Summary of Contents for OAS Indo

  • Page 1 Oas Indo Operation & Maintenance...
  • Page 2 This manual applies to model OS8732 Ei2. (58)
  • Page 3 Thank you for purchasing the Oas shower system. To enjoy the full potential of the shower please read and follow the procedures in this manual. Make sure that you fully understand how to operate this shower and (58) make sure that it is properly maintained in accordance with the instructions given in this manual.
  • Page 4 Caution risk of personal injury - the shower has • If the Indo cosmetic cover is not correctly fitted a temperature barrier lock at 38 degrees Celsius • If the shower system is damaged which can be removed manually but may lead to •...
  • Page 5 S A F E T Y I N S T R U C T I O N S The Oas recirculating shower system is designed for regular showering only. Do not use the shower to clean extreme soiling or pour corrosive chemicals or cleaners down the shower drain. Any other use of the system could seriously deteriorate the quality of the filtration system or damage the shower system.
  • Page 6 S A F E T Y I N S T R U C T I O N S These instructions are provided to advise the This is an earthed appliance, the connection to the best practice for the installation. All installations earth circuit is mandatory.
  • Page 7 WA R R A N T Y The Oas shower and its components are manufactured from high-quality materials and assembled under strict standards. Orbital Systems warranty covers defects which appear within a period of 5 years from delivery of the product or prior to the consumption of 500,000 litres of water by use of the product, whichever of the two is the sooner.
  • Page 8 S E R V I C E Orbital Systems and our team of expert staff including our certified Service Partners are available to assist you should you require product advice, experience any problems, need to purchase spare parts or to set up a service visit. We recommend your first point of contact should be your installer, who will be able to offer all of the above services.

  • Page 9: Table Of Contents

    TA B L E O F C O N T E N T S Operating the Oas Shower Maintenance Overview Changing the Filter Capsule Changing the UV Lamp (58) Cleaning the Quartz Glass Cleaning the Sensor Tank Unit Running the Cleaning Program...

  • Page 10: Operating The Oas Shower

    O P E R AT I N G T H E O A S S H O W E R (58)
  • Page 11 P U S H T O S TA R T A N D S T O P S H O W E R (58) The Oas shower performs a short startup sequence to fill up the system and adjust water temperature before water starts pouring out of the shower head.
  • Page 12 A DJ U S T T E M P E R AT U R E (58)
  • Page 13 M E N U Long press to Turn to navigate. Push to select action. access the menu. (58)
  • Page 14 O P E R AT I N G T H E H A N D S H O W E R (58)

  • Page 15: Maintenance Overview

    M A I N T E N A N C E O V E R V I E W (58)
  • Page 16 • Sensor Tank Unit cleaning should be performed weekly. • Do not use any corrosive detergents during the cleaning and maintenance of the Oas shower system. • Do not use abrasive pads or cloths as these may damage the product.
  • Page 17 C O N S U M A B L E C O M P O N E N T S The Oas shower is equipped with five consumable components that will require periodic replacement to ensure optimal performance throughout the product’s life time. Consumable components are not covered by the warranty.
  • Page 18 C O N S U M A B L E C O M P O N E N T S Recirculation mesh Descaling tablet The Recirculation Mesh located in the Sensor Tank The descaling tablet is essential when running the is essential in trapping larger particles so that Cleaning Program.

  • Page 19: Changing The Filter Capsule

    M A I N T E N A N C E O V E R V I E W Changing the Filter Capsule Changing the UV Lamp Cleaning the Quartz Glass (58) Cleaning the Sensor Tank Unit Running the Cleaning Program...
  • Page 20 M A I N T E N A N C E C O M P O N E N T O V E R V I E W Filter Capsule Filter Bay Filter Clamp UV Lamp (58) UV Cover UV Connector Quartz Glass M3 (2mm driver), x2...
  • Page 21 O P E N T H E I N D O PA N E L (58)
  • Page 22 C H A N G I N G T H E F I LT E R C A P S U L E Filter Capsule Model No: OS C1050085A10 Use only Orbital Systems Filter Capsule OS C1050085A10 in the shower system. For further assistance or to order any (58) replacement consumable components contact:...
  • Page 23 (58)
  • Page 24 (58)
  • Page 25 (58)
  • Page 26 Make sure Filter Capsule is inserted correctly or leakage may occur. “Click!” (58)
  • Page 27 C H A N G I N G T H E U V L A M P UV Lamp Model No: OS1040019 Use only Orbital Systems UV Lamp OS1040019 in the shower system. For further assistance or to order any (58) replacement consumable components contact: support@orbital-systems.com...
  • Page 28 Always wait a minimum of 10 minutes after the shower has been running before accessing and handling the UV Lamp. We recommend you wear clean gloves. (58) Handle with care, the UV Lamp contains mercury. UV Lamp disposal Recycling is available at many home improvement stores or at your local hazardous waste facility.
  • Page 29 (58)
  • Page 30 (58)
  • Page 31 Mercury Handle with care. (58)
  • Page 32 (58) Insert new UV Lamp.
  • Page 33 (58)
  • Page 34 (58)
  • Page 35 C L E A N I N G T H E Q U A R T Z G L A S S (58) watch video: https://bit.ly/2QPQga1...
  • Page 36 Always wait a minimum of 10 minutes after the shower has been running before accessing and handling the Quartz Glass. We recommend you wear clean gloves. (58) Quartz Glass disposal Recycling is available at many home improvement stores or at your local hazardous waste facility.
  • Page 37 (58)
  • Page 38 (58)
  • Page 39 (58)
  • Page 40 Hand tighten only or leakage may occur. (58)
  • Page 41 C L E A N I N G T H E S E N S O R TA N K U N I T (58) watch video: https://bit.ly/2VVKfw6...
  • Page 42 (58) Use non-abrasive cleaning agents only.
  • Page 43 (58)
  • Page 44 (58)
  • Page 45 (58) Use non-abrasive cleaning agents. Make sure to clean all surfaces of each component, including the built-in Drain Unit.
  • Page 46 (58)
  • Page 47 (58)
  • Page 48 (58)
  • Page 49 Make sure Smart Sensor Unit is inserted correctly. The O-ring should not be visible. (58)
  • Page 50 (58)
  • Page 51 (58)
  • Page 52 R U N N I N G T H E C L E A N I N G P R O G R A M (58) watch video: https://bit.ly/2sxw5nm...
  • Page 53 The Cleaning Program shall be performed every second week. Use a standard descaling tablet (>10g tablet) for coffee machines with at least one of the following ingredients: • Citric acid • Sulfamic acid • Sodium carbonate Recommended suppliers for cleaning tablets: (58) •...
  • Page 54 (58) Place the Descaling Tablet directly under the Shower Head.
  • Page 55 Long press to access the menu. (58)
  • Page 56 (58)
  • Page 57 (58) 04:58 Make sure water is running through all shower nozzles. Running Cleaning Program Exit the shower area...
  • Page 58 Cleaning program (58) successful...
  • Page 59 C E R T I F I E D S P A C E T E C H N O L O G Y...
