Patcher I Diesel

PART MANUAL - 56933

Rev. 0

Table of Contents

Troubleshooting

Need help?

Do you have a question about the Crafco Patcher I Diesel and is the answer not in the manual?

Questions and answers

Summary of Contents for Ergon Crafco Patcher I Diesel

Page 1 Patcher I Diesel PART MANUAL - 56933 Rev. 0...
Page 2 Revised: 02/06...
Page 3 Patcher I Diesel Part Number 56900 (Skid Mount)
Page 4: Table Of Contents
TABLE OF CONTENTS Patcher I ..........................5 Safety Precautions.......................6-7 Limited Warranty........................8 Warranty Claim Instructions....................9 Specifications........................10 Introduction..........................11 Operating Instructions Machine Start Up..................12 Figures 1 and 2.................... 13 Figures 3 and 4.................... 14 Figures 5 and 6.................... 15 Figures 7 and 8.................... 16 Caution......................
Page 5: Patcher I
Patcher I Diesel This manual is furnished with each new CRAFCO Patcher I Diesel MIXER. The manual will help your machine operators learn to run the mixer properly and understand its mechanical functions for trouble-free operation. Your CRAFCO Patcher I Diesel MIXER is designed to give excellent service and save maintenance expense.
Page 6: Safety Precautions
SAFETY PRECAUTIONS • High operating temperatures of product and machine require protective clothing, long sleeve shirt, long pants/coveralls, hat or hard hat (if required) and flame resistant gloves be worn by operator. • Always wear eye protection (goggles or faceshield) when operating hot compressed air lance, air gas lance and when applying material.
Page 7 SAFETY PRECAUTIONS continued • Follow operating instructions for starting and shut-down of burner. Instructions are mounted on control box. • Replace any hoses which show signs of wear, fraying, or splitting. Be sure all fittings and joints are tight and leak-proof. •Precaution is the best insurance against accidents.
Page 8: Limited Warranty
Patcher I Diesel LIMITED WARRANTY Crafco, Inc., through its authorized distributor, will replace for the original purchaser free of charge any parts found upon examination by the factory at Mesa, Arizona, to be defective in material or workmanship. This warranty is for a period within 60 days of purchase date, but excludes engine or components, tires, and battery as these items are subject to warranties issued by their manufacturers.
Page 9: Warranty Claim Instructions
WARRANTY CLAIM INSTRUCTIONS Please follow the instructions stated below when calling in a Warranty Claim. Failure to follow these procedures may be cause to void the warranty. Call your local Crafco Distributor. If you do not know who your local distributor is, call a Crafco Customer Service Representative, (toll free 1-800-528-8242) for name, location, and telephone number.
Page 10: Specifications
SPECIFICATIONS Vat Capacity............. 95 gallons Heat Transfer Oil Required........17 gallons at 70 Tank Construction............ Double boiler type Tank Opening Size (2)..........14.25” x 17.88” (each) Maximum Heat Input..........260,000 B.T.U. Burner & Temperature Control........Automatic - Digital readout. Hot oil and material. Auto flame shutdown.
Page 11: Introduction
Patcher I Diesel OPERATING INSTRUCTIONS INTRODUCTION The Crafco Patcher I Diesel Mixer was developed to melt patching material. DO NOT operate machine without following these instructions: Check engine crankcase oil level (refer to Engine Operator Manual). Check hydraulic fluid level, at ambient temperature. Add fluid if necessary to bring to correct level (approximately 3”...
Page 12: Machine Start Up
MACHINE START UP Start engine. To start engine, insert key into the control panel. Turn key to first position. Warning lights should turn “ON.” Turn key to second position. Engine should start. Release key when engine is running. Leave at idle for a few minutes. Move throttle lever to set engine at desired speed (see Fig.
