Please familiarise yourself with the fitting
instructions before commencing fitting.
1. Check that you have the tools required.
2. Check that the installation site is compatible
with size of screen supplied
3. Check all the screen components.
4. Check that the installation kit is complete
Any parts missing or damaged must be reported to your supplier within 5 days of purchase.
Inspect shower enclosure before fitting .N o claims will be acceptable after product has been installed.
Installation Guide
MB8 Hinged Bath Screen
Important
M
MERLYN
SHOWERING
DO NOT
attempt to install the product unless you can
tick ALL
4 boxes as satisfactory.
The wall plugs supplied with the installation kit are for
use in solid walls. Hollow or ' s tud-partition' walls will
require alternative fixings. Please consult a hardware
supplier for the correct type.
It may also be necessary to consult your tiling supplier
about the correct method for drilling your tiles.
USE SAFETY EYEWEAR WHEN DRILLING
MerlynBath
Screens.
Advertisement
Table of Contents
Summary of Contents for MerlynBath Screens MB8
- Page 1 MerlynBath Screens. MERLYN SHOWERING Installation Guide MB8 Hinged Bath Screen Important Please familiarise yourself with the fitting DO NOT attempt to install the product unless you can instructions before commencing fitting. tick ALL 4 boxes as satisfactory. The wall plugs supplied with the installation kit are for 1.
- Page 2 COMPONENTS AND BOX CONTENTS Part No. Description Description Part No. Part No. Cover cap for wall profile L/R Luna rail end cap L/R M7017 M7010L/R Luna rail Wall profile M7013 M7014 M7016 Cover strip Bottom seal M7004 Moving panel Moving panel Hinge(in side) Screw ST4x12 A2403001...
- Page 3 INSTALLATION 2. Plumb the wall profiles using the vertical element of 1.Position the wall profile so the seal on the the spirit level. Mark 3 holes, drill with 6mm masonry moving panel sits on the inside edge of the bit and fit wall plugs. Using the 3 screw fix wall profile bath.
- Page 4 4. Insert the screen into the wall profile. Ensure the bottom edge of the moving panel is parallel to the top surface of the bath. Use spacer (M7020) to position. Fig4. INSIDE M7020 INSIDE FIG 4A FIG 4B 5. Drill 3 holes through the wall profile and 6.
- Page 5 7. Fix top cover cap(M7017) to wall 8. Position moving panel at 90 degrees to the fixed panel. Starting at the bottom profile (M7013). Fig 7. push on magnet seals fully. Open the moving panel and ensure both seals meet fully and provide a complete seal.
- Page 6 OPTIONAL If fitted the panels cannot be folded out over 11.Fitting the luna rail is optional. the luna rail as they will get damaged .Fix the luna rail on top of bath. Put a dab of silicone to bottom of each luna rail end cap (note left & right) and a thin bead of silicone to the bottom of the luna rail.
