgical equipment. The BT-220 is not specified or intended for operation in conjunction with any other type of monitoring equipment except the specific devices that have been identified for use in this Operation Manual. -
Page 5: Cautions
Do not disjoint or Power off when the disassemble the equipment is not fully equipment. installed. BISTOS Co., Ltd. does Otherwise, the not take responsibility of equipment could be damaged. P/N : 220-ENG-OPM-EUR-R03 Bistos Co.,Ltd 2018.06... -
Page 6: Definitions Of Symbols
BT-220 Operation Manual Definitions of Symbols Symbol Description Power On/Off Button This symbol identifies a caution. Ensure you understand the function of this control before using it. Control function is described in the operation manual. Type BF Equipment IPX7 IPX7 Waterproof When disposing of some components, do not dispose as general wastes. -
Page 7: Introcution
Intended Use The BT-220 is a potable fetal Doppler that measures the fetal heart rate and outputs the fetal heart sound through a built-in speaker. Measuring the fetal heart rate (FHR) gives an indication of fetal well-being. -
Page 8: Exterior Component Designation
BT-220 Operation Manual Exterior Component Designation ◎ Front View, Top View & Right View ◊ BT-220L ① Custom Mono LCD ② Power and Mode Button, Speaker test and Up/Down Button ③ Charging Indicator LED ④ Built-in speaker ⑤ Ear Phone Jack ◊... - Page 9 BT-220 Operation Manual ◎ Rear View, Bottom View & Left View ① Product Label ② Battery Compartment ③ Probe Groove Joint ④ Probe Connection and Charging Jack ◎ Probe ① Sensor ② Probe Groove Joint ③ Probe Connector P/N : 220-ENG-OPM-EUR-R03 Bistos Co.,Ltd...
-
Page 10: Operation
BT-220 Operation Manual Section Operation Controls and Indicators 3.1.1 Button and Description ◊ BT-220L Button Description Speaker test On/Off Volume Down Volume Up Power On/Off ◊ BT-220C Button Description Mode change or menu select Volume Down, Speaker teste on and data value decrease... -
Page 11: Mode And Description
BT-220 Operation Manual 3.1.3 Mode and Description ◊ BT-220C Symbol Description This mode displays fetal heart rate and FHR Number heart rhythm with heart sound This mode displays fetal heart rate, heart FHR Graph rhythm and change of heart rate with... -
Page 12: Operation Of Bt-220
BT-220 Operation Manual Ultrasound transducer Search for the position which can get the clearest sound. Operation of BT-220 3.2.1 LCD Display ◊ BT-220L <Measurement> When the input signal is good and stable, FHR will appear on the screen and the solid heart rhythm indicator will flash as shown in Figure. -
Page 13: Fhr Mode
BT-220 Operation Manual ◊ BT-220C BT-220C has totally four modes. You can select the mode by pressing button for a short time. FHR Number mode FHR Graph mode BMI mode BMI trend mode 3.2.2 FHR(Fetal Heart Rate) Mode When the input signal is good and stable, FHR will appear on the screen and the solid heart rhythm indicator will flash as shown in Figure. -
Page 14: Bmi Calculation Mode
The sound is generated only at speaker. AST1 has 75 Hz and AST2 has 100 Hz frequency. 3.2.3 BMI(Body mass index) Mode BT-220 displays BMI(Body Mass Index) using the weight and height. 1) Mode Change (FHR mode → BMI mode): Press the button for a short time. BMI mode... - Page 15 BT-220 Operation Manual ② Last measured data ① Function of button ③ ④ Body composition graph Entered information ⑤ Pop-up window for deleting data 2) Information Setting: Press the button to enter the start menu. Item Select: Press the button to select item (Sex, Age, HT, WT) Change Value : Use the button to change the value.
