- Page 1 XM3BT Multimedia Speaker User manual Unpack the Box Box contents Left satellite speaker Subwoofer Right satellite speaker 3.5mm-3.5mm audio cable User manual...
- Page 2 Illustrations 1. Press: Bluetooth/USB/SD card mode: previous track FM mode: quick adjustment to low frequencies Press and hold: USB/SD card mode: previous folder 2. Press: play/pause (Bluetooth/USB/SD card mode) Press and hold: search for full frequencies (FM mode) 3. Press: Bluetooth/USB/SD card mode: next track FM mode: quick adjustment to high frequencies Press and hold:...
- Page 3 Connection 1. Connect satellite speakers to subwoofer using connecting cables from the satellite speakers, please pay attention to color matching: red port is right sound channel and white port is left sound channel. 2. Connect subwoofer to power source using power cable from the subwoofer and turn on power switch, LED indicator will be lit and the speakers should be ready to go.
- Page 4 Operational Guide 1. Connect to audio source. Select audio source. Green: AUX/Line in Red: SD card/USB Blue: Bluetooth Orange: FM radio Play music on the connected device and adjust the settings to a desired level.
- Page 5 Operational Guide FM Mode Orange: FM 1. Press the “ ” button on the side panel of the subwoofer to select FM mode, LED indicator will turn orange. 2. Press and hold the “ ” button on the side panel of the subwoofer to start searching for and presetting radio stations, orange indicator will flash during searching and will be constantly lit after searching is complete.
- Page 6 ” button on the side panel of the subwoofer to select Bluetooth mode, LED indicator will turn blue. 2. Set your Bluetooth device to search for and connect to “EDIFIER XM3BT”. 3. Pin code for connection is “0000” if needed.
- Page 7 Specifications Power output: R/L: 8W+8W SW: 18W Frequency response: R/L: Hz-KHz SW: Hz-Hz Mid-range and treble unit: 3 1/2 inch (88mm) Bass unit: 5 1/4 inch (148mm) Audio input: AUX/Line in/Bluetooth/USB/SD card...
