• RM210A is a 2-post, 11U mobile rack that supports 1000 pounds.
• RM215A is a 4-post, 11U mobile rack that supports 1500 pounds.
• RM220A is a 2-post, 19U mobile rack that supports 1000 pounds.
• RM225A is a 4-post, 19U mobile rack that supports 1500 pounds.
Order toll-free in the U.S. or for FREE 24/7 technical support: Call 877-877-BBOX
Contact
(outside U.S. call 724-746-5500)
Information
www.blackbox.com • info@blackbox.com
RM210A
RM220A
RM215A
RM225A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM220A and is the answer not in the manual?

Questions and answers

Summary of Contents for Blackbox RM220A

  • Page 1 • RM210A is a 2-post, 11U mobile rack that supports 1000 pounds. • RM215A is a 4-post, 11U mobile rack that supports 1500 pounds. • RM220A is a 2-post, 19U mobile rack that supports 1000 pounds. • RM225A is a 4-post, 19U mobile rack that supports 1500 pounds.
  • Page 2: Important Information

    The Mobile Open Rack should be repaired by personnel trained by Black Box, or returned to Black Box for repair or replacement. Contact Black Box Technical Support at 877-877-2269 or go to blackbox.com and click on ”Talk to Black Box.”...
  • Page 3: Table Of Contents

    RM215A Exploded View .............................. 17 Assembling the RM215A ............................. 18 3.3 RM220A ..................................22 Tool List ..................................22 Parts List ..................................22 RM220A Exploded View .............................23 Assembling the RM220A............................. 24 3.4 RM225A ..................................28 Tool List ..................................28 Parts List ..................................28 RM225A Exploded View .............................29 Assembling the RM225A .............................30...
  • Page 4: Specifications

    RM215A: 24.27"H x 22.47"W x 29.36"D (61.64 x 57.1 x 74.57 cm); Dimensions RM220A: 38.27"H x 22.47"W x 19.86"D (94.66 x 57.1 x 50.4 cm); RM225A: 38.27"H x 22.47"W x 29.36"D (97.20 x 57.1 x 74.57 cm) 20" x 20" (50.8 x 50.8 cm) Bottom Plate Dimensions NOTE: Bottom plate serves as a built-in shelf.
  • Page 5: Overview

    • 4-post versions (RM215A and RM225A) have a mounting depth of 29". • Dual, heavy-duty, swiveling and locking casters hold up to 1000 lb. on the 2-Post versions (RM210A and RM220A) and 1500 lb. on the 4-post versions (RM215A and RM225A).
  • Page 6: What's Included

    Figures 2-1 through 2-4 show the Mobile Open Rack models available. Detailed assembly instructions are included in the Assembly section of this manual. 2.4.1 RM210A Figure 2-1. Mobile Open Rack - 2-Post, 11U (RM210A), top, angled front, and straight-on front views. 877-877-2269 | blackbox.com Page 6...
  • Page 7: Rm215A

    Chapter 2: Overview 2.4.2 RM215A Figure 2-2. Mobile Open Rack - 4-Post, 11U (RM215A)., top, angled front, and straight-on front views. 877-877-2269 | blackbox.com Page 7...
  • Page 8: Rm220A

    Chapter 2: Overview 2.4.3 RM220A Figure 2-3. Mobile Open Rack - 2-Post, 19U (RM220A), top, angled front, and straight-on front views.. 877-877-2269 | blackbox.com Page 8...
  • Page 9: Rm225A

    Chapter 2: Overview 2.4.4 RM225A Figure 2-4. Mobile Open Rack - 4-Post, 19U (RM225A), top, angled front, and straight-on front views. 877-877-2269 | blackbox.com Page 9...
  • Page 10: Assembly Instructions

    M8 x 16-mm hex-head machine screw M8 hex nut M8 flat washer M6 cage nut (not shown in exploded view) M6 x 12-mm pan-head machine screw (not shown in exploded view) 877-877-2269 | blackbox.com Page 10...
  • Page 11: Rm210A Exploded View

    Chapter 3: Assembly Instructions RM210A Exploded View Figure 3-1. RM210A exploded view. 877-877-2269 | blackbox.com Page 11...
  • Page 12: Assembling The Rm210A

    STEP 1: Place the 11U rack top (#2 in Figure 3-1) on the 2-post base plate (#1 in Figure 3-1) so that the three holes align on both sides. Figure 3-2. RM210A assembly, Step 1. 877-877-2269 | blackbox.com Page 12...
  • Page 13 (#5 in Figure 3-1), (6) M8 hex nuts (#6 in Figure 3-1), and (12) M8 flat washers (#7 in Figure 3-1). Do not tighten the bolts until all six hex head screws are inserted through their appropriate holes. Figure 3-3. RM210A assembly, Step 2. 877-877-2269 | blackbox.com Page 13...
  • Page 14 (#6 in Figure 3-1), and (32) M8 flat washers (#7 in Figure 3-1). Locking casters (#4 in Figure 3-1) should be attached on the same side. Do not attach locking casters on diagonal corners. Figure 3-3. RM210A assembly, Step 4. 877-877-2269 | blackbox.com Page 14...
  • Page 15 The Mobile Open Rack requires no further installation. Just slide it under your sitting-height or standing-height desk and roll the rack out when you need to access IT, test, diagnostic, and other electrical equipment stored on the rack. Its swiveling, locking casters make the rack easy to move and secure as needed. 877-877-2269 | blackbox.com Page 15...
  • Page 16: Rm215A

