- Page 1 SmartCD.G2 Manual 22.05.2019...
-
Page 2: Table Of Contents
Contents SmartCD.G2 (Manual) 2 / 19 Contents Intended use .............................. 3 Safety instructions ............................ 4 Scope of supply ............................ 6 Connection to a PC/laptop........................ 7 Charging the batteries .......................... 8 Initial operation............................ 9 Configuring the Bluetooth connection.................... 10 Initial installation ............................ 10 Changing the connection ........................... 10 Programming with Smart CD ......................... 11... -
Page 3: Intended Use
3 / 19 1 Intended use The SmartCD.G2 is a programming device which has been specially developed to run on a PC, netbook or laptop or in conjunction with a Windows Mobile 5.x / 6.x PDA. It is a very convenient way for you to programme and read all digital components in SimonsVoss System 3060 (locking cylinders, transponders, SmartHandles and SmartRelays). -
Page 4: Safety Instructions
Do not open or burn them, or heat them to over 70°C. CAUTION Do not remove or replace batteries. SimonsVoss Technologies GmbH can replace used batteries for a fee. CAUTION Ensure that the device does not fall onto the floor and is not exposed to any other type of impact. - Page 5 (Manual) 5 / 19 IMPORTANT We can only guarantee error-free functioning during programming with a Windows Mobile 5.x PDA if you use devices approved by SimonsVoss. IMPORTANT The manufacturer reserves the right to make technical changes at any time. IMPORTANT In the event of doubt, the original German language manual applies.
-
Page 6: Scope Of Supply
Cable to connect to a USB port You need the SimonsVoss software LDB or LSM to use the SmartCD.G2. You also need the LSMmobile software on your mobile device to programme components in situ. This software is not included in the scope of supply, so it must be ordered separately. -
Page 7: Connection To A Pc/Laptop
If you programme with a PDA and SmartCD, you will need to unplug the cable connecting the SmartCD.G2 to the PC or laptop again. It is not pos- sible to use Bluetooth to communicate between SmartCD.G2 and a PC or laptop. -
Page 8: Charging The Batteries
Beware: the USB port will probably deactivate if a laptop is switched off. IMPORTANT If you do not wish to use your SmartCD.G2 for a longer period of time, con- nect it to the USB port. This prevents the batteries from discharging and the device is thus ready for use at any time. -
Page 9: Initial Operation
Install the SmartLSM locking plan software using ActiveSync on the PDA. Interconnect SmartCD.G2 and PDA via Bluetooth (use the SmartLSM to do so). Set COM port on the PDA to SmartCD.G2 (use the SmartLSM to do so) ... -
Page 10: Configuring The Bluetooth Connection
SmartCD.G2 and the PDA. Select 'SV [your device's serial number]' for the SimonsVoss device. When you connect the PDA to SmartCD.G2 for the first time, you should ensure that no other SmartCD.G2s with an activated Bluetooth are within the receiving range. -
Page 11: Programming With Smart Cd
8. Programming with Smart CD SmartCD.G2 (Manual) 11 / 19 8 Programming with Smart CD During programming, there should a minimum gap of around 10 cm between SmartCD and the locking device; for SmartRelay it should be around 30 cm and 70 cm for the block lock. -
Page 12: Antenna Alignment
Antenna alignment for selected components is described below to ensure error-free programming. You can achieve the greatest possible read range for programming if the SmartCD.G2 and locking device antennas are positioned in parallel to one another. As a general rule, the distance between antennas should be at least 10 cm to prevent overshooting. -
Page 13: Replacing The Batteries
13 / 19 10 Replacing the batteries Contact your retail specialist if you should need to replace batteries. The retailer can then have batteries replaced by SimonsVoss Technologies GmbH for a fee. IMPORTANT Do not try to replace the batteries yourself under any circumstances. -
Page 14: Signals
The first LED (green/POWER) lights up when the SmartCD.G2 is connected to the PC or laptop using USB or when the SmartCD.G2 is switched on by pressing the button without a USB connection. The device can be switched off again to save power by re-pressing the button. -
Page 15: Technical Specifications
12. Technical specifications SmartCD.G2 (Manual) 15 / 19 12 Technical specifications Housing dimensions H x W x D: 112 x 63 x 22 mm Weight, including batteries: 95 g Housing material: Plastic Housing colour: Grey Number of LEDs: Li-ion manganese batteries (per-... -
Page 16: Declaration Of Conformity
13. Declaration of conformity SmartCD.G2 (Manual) 16 / 19 13 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article Programmiergerät complies with the following guidelines: 2014/53/EU "Radio equipment" 2014/30/EU "EMC" 2011/65/EU "RoHS" 2012/19/EU "WEEE"... -
Page 17: Help And Other Information
Take the packaging to an environmentally responsible recycling point. Hotline If you have any questions, the SimonsVoss Service Hotline will be happy to help you on +49 (0)89 99 228 333 (German fixed network; call charges vary depending on the operator). - Page 18 14. Help and other information SmartCD.G2 (Manual) 18 / 19 FAQs You will find information and help for SimonsVoss products in the FAQ section on the SimonsVoss website ( https://faq.simons-voss.com/otrs/ public.pl SimonsVoss Technologies GmbH Feringastrasse 4 85774 Unterföhring Germany...
- Page 19 Unterföhring, near Munich, and its production site in Osterfeld, eastern Germany, the company employs around 300 staff in eight countries. SimonsVoss is a company in the ALLEGION Group, a globally active network in the security sector. Allegion is represented in around 130 countries worldwide (www.allegion.com).
