- Page 1 User Manual Q.NET-5TX and Q-NET-8TX Industrial Ethernet Rail Switch Document 27-667 │ Release ENG01 │ 2019-08-14...
-
Page 2: Table Of Contents
Recycling note ..................1-5 Description General device description ..............2-1 Device name and product code ............2-1 Device view ................... 2-2 2.3.1 Q.NET-5TX .................... 2-2 2.3.2 Q.NET-8TX .................... 2-3 Power supply ..................2-3 Ethernet ports ..................2-4 2.5.1 10/100 Mbit/s twisted pair port .............. 2-4 Pin assignments .................. - Page 3 Removing the device ................6-1 Technical data General technical data ................7-1 Dimension drawings ................7-2 7.2.1 Q.NET-5TX .................... 7-2 7.2.2 Q.NET-8TX .................... 7-2 EMC and immunity ................7-3 Network range ..................7-3 Power consumption/power output at 24 V DC ........7-4 Scope of delivery ...................
-
Page 4: Content
Saia-Burgess Controls AG Content Dokumentversionen | Handelsmarken und Warenzeichen Document history Version Published Chapter Remarks ENG01 2019-08-14 First edition Trademarks ® Saia PCD is a registered trademark of Saia-Burgess Controls AG. Subject to technical changes in line with the latest technological developments. Saia-Burgess Controls AG, 2019. -
Page 5: Safety Instructions
Saia-Burgess Controls AG Safety instructions Safety instructions General safety instructions You operate this device with electricity. Improper usage of the device entails the risk of physical injury or significant property damage. The proper and safe opera- tion of this device depends on proper handling during transportation, proper stor- age and installation, and careful operation and maintenance procedures. -
Page 6: Qualification Requirements For Personnel
Saia-Burgess Controls AG Safety instructions 1.5 Qualification requirements for personnel ■ Only allow qualified personnel to work on the device. Qualified personnel have the following characteristics: f Qualified personnel are properly trained. Training as well as practical knowl- edge and experience make up their qualifications. This is the prerequisite for grounding and labeling circuits, devices, and systems in accordance with cur- rent standards in safety technology. -
Page 7: Requirements For Connecting Electrical Wires
The power supply cable is suitable for the voltage, the current and the physical load. SBC recommends a wire diameter of 0.5 mm² (AWG20). f The cross-section of the ground conductor is the same size as or bigger than the cross-section of the power supply cables. -
Page 8: Supply Voltage
Saia-Burgess Controls AG Safety instructions Supply voltage | CE marking 1.10 Supply voltage The supply voltage is only connected with the ground connection via protective elements. 1.11 CE marking The labeled devices comply with the regulations contained in the following Euro- pean directive(s): ●... -
Page 9: Fcc Note
Saia-Burgess Controls AG Safety instructions FCC note | Recycling note 1.12 FCC note This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Description
Saia-Burgess Controls AG Description General device description | Device name and product code Description General device description The SPIDER-SL devices are designed for the special requirements of industrial automation. They meet the relevant industry standards, provide very high opera- tional reliability, even under extreme conditions, and also long-term reliability and flexibility. -
Page 11: Device View
Saia-Burgess Controls AG Description Device view Device view 2.3.1 Q.NET-5TX LED display elements for device status 3-pin, pluggable terminal block for power supply 3 … 7 5 × RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections Rail lock gate for DIN rail mounting... -
Page 12: Q.net-8Tx
Saia-Burgess Controls AG Description Device view | Power supply 2.3.2 Q.NET-8TX LED display elements for device status 3-pin, pluggable terminal block for power supply 3 … 6 4 × RJ45 socket for 10/100 Mbit/s twisted pair connections Rail lock gate for DIN rail mounting 8 …... -
Page 13: Ethernet Ports
Saia-Burgess Controls AG Description Ethernet ports | Pin assignments Ethernet ports 2.5.1 10/100 Mbit/s twisted pair port This port is an RJ45 socket. The 10/100 Mbit/s twisted pair port offers you the ability to connect network com- ponents according to the IEEE 802.3 10BASE-T/100BASE-TX standard. This port supports: f Autonegotiation f Autopolarity... -
Page 14: Display Elements
Saia-Burgess Controls AG Description Display elements Display elements After the supply voltage is switched on, the device performs a self-test. During this process, various LEDs light up. 2.7.1 Device state This LED provides information on the status of the power supply. Color Activity Meaning... -
Page 15: Port State