    M8 x 16-mm hex-head machine screw M8 hex nut M8 flat washer M6 cage nut (not shown in exploded view) M6 x 12-mm pan-head machine screw (not shown in exploded view) 877-877-2269 | blackbox.com Page 16...
  • Page 17: Rm215A Exploded View

    Chapter 3: Assembly Instructions RM215A Exploded View Figure 3-5. RM215A exploded view. 877-877-2269 | blackbox.com Page 17...
  • Page 18: Assembling The Rm215A

    STEP 1: Place one 11U rack top (#2 in Figure 3-5) on one side of the 4-post base plate (#1 in Figure 3-5) so that all six holes align with the holes in the base plate. Figure 3-6. RM215A assembly, Step 1. 877-877-2269 | blackbox.com Page 18...
  • Page 19 STEP 3: Tighten down all bolts holding the hex nut (#6 in Figure 3-5) with the open-end wrench (#1 in Tool List) and tighten the bolt head with the socket wrench (#2 in Tool List). 877-877-2269 | blackbox.com Page 19...
  • Page 20 (#6 in Figure 3-5), and (32) M8 flat washers (#7 in Figure 3-5). Locking casters (#4 in Figure 3-5) should be attached on the same side. Do not attach locking casters on diagonal corners. Figure 3-9. RM215A assembly, Step 5. 877-877-2269 | blackbox.com Page 20...
  • Page 21 The Mobile Open Rack requires no further installation. Just slide it under your sitting-height or standing-height desk and roll the rack out when you need to access IT, test, diagnostic, and other electrical equipment stored on the rack. Its swiveling, locking casters make the rack easy to move and secure as needed. 877-877-2269 | blackbox.com Page 21...
  • Page 22: Rm220A

    Chapter 3: Assembly Instructions 3.3 RM220A Tool List Item Number Tool Description 13-mm open-end wrench 13-mm socket and ratchet Parts List Item Number Quantity Part Description 2-post base plate 19U rack top swivel caster swivel, locking caster M8 x 16-mm hex-head machine screw...
  • Page 23: Rm220A Exploded View

    Chapter 3: Assembly Instructions RM220A Exploded View Figure 3-11. RM220A exploded view. 877-877-2269 | blackbox.com Page 23...
  • Page 24: Assembling The Rm220A

    STEP 1: Place the 19U rack top (#2 in Figure 3-11) on the 2-post base plate (#1 in Figure 3-11) so that the three holes align on both sides. Figure 3-12. RM220A assembly, Step 1. 877-877-2269 | blackbox.com Page 24...
  • Page 25 (#5 in Figure 3-11), (6) M8 hex nuts (#6 in Figure 3-11), and (12) M8 flat washers (#7 in Figure 3-11). Do not tighten the bolts until all six hex head screws are inserted through their appropriate holes. Figure 3-13. RM220A assembly, Step 2. 877-877-2269 | blackbox.com...
  • Page 26 (#6 in Figure 3-11), and (32) M8 flat washers (#7 in Figure 3-11). Locking casters (#4 in Figure 3-11) should be attached on the same side. Do not attach locking casters on diagonal corners. Figure 3-14. RM220A assembly, Step 4. 877-877-2269 | blackbox.com...
  • Page 27 Chapter 3: Assembly Instructions STEP 5: Assembly is complete. Figure 3-15. RM220A assembly, Step 5. STEP 6: Use the included (25) M6 cage nuts (not shown in Figure 3-11) and (25) M6 x 12-mm pan-head machine screws (also not shown in Figure 3-11) for mounting equipment.
  • Page 28: Rm225A

    M8 x 16-mm hex-head machine screw M8 hex nut M8 flat washer M6 cage nut (not shown in exploded view) M6 x 12-mm pan-head machine screw (not shown in exploded view) 877-877-2269 | blackbox.com Page 28...
  • Page 29: Rm225A Exploded View

    Chapter 3: Assembly Instructions RM225A Exploded View Figure 3-16. RM225A exploded view. 877-877-2269 | blackbox.com Page 29...
  • Page 30: Assembling The Rm225A

    STEP 1: Place one 19U rack top (#2 in Figure 3-16) on one side of the 4-post base plate (#1 in Figure 3-16) so that all six holes align with the holes in the base plate. Figure 3-17. RM225A assembly, Step 1. 877-877-2269 | blackbox.com Page 30...
  • Page 31 STEP 3: Tighten down all bolts holding the hex nut (#6 in Figure 3-4) with the open-end wrench (#1 in Tool List) and tighten the bolt head with the socket wrench (#2 in Tool List). 877-877-2269 | blackbox.com Page 31...
  • Page 32 Chapter 3: Assembly Instructions STEP 4: Repeat STEPS 1–3 to attach the second 19U rack top (#2 in Figure 3-16). Figure 3-19. RM225A assembly, Step 4. 877-877-2269 | blackbox.com Page 32...
  • Page 33 M8 hex nuts (#6 in Figure 3-16), and (32) M8 flat washers (#7 in Figure 3-16). Locking casters (#4 in Figure 3-16) should be attached on the same side. Do not attach locking casters on diagonal corners. Figure 3-20. RM225A assembly, Step 5. 877-877-2269 | blackbox.com Page 33...
  • Page 34 The Mobile Open Rack requires no further installation. Just slide it under your sitting-height or standing-height desk and roll the rack out when you need to access IT, test, diagnostic, and other electrical equipment stored on the rack. Its swiveling, locking casters make the rack easy to move and secure as needed. 877-877-2269 | blackbox.com Page 34...
  • Page 35 NOTES 877-877-2269 | blackbox.com Page 35...
  • Page 36 Tech support the way it should be. Great tech support is just 60 seconds away at 877-877-2269 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
