  • Page 1 Operating Instructions Monarch 9876™ and 9878 ® ™ Mobile Work Station (MWS™) 28028 TC987xOI Rev. AE 10/19 ©2007 Avery Dennison Corp. All rights reserved.
  • Page 2 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Avery Dennison Corp. reserves the right to make changes in the product, the programs, and their availability at any time and without notice. Although Avery Dennison Corp.

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S GETTING STARTED ........................1-1 About the MWS .......................... 1-1 About the 9876 Optional Accessories ..................1-1 Attaching the Hanging Folders ....................1-2 Connecting the Power Cord ......................1-2 Routing the Cables (9878 MWS) ....................

  • Page 5: Getting Started

    G E T T I N G S T A R T E D Use the Monarch® 9876™ and 9878™ Mobile Work Station™ (MWS™) for mobile printing. A b o u t t h e M W S The MWS ships mostly assembled. There are optional accessories available for the 9876 MW S that may require some assembly.

  • Page 6: Attaching The Hanging Folders

    Attaching the Hanging Folders Follow the steps below to attach the hanging folders to the 9876 MWS. . 1. Remove the following items from their packaging: (1) file folders (4) 3/8" plastite screws (may already be attached to panel) 2. Use the assembly instructions provided with the file folders to assemble folders to the MWS panel.

  • Page 7: Safety Precautions

    S a f e t y P r e c a u t i o n s The following symbols are used in this manual to show the importance of safety when using the MW S. WARNING Failure to follow the guidelines marked with this symbol could result in serious personal injury or death.
  • Page 8 1-4 Operating Instructions...

  • Page 9: Charging The Batteries

    C H A R G I N G T H E B A T T E R I E S The battery charger is a fully automatic, maintenance-free charger. Dispose of used batteries according to the manufacturer’s instructions. CAUTION: The charger's power switch does not control MWS power. The MW S power switch, located on the power panel, controls power to the MWS and connected devices.

  • Page 10: Battery Life

    B a t t e r y L i f e The MWS Battery Status LEDs are located on the top-left side of the Power Panel. To use the Battery Status LEDs, the MW S must be on. If you leave the battery charger plugged in and constantly charging when the MWS is not in use (turn MWS power off), the battery life is maximized for the application.

  • Page 11: Important Charging Information

    I m p o r t a n t C h a r g i n g I n f o r m a t i o n WARNING: DANGER! RISK OF ELECTRICAL AND FIRE HAZARD. CERTAIN ACTIONS MAY RESULT IN DEATH, SERIOUS INJURY, SHOCK, OR BURNS. ♦...

  • Page 12: Charger Leds

    Charger LEDs Use this table to read the charger’s LEDs: Status Description Red LED Yellow LED Green LED Calibrating charger BLINKING BLINKING Preparing to charge Charging Completing charge BLINKING Batteries are charged (fan off) Error BLINKING BLINKING Note: Chargers using firmware version 3.0 and later indicate firmware version using LED blinks.

  • Page 13: Specifications

    S P E C I F I C A T I O N S M W S The specifications for the 9876 and 9878 mobile work stations are listed below. 9876 9878 ≈42 inches (1067 mm) ≈37 inches (940 mm) Height: depending on selected options depending on selected options...

  • Page 14: Chargers

    C h a r g e r s Tw o Batteries Input 180-264 VAC @ 3.0 - 1.5 A 50/60 Hz IEC 320-C14 Connection Output 24 VDC, 8 Amps DC charging current ♦ Reverse polarity and short circuit-proof ♦ 8 to 11 hours full charge, typical recharge time is 3 to 8 hours The recharge time depends on the battery size and amount of charge remaining.

  • Page 15: Wiring Diagrams

    W I R I N G D I A G R A M S This appendix contains wiring diagrams for the various power options: ♦ 24v with DC-to-DC Converter, 12v (9876) ♦ 24v with 700w Inverter (9876) ♦ 24v with 1,000 Inverter (9876/9878) WARNING Only qualified service personnel may install or replace the two 12-volt sealed lead acid batteries used to power the printer on the Station.
  • Page 16 2 4 v w i t h D C - t o - D C C o n v e r t e r , 1 2 v ( 9 8 7 6 ) B-2 Operating Instructions...
  • Page 17 2 4 v w i t h 7 0 0 w I n v e r t e r ( 9 8 7 6 / 9 8 7 8 ) Wiring Diagrams B-3...
  • Page 18 2 4 v w i t h 1 , 0 0 0 W a t t I n v e r t e r ( 9 8 7 6 / 9 8 7 8 ) B-4 Operating Instructions...
  • Page 20 28028 Avery Dennison 170 Monarch Lane Miamisburg, OH 45342 1-800-543-6650 (In the U.S.A.) 1-800-387-4740 (In Canada) www.monarch.com...