Page 13: Figures 1 And 2
grease fitting Fig. 1 safety chain discharge gate Fig. 2...
Page 14: Figures 3 And 4
mixer control switch Fig. 3 heat transfer dipstick Fig. 4...
Page 15: Figures 5 And 6
throttle lever Fig. 5 temperature dials toggle switch Fig. 6...
Page 16: Figures 7 And 8
engine fuel tank Fig. 7 by-pass valves Fig. 8...
Page 17: Caution
CAUTION Extreme care must be used when operating this equipment. Safety is the result of being careful and paying attention to details. Certain exposed parts of this machine, when operat- ing, reach 500 F.; the material as high as 400 F.
Page 18: Trouble Shooting Chart
TROUBLE SHOOTING CHART l a i l a i & c i l u l f . l e c i l o l f o l f . y r d l i i l l o l l .
Page 19: Maintenance Instructions
MAINTENANCE INSTRUCTIONS ENGINE: Check oil daily. Service engine per Yanmar owners manual. See engine owners manual for additional operating and maintenance instructions. HYDRAULIC SYSTEM: Check hydraulic fluid daily. Change hydraulic filter after 250 hours. Change hydraulic fluid every 500 hours of operation. MIXER PACKING GLAND/SEALS: Tighten gland while hot at 40 hour intervals.
Page 20: Maintenance Chart
MAINTENANCE CHART...
Page 21: Recommended Fluids & Lubricants
RECOMMENDED FLUIDS & LUBRICANTS i g n l i o r e f . l a . s t m i l l e s . s l m i l c i l l i o - l i .
Page 22: General Maintenance Items
GENERAL MAINTENANCE ITEMS t l i INSTRUCTIONS FOR ORDERING PARTS Parts may be ordered from your local CRAFCO distributor or directly from CRAFCO, Inc. if a distributor is not available in your area. When ordering parts, give the following information: Part Number Machine Model Serial Number from Name Plate...
Page 23: Patching Material Placement
HOT APPLIED PATCHING MATERIAL PLACEMENT Prior to the material application you will need to move the equipment to the work area. The items needed are: Compressor Saw to cut out repair area Pneumatic hammer Broom and shovels to clean up area Broom or sweeper (if required to remove FOD) TechCrete machine, material, and application tools Dressing stone...
Page 24: Application Of The Patching Product
APPLICATION OF THE PATCHING PRODUCT During the time you have been preparing the patch areas you should have calculated the amount of material needed for the repairs. Place bags of material in the mixer and heat. Start the agitator as soon as possible to break up the bags.
Page 25: Burner Trouble Shooting
BURNER TROUBLE SHOOTING BURNER WILL NOT IGNITE Step 1: Check for 12 volts at “POWER” toggle switch. No: Engine key “OFF” Toggle switch “OFF” Blown fuse Broken wire YES: 12 volts at terminal #4 on “MATERIAL” Pak-Stat NO: Bad Pak-Stat Faulty sensor YES: Check for 12 volts at terminal #7 on “OIL”...
Page 26: Diesel Burner Electrode Adjustment
DIESEL BURNER ELECTRODE ADJUSTMENTS DIESEL BURNER SETTINGS Air Shutter = 6 Air Band = 0 Fuel Pressure = 140 PSI Use fuel and hydraulic pressure gauge kit part number 29960.
Page 27: Rtd Sensor - Ohms Vs. Temperature
RTD SENSOR - OHMS vs. TEMPERATURE The following chart shows what the ohm reading would be for a given temperature.The follow- ing are the instructions for use. Measure the resistance (Ohms) of the sensor in question with an Ohm meter. Find the reading in the chart.
Page 28: Patcher I Diagrams And Parts
Patcher I Diesel...
Page 29 Patcher I Diesel " 4 " 6 " 4 " 4 " 4 " 4 " 6 " 6 " 4 " 6 " 6 " 2 " 1...
Page 30 Patcher I Diesel...
Page 31 Patcher I Diesel " 2 " 4 " 4 - " - " " 4 " 1 " 1 " 8...
Page 32 Patcher I Diesel " 1 " 8 " 2...
Page 33: Place For Noted
Patcher I Diesel Notes...
Page 34: Hydraulic Diagram And Parts
Patcher I Diesel HYDRAULIC DIAGRAM...
Page 35 Patcher I Diesel HYDRAULIC PARTS...
Page 36 Patcher I Diesel HYDRAULIC PARTS...
Page 37 Pioneering Leadership and Innovation in Quality Pavement Maintenance Products. 235 South Hibbert Mesa, Arizona 85210 • 480-655-8333 • Watts 1-800-528-8242 Fax 480-655-1712 ©Copyright 2003 by Crafco, Inc.
