USER MANUAL
18V Li-ion High Torque Brushless
Impact Wrench
SPECIFICATIONS
Square Driver . . . . . . . . . .1/2" (12 .7mm)
Motor . . . . . . . . . . . . . . . .18V
No load speed . . . . . . . . .(L) 0~900/min . (M) 0~1,200/min .
. . . . . . . . . . . .(H) 0~1,900/min . (R) 0~1,900/500/min .
Impacts per minute . . . . . .(L) 0~1,200 I .P .M . (M) 0~1,600 I .P .M .
. . . . .(H) 0~2,400 I .P .M .
Max . torque . . . . . . . . . . . .650 Nm
Net weight (w/o battery) . .2 .32kg
Charger
Model No . . . . . . . . . . . . . .FE IW 18V/T650C
Input . . . . . . . . . . . . . . . . .100V~240V, 50-60Hz, 80W
Charging voltage . . . . . . .20V
Battery
Model No . . . . . . . . . . . . . .FE IW 18V/T650B3 (3 .0Ah)
. . . . . . . . . . . . . .FE IW 18V/T650B4 (4 .0Ah)
. . . . . . . . . . . . . .FE IW 18V/T650B5 (5 .0Ah)
Lithium
Model No. : FE IW 18V/T650
6096-795515

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FE IW 18V/T650 and is the answer not in the manual?

Questions and answers

Summary of Contents for FE Powertools FE IW 18V/T650

  • Page 1 . . . . . . . . . . . . . .FE IW 18V/T650B4 (4 .0Ah) . . . . . . . . . . . . . .FE IW 18V/T650B5 (5 .0Ah) Lithium Model No. : FE IW 18V/T650 6096-795515...

  • Page 2: General Safety Rules

    GENERAL SAFETY RULES Thank You For Buying A FE Powertools tool Manufactured to Fe Powertools high standard for dependability, properly cared for, it will give you years of trouble free performance . Important: Carefully read through this entire owner’s manual before using your new tool . Pay close attention to the Rules for Safe Opera- tion .

  • Page 3: Important Safety Instructions For Charger

    Correct use: Universal fast chargers are to be used Use the power tool, accessories and tool bits etc., exclusively for charging 18V Fe Powertools serious in accordance with these instructions and in the rechargeable battery packs . Any other may result in...
  • Page 4 12 . To reduce risk of damage to electric plug and cord, Do not incinerate the battery, even if it is severely pull by plug rather than cord when dis-connecting damaged or completely worn out . The battery may charger . explode in fire.

  • Page 5: Operation Information

    • DISPOSAL OF THE EXHAUSTED BATTERY OPERATION INFORMATION WARNING : Do not attempt to disassemble WARNING : Before attempting to use any the battery pack . Fire or injury may result . tool, make sure your are familiar with all operating features and safety requirements .

  • Page 6: Indicator Lights

    • BATTERY CAPACITY INDICATOR NOTE: Do not use force when installing the battery pack . If the cartridge does not slide in easily, it is not being 1 . The tool is applied with the inserted correctly . battery capacity indicator (A) on the top pad for easy •...

  • Page 7: Led Light

    • FORWARD/REVERSE LEVEL L/M/H three modes only be selected at forward rota- tion, L/M/H three modes and mode (R mode) are WARNING : Always check the direction of selected at reversed rotation . When the letter you rotation before operation . press is lighted, the tool is ready to work .

  • Page 8: Maintenance Information

    • BELT HOOK • MAINTENANCE Place switch in OFF position and remove the battery CAUTION : When installing the hook, tighten before the appliance is serviced, cleaned, or mainte- the screw firmly.Failure to do so may cause the breakage of the toolor personal injury . nance is performed .
