Robus RDN00740-01 Instruction Manual

DINGLE 7W IP44 LED COACH LANTERN
4000K WHITE OR BLACK
RDN00740-01, RDN00740-04
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
! Electrical products can cause death or injury, or damage to property. If in any doubt about the installation or
use of this product, consult a competent electrician
Product technical information and specification may change over time without prior notification
For the latest technical information please visit our web site www.ledgrouprobus.com or robusdirect.com
Specifications
Model No.
Voltage:
Power:
Lumen:
CCT:
CRI :
Beam Angle:
Ta Range:
IP Rating :
Safety Class:
Dimensions(mm):
Weight :
Warranty :

Installation :

Suitable for mounting on normally flammable surface

Information for the Product user:

1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE marked with
crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre for waste electrical
equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is important that it is
separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal household waste, but should be
disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Issue 1 050914
RDN00740
220-240V~50/60Hz
7W
420lm
4000K
85
120
o
-20°C < ta < 45°C
44
Class II
(H)380 x (W)175 X (D)240
0.5Kg
3 year
Wall mounted,
Tel: +353 1 7099000
Fax: +353 1 7099060
Email: info@led.ie
Website: www.led.ie
Note:
Installation
1. Ensure mains supply is switched off before commencing
work.
2. Remove the front cover.
3. Mark appropriate fixing points on wall; check that fixings will
not impinge on concealed cables of pipes before drilling
holes.
4. Introduce the cable through cable entry, connect supply to the
terminal block, Brown (live) to L and Blue (neutral) to N
5. Attach fitting to wall by screws provided, ensure that it is
secure
6. Attach cover to base, ensure that the screws are tight and
cover is secure
This product has no user serviceable parts. If any part is
damaged, disconnect from mains and discontinue use.
INSTRUCTION MANUAL
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
1
