  • Page 1 FLAME C-3 MK2 KNOB RECORDER MANUAL Version 1.00...

  • Page 2: Table Of Contents

    MANUAL FLAME KNOB RECORDER Version 1.00 Contents 1. Short description ..............3 2. Hardware / Connections ............. 3 2.1 Connection to the modular system (Doepfer bus) 2.2 Module overview 2.3 Module backside 3. Handling ................3.1 Manual mode (Stop) 3.2 Record 3.3 Play back...

  • Page 3: Short Description

    1. Short description The C3 module is a three-channel module for recording and playing back movements of con- trollers. Those can be recorded with each channel´s individual knob. The movements will be out- put as control voltages. The record time amounts to one minute maximal. The track can be played once only (one shot) or in loop.
  • Page 4 2.2 Modul overview Key RECORD Mode LED Key PLAY Key STOP Pots for CV, Speed or Offset CV-1 input for track 1 (0..10V , +/-5V) CV outputs of tracks 1-3 (0..10V, +/-5V) Trigger input RESET (0/5V)

  • Page 5: Module Backside

    2.3 Module backside At the bottom of the module there is a slide switch for setting the polarity of the module (the range is either unipolar 0 .. + 10V or bipolar +/- 5V) as well as the socket for the backup battery of the memo- ry.

  • Page 6: Handling

    3. Handling 3.1 Manual mode (Stop) After power on the module stands in STOP mode. All LEDs are off. With the pot you can adjust an output voltage between 0 and +10V. Track 1 can alternatively output and record a voltage applied to the CV-1 input.

  • Page 7: External Reset

    3.4 Play functions (Speed and Offset) You can use two switchable functions in Play mode: - SPEED (the speed of the play back) and - OFFSET (shifting the CV output up or down). Toggle between both functions while you hold down the button STOP and then you press the button PLAY.

  • Page 8: Technical Details

    - electric damage caused by improper connecting (wrong power supply/ jacks/ MIDI connections/ voltage problems). If you have any complaints please contact your dealer or send an e-mail to: service@flame-instruments.de 4.3 Terms of production conformity: CE, RoHS, UL 4.4 Disposal The device is produced with RoHS-conformity (subject to the regulations of the European Union) and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