Saia-Burgess Controls AG Description Display elements 2.7.2 Port state These LEDs provide port-related information. LS/DA Color Activity Meaning (link status/data) Green Lights up Device detects a valid link Flashing Device is transmitting and/or receiving data None Device detects an invalid or missing link Color Activity Meaning... -
Page 16: Installation
Saia-Burgess Controls AG Installation Checking the package contents Installation The devices have been developed for practical application in a harsh industrial environment. On delivery, the device is ready for operation. To configure a subdomain, follow these steps: f Checking the package contents f Mounting the device f Wiring the terminal block for the supply voltage and the grounding f Operating the device... -
Page 17: Mounting The Device
Saia-Burgess Controls AG Installation Mounting the device Mounting the device You have the following options for mounting your device: f Installing the device onto the DIN rail f Mounting on a flat surface 3.2.1 Installing the device onto the DIN rail Prerequisite: The device is for mounting on a 35 mm DIN rail in accordance with DIN EN60715. -
Page 18: Wiring The Terminal Block For The Supply Voltage And The Grounding
Saia-Burgess Controls AG Installation Wiring the terminal block for the supply voltage Wiring the terminal block for the supply voltage and the grounding WARNING ELECTRIC SHOCK Connect only a supply voltage that corresponds to the type plate of your device. Never insert sharp objects (small screwdrivers, wires, etc.) into the connection terminals for the supply voltage, and do not touch the terminals. -
Page 19: Operating The Device
Saia-Burgess Controls AG Installation Operating the device | Datenkabel anschließen Operating the device By connecting the supply voltage via the terminal block, you start the operation of the device. Connecting data cables Note the following general recommendations for data cable connections in envi- ronments with high electrical interference levels: f Keep the length of the data cables as short as possible. -
Page 20: Monitoring The Ambient Air Temperature
Saia-Burgess Controls AG Monitoring the ambient air temperature Monitoring the ambient air temperature Operate the device below the specified maximum ambient air temperature exclu- sively. See „7.1 General technical data“ auf Seite 7-1. The ambient air temperature is the temperature of the air at a distance of 2 in (5 cm) from the device. -
Page 21: Maintenance And Service
Failure to follow these instructions can result in injury or equipment damage. Note! You will find information about the complaints and returns procedures on the Inter- net under: https://www.sbc-support.com/en/services/repair-service/ User Manual Q.NET-xTX │ Document 27-667 – Release ENG01 │ 2019-08-14... -
Page 22: Disassembly
Saia-Burgess Controls AG Disassembly Removing the device Disassembly Removing the device Proceed as follows: ■ Disconnect the data cables. ■ Disable the supply voltage. ■ Remove the power connector from the device. ■ Use a screwdriver to pull the rail lock gate downwards. ■... -
Page 23: Technical Data
Saia-Burgess Controls AG Technical data General technical data Technical data General technical data Characteristic values Descritpion Dimensions See „7.2 Dimension drawings“ auf Seite 7-2. W × H × D Power supply f 1 voltage input f 3-pin terminal block f Safety extra-low voltage (SELV) Rated voltage range DC 12 V ... -
Page 24: Dimension Drawings
Saia-Burgess Controls AG Technical data Dimension drawings Dimension drawings 7.2.1 Q.NET-5TX 7.2.2 Q.NET-8TX User Manual Q.NET-xTX │ Document 27-667 – Release ENG01 │ 2019-08-14... -
Page 25: Emc And Immunity
Saia-Burgess Controls AG Technical data EMC and immunity | Network range EMC and immunity EMC interference emission Radiated emission FCC 47 CFR Part 15 Class A EN 55022 Class A Conducted emission FCC 47 CFR Part 15 Class A EN 55022 Class A EMC interference immunity Electrostatic discharge... -
Page 26: Power Consumption/Power Output At 24 V Dc
Saia-Burgess Controls AG Technical data Diverse Power consumption/power output at 24 V DC Device name Max. power consumption Power output Q.NET-5TX 2,0 W 7,0 BTU(IT)/h Q.NET-8TX 1,5 W 5,3 BTU(IT)/h Scope of delivery Number Article 1 × Device 1 ×... -
Page 27: Appendix
Saia-Burgess Controls AG Appendix A Icons Appendix Icons In operating instructions, this symbol points the reader to further information in these instructions, in other instructions or in technical documents. No direct link to these documents is given. Instructions with this symbol must always be followed. This symbol warns the reader of the risk to components from electrostatic discharges caused by touch. -
Page 28: Contact
3280 Murten, Switzerland Telefon ........+41 26 580 30 00 Fax .......... +41 26 580 34 99 Email Support: ....... support@saia-pcd.com Supportsite: ......www.sbc-support.com SBC site: ........ www.saia-pcd.com International Represetatives & www.saia-pcd.com/contact : ..... SBC Sales Companies Postal address for returns from customers of the Swiss Sales office Saia-Burgess Controls AG Service Après-Vente...