-
Page 16: Bia Trend
BT-220 Operation Manual <Ready> <Processing> After pressing start, touch the metal electrode on the left side on main body with both thumbs. Then measurement begins automatically. If the contact area is small, the measurement may be inaccurate Information of setting age, height, weight will be saved automatically. -
Page 17: Unit Setting
BT-220 Operation Manual 3.2.5 UNIT Setting ② Function of buttons ① Unit set value 1) To enter unit setting menu, press down the button about 2 seconds. 2) Item select: Press the button shortly 3) Value Change: Press the button. -
Page 18: Maintenance & Cleaning
Section Maintenance & Cleaning This chapter contains instructions for the care and cleaning of the BT-220 unit and its accessories. The BT-220 requires proper care and preventive maintenance. If you use the material that is not approved, it may cause any damage to the product. In this case, the product will not be guaranteed even within the warranty period. -
Page 19: Specifications
BT-220 Operation Manual Section Specifications BT-220 fetal Doppler is complies with IEC 60601-1 and IEC 60601-1-2. And the ultrasound Doppler system complies with IEC 60601-2-37. General Ultrasound Frequency 2MHz, 3Mhz Intensity Less than 10mW/cm 50 ~ 240 bpm(BT-220L)/ Heart rate counting range... -
Page 20: Declaration On Emc
Section Declaration on EMC Electromagnetic emissions The BT-220 is intended for use in the electromagnetic environment specified below. The customer or the user of BT-220 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment-guidance... -
Page 21: Electromagnetic Immunity
Electromagnetic immunity The BT-220 is intended for use in the electromagnetic environment specified below. The customer or the user of the BT-220 should assure that it is used in such an environment. IEC 60601... - Page 22 BT-220 Operation Manual The BT-220 is intended for use in the electromagnetic environment specified below. The customer or the user of the BT-220 should assure that it is used in such an environment. IEC 60601 test Compliance Electromagnetic environment- Immunity test...
-
Page 23: 6.4 Immunity And Compliance Level
BT-220 Operation Manual 6.4 Immunity and Compliance Level [Probe : AY-2MHZDOP-220C (2 Hz, Vertical)] Image at Frequency of Interest Frequency of Interest** Actual Immunity Level [MHz] 160.54 MHz 3 V/m 201.82 MHz 3 V/m Radiated RF IEC 61000-4-3 * Voltage Level at which the RF Induced Noise is No Longer Discernable from the system ambient background noise. - Page 24 BT-220 Operation Manual Probe : AY-2MHZDOP-220C (2 Hz, Horizontal)] Image at Frequency of Interest Frequency of Interest** Actual Immunity Level [MHz] 82.42 MHz 3 V/m 152.74 MHz 3 V/m 216.38 MHz 3 V/m Radiated RF IEC 61000-4-3 * Voltage Level at which the RF Induced Noise is No Longer Discernable from the system ambient background noise.
- Page 25 BT-220 Operation Manual [Probe : AY-3MHZDOP-220C (2 Hz, Vertical)] Image at Frequency of Frequency of Interest** Actual Immunity Level Interest [MHz] 116.76 MHz 3 V/m 120.30 MHz 3 V/m Radiated RF IEC 61000-4-3 * Voltage Level at which the RF Induced Noise is No Longer Discernable from the system ambient background noise.
- Page 26 BT-220 Operation Manual [Probe : AY-3MHZDOP-220C (2 Hz, Horizontal)] Image at Frequency of Frequency of Interest** Actual Immunity Level Interest [MHz] 157.37 MHz 3 V/m 229.69 MHz 3 V/m 277.49 MHz 3 V/m Radiated RF IEC 61000-4-3 * Voltage Level at which the RF Induced Noise is No Longer Discernable from the system ambient background noise.
- Page 27 Sales Agency Manufacture Bistos Co., Ltd. ※ Thank you for purchasing BT-220. ※ This product is manufactured and passed through strict quality control and inspection. ※ Compensation standard concerning repair, replacement, refund of the product complies with “Framework Act on Consumers” noticed by Fair Trade Commission of Republic of Korea.
