Grape Solar STONE User Manual

STONE
Power pack User Manual
Thank you for purchasing the Stone portable power pack.
It is a rechargeable device designed to store energy from a
portable solar panel or USB charging port and use that
power to charge mobile devices including, but not limited
to, smart phones, tablet PCs and MP3 players. Please read
the manual carefully before using this product and be sure
to keep this manual in a safe place for future reference.
Use Guidelines
Please read this manual carefully before using the
product.
Be sure to select the proper connector for your device.
Do not attempt to charge a device with your power pack
at the same time your power pack is charging.
When the power pack is not in use disconnect all cables.
Only use an adapter that matches the input specifications
of the mobile power pack. Using the wrong adaptors
may damage the device.
Safety Precautions
Do not expose the power pack to prolonged high temper-
atures over 110°F (45°C).
Do not short circuit the power pack
Do not store or transport the device near sharp objects
that may puncture the power pack.
Keep power pack away from water. If the power pack
becomes wet unplug the cables immediately.
Do not use the power pack if there is an electrolyte
leakage, strange odor, overheating, color change or any
other abnormal occurrences.
Product Introduction
A. Mobile power pack
B. Product Specifications:
Battery Type Polymer Lithium-ion battery
Nominal Input DC 5V/1000mA
Nominal Output DC 5V/1000mA
Capacity 5200mAh@3.7V(19.2Wh)
Dimensions 99x72x18mm
Weight 142g
Color Optional
Operating Temperature 14°F to 110F° (-10°C to 45°C)
Operation Guide
Charging the mobile power pack
1.
Charging via the USB Cable: Plug the USB cable into a USB
1-1
adaptor that can plug into a wall outlet or computer. Plug the
USB end of the charging adaptor cable into the adapter and the
micro-USB end of cable into the power pack input port.
Charging via Solar: Plug the USB cable into the power pack input
1-2
port, then plug the USB cable into the Grape Solar portable
panel's USB port.
When the mobile power pack is being charged the capacity
1-3
indication lights will flash. When it is fully charged, the lights will
stop flashing.
