Summary of Contents for Xvive Audio U2

Page 1 GUITAR WIRELESS SYSTEM...
Page 2: Caution Risk Of Electric Shock Do Not Open
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC Radio Approvals: FCC Part 15.249, FCC Part 15 B, RSS-210 SHOCK, DO NOT REMOVE SCREWS. NO USER-SERVICEABLE (Canada), EN 300 440 (Europe), EN 301.489 (Europe), Japan Radio 2.4GHz Band (Japan), MIC ARIB STD-T66 (Japan) PARTS INSIDE.
Page 3 CERTIFICATION THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. in a residential installation. This equipment generates, OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: uses and can radiate radio frequency energy and, if not (1) THIS DEVICE MAY NOT CAUSE HARMFUL installed and used in accordance with the instructions, INTERFERENCE, AND may cause harmful interference to radio communications.
Page 4 IMPORTANT SAFETY INSTRUCTIONS PLEASE THESE INSTRUCTIONS IN A SAFE PLACE WARNING: BEFORE USING YOUR XVIVE U2 DIGITAL WIRELESS SYSTEM, CAREFULLY READ THE OPERATING INSTRUCTIONS. 1. Observe all instructions carefully in the U2 manual. 3. Do not place near heat sources, such as radiators, heat 2.
Page 5: Product Introduction
This wireless is a perfect ﬁt for any pedal board thanks to its simplistic, and compact design. So, go wireless with the xvive U2 system. It’ll declutter the stage and oﬀers freedom in motion...
Page 6: Quick Start
QUICK START channels 1 ﬂash once channels 2 ﬂash twice channels 3 ﬂash three times channels 4 ﬂash four times 1. Transmitter plugs into the Guitar (you instruments), the 2. Turn on the Transmitter and the receiver and check the receiver plugs into the eﬀects pedal, AMP, Audio, etc.
Page 7: Quick Start Diagram
QUICK START DIAGRAM Hello! 3. After connecting successfully, LED lights on receiver will 4. Now, let’s rock together. keep light on.
Page 8: Basic Operation
BASIC OPERATION 1. Power – Slide Switch to turn on/oﬀ TRANSMETER/RECEIVER 2. Power LED and Battery LED Solid Red LED indicates the power on, The ﬂashing red LED indicates the battery is low charge, it needs to be recharged . In the progress of charging, the light will stop ﬂashing and will turn oﬀ...
Page 9 BASIC OPERATION 4. Transmitter Audio signal indicator LED When the signal is good, The receiver audio Signal indicator LED will become solid blue, it will start to ﬂash When Power is on, the Blue LED will ﬂash to indicate the if the signal is not good .
Page 10: Batteries And Charging
0:30 min 1 hour 1 hour 2 hours 2 hours 5 hours * Always store U2 at room temperature * When storing the unit, please check the battery state regularly and charge if necessary. Connect Power Connect to the socket Note: In an emergency, power can be supplied via a USB wall adapter however, the battery life will be reduced.
Page 11 2.4 GHz SPECTRUM OVERVIEW AND INTERFERENCE U2 operates within the 2.4GHz ISM band which is utilize 2.4Ghz Frequency Tables by Wi-Fi, Bluetooth, and other wireless devices. 2.4Ghz is CHANNEL1 2402MHZ,2480MHZ,2482MHZ an open band and, as such, does not require a license to be used worldwide.
Page 12 U2 can set up diﬀerent channels for U2 Receiver them to prevent signal interference. When there is only Since U2 is the 2.4 GHz wireless system, please avoid one player, the diﬀerent channel function can also be putting the receiver close to other signal emitting used for him/her to prevent interferences from diﬀerent...
Page 13 When The voltage output is 5V. The red LED light of U2 will be confront with interferrence from other devices or need always on for normal use. Red LED light ﬂashing means more distance for using, you can change the antenna's low battery which requires immediate power charge.
Page 14: Specifications
SPECIFICATIONS Tuning Bandwidth 2400 – 2483.5MHz >70 feet Line-0-site outdoors. Actual range depends on RF signal Working Range absorption, reﬂection and interference. Audio Frequency Response 20Hz – 20KHz(-3dB). Dependent on microphone type or Input signal. Dynamic Range >103dB Battery Life Up to 5 hours (3.7V Rechargeable Li-lon, 650mA) RF Sensitivity -85dBm...
Page 15: Application Scene
APPLICATION SCENE Guitar Effects Pedal Guitar AMP Guitar / Bass Portable PA Systems Piezo-electric Acoustic Guitar Recorders GUITAR WIRELESS SYSTEM...
Page 16 China Patent Numbers ZL 2016 3 0165464.8 2nd ﬂoor, Building 12, Xicheng Industrial Area, Xixiang Town, Baoan District, Shenzhen Guangdong China. 518101 E-mail: nancy@xviveaudio.com...
